The Operator Panel is programmed to display a range of messages about operational
conditions on its two line screen. The first line displays the description of the condition and the
second line displays the required action (if any). These are summarised in Table 8-2:
Display Line 1 (Condition)
System Power-up
Confirm Mute?
Mode Change?
Obstruction during mute point setup
Ambient light present
Start-up test1 complete
Receiver clear / obstruction status error
No movement detected on down command
No material sensed below mute point
No movement detected with down command active
Opening too small for start-up test
Down stroke stopped by first obstruction in normal mode
Down stroke stopped by second obstruction in normal mode
Down stroke stopped by outside obstruction in tray mode
Down stroke stopped by centre obstruction in tray mode
Down stroke stopped at mute point in 'stop at mute' mode
Crawl speed due to field muted mode
Crawl speed due to second obstruction in normal mode
Crawl speed due to centre obstruction in tray mode
Crawl speed due to open tools with protection off
Crawl speed due to no start-up test being performed
Error detected, emergency stop activated
Do Start-up Test1
Set new mute pnt
Unrecognised Error Code
Table 8-2: Operator panel condition codes
Abbreviations
The following abbreviations are used for conciseness in some of the above messages:
Abbreviation
pdl
pnt
prs
s
Table 8-3
Version 1.11
p e r a t o r P a n e l C o n d
p e r a t o r P a n e l C o n d
Meaning
Pedal
Point
Press
Seconds
LZS-003-HS Operation Manual – Dual Laser Version
i t i o n s
i t i o n s
Display Line 2 (Action Required)
Press 'SET'
Press 'SET'
Press 'SET'
Press 'SET'
Press 'SET'
Down / Up pedal
Receiver line check error
Press 'SET'
Return to top
Release down pdl
prs 'SET' for 2s
Release down pdl
Release down pdl
Release down pdl
Release down pdl
Release down pdl
LASER INACTIVE
-
-
-
RESET MACHINE
Check Error Code
Press down pedal
Press down pedal
-
