Summary of Contents for Plustek SecureScan X50

  • Page 1 SecureScan Installation Usage...
  • Page 2 Trademarks © 2017 Plustek Inc. All rights are reserved. No portion of this document may be reproduced without permission. All trademarks and brand names mentioned in this publication are property of their respective owners. Liability While all efforts have been made to ensure the accuracy of all contents in this...

  • Page 3: Table Of Contents

    Installing and Setting up the Scanner ............... 10 Step 1. Connecting the Scanner to Your Computer ............10 Step 2. Installing the Software.................... 12 Step 3. Testing the Scanner ....................13 Uninstalling the Plustek device driver and software ..........14 II. S ..........15 HAPTER...

  • Page 4: Introduction

    Introduction Thank you for choosing us as your scanner supplier. Your new scanner will improve the professionalism of your day-to-day computing tasks by allowing you to input images and electronic text into your computer system. Like all of our products, your new scanner is thoroughly tested and backed by our reputation for unsurpassed dependability and customer satisfaction.

  • Page 5: A Note About Icons

    This guide uses the following icons to point out information that deserves special attention. A procedure that must be followed carefully to prevent injury, or accidents. Warning Instructions that are important to remember and may prevent mistakes. Attention Optional tips for your reference. Information Safety Precautions Before using this device, please read the following important information to...

  • Page 6: System Requirements

    System Requirements ® PC with Intel Pentium IV 1.8GHz processor (2.4GHz Recommended) 512 MB RAM (1GB RAM Recommended) Available USB 2.0 port CD-ROM Drive or DVD-ROM Drive 500 MB Free Hard Disk Space Operating System: Windows 7 / 8 / 10 Higher requirements might be needed when scanning or editing a large quantity of image data.

  • Page 7: Box Contents

    Box Contents X50 / X100 1. Scanner 2. USB Cable 3. Quick Guide 4. Setup/Application CD-ROM 5. Cover X150 1. Scanner 2. USB Cable 3. AC Adapter 4. Quick Guide 5. Setup/Application CD-ROM 6. Cover Save the box and packing materials in case you need to transport this scanner in the future. The product packaging can be recycled.

  • Page 8: Scanner Overview

    Scanner Overview X50 / X100 1. Scan Indicator: Indicates the scanner’s scan status. The scanner will beep and the scan indicator will blink when the scan process is finished. Light Status The scanner has completed the scanning task. It also comes with Blinking a beep sound.
  • Page 9 6. USB Port: It connects the scanner to a USB port on your computer by the included USB cable.
  • Page 10 X150 1. Scan Indicator: Indicates the scanner’s scan status. The scanner will beep and the scan indicator will blink when the scan process is finished. Light Status The scanner has completed the scanning task. It also comes with Blink a beep sound. The scanner is currently not scanning.
  • Page 11 6. Power Switch: Use this to turn the scanner ON or OFF. 7. Power Receptor: Connects the scanner to a standard AC power outlet by the AC adapter included. 8. USB Port: Connects the scanner to a USB port on your computer by the included USB cable.

  • Page 12: Chapter I. Installing The Scanner

    Chapter I. Installing the Scanner Before installing your scanner, please verify that you have all of the proper components. A list of the package contents is provided in the Box Contents section of this guide. Software Installation Requirements Your scanner comes with the scanner’s driver, and the image capture software (SecureScan).

  • Page 13: Installing And Setting Up The Scanner

    Installing and Setting up the Scanner Please follow the step-by-step procedures described below to install the scanner. X50 / X100 1. Plug the square end of the included USB cable to the USB port at the rear of the scanner. 2.
  • Page 14 X150 Please make sure the scanner is turned OFF before you plug or unplug the scanner power adapter. Attention 1. Plug the AC adapter into the scanner’s power receptor. 2. Plug the other end of the power cable into a standard AC power outlet. 3.

  • Page 15: Step 2. Installing The Software

    1. If the USB components on your computer are functioning correctly, they will automatically detect the scanner causing the Add New Hardware Wizard or Found New Hardware Wizard to be launched. If your computer is off when the scanner is connected, the “Add New Hardware Wizard”...

  • Page 16: Step 3. Testing The Scanner

    4. Follow the on-screen instructions to install all software that your new scanner requires. If the pop-up wizard window appears click Next, and click Install this driver software anyway in the Windows Security window then click Finish in the wizard window. 5.

  • Page 17: Uninstalling The Plustek Device Driver And Software

    Uninstalling the Plustek device driver and software To uninstall your existing Plustek driver and software, please follow the steps below: 1. From the Windows START menu, point to All Programs > Your Scanner Model Name , and the click Uninstall (Your Scanner Model Name) .

  • Page 18: Chapter Ii. Scanning Via Securescan Program

    Chapter II. Scanning via SecureScan Program SecureScan program is able to capture and verify relevant data of Size 1 Machine Readable Official Travel Documents (TD1), Size 2 Machine Readable Official Travel Documents (TD2), Size 3 Machine Readable Travel Documents (TD3), as well as visas. This program is capable of reading the Machine Readable Zone and Visual Zone data on the ICAO standard documents including international passports, standard size plastic ID cards, and driver licenses.
  • Page 19 When you’re scanning the passport, please gently press the passport binding to guarantee the minimum space between the to-be-scanned Information page and the scanner glass. 4. The scanner starts to scan immediately. After the scanning process is completed, the scanner will beep once and the scan indicator will blink once. The scanned image will display on the screen.

  • Page 20: Chapter Iii. Managing Via Securescan Manager Program

    Chapter III. Managing via SecureScan Manager Program The SecureScan Manager program is important software that comes with your scanner. This program allows you to view and search the scanned data. You can easily adjust settings to export and print the scanned data. Follow the steps described below: 1.
  • Page 21 5. Click the Setting button to configure settings. a. To modify the saving path in the Save to field, click the button to select the desired saving folder. b. Select the desired Format from the drop-down list. c. Select the desired Resolution from the drop-down list. d.
  • Page 22 have to enter the password again to confirm the delete action. 8. Select the desired data and click the Print button to print the selected data. 9. Click the Exit button to exit the SecureScan Manager program.

  • Page 23: Appendix A: Specifications

    Appendix A: Specifications Plustek SecureScan X50 Image Sensor CMOS Light Source White LED Optical Resolution 5 Megapixels Focus Fixed Scan Modes Color: 24-bit Input; 24-bit Output Approx. 1 second (Color Mode, Full Page passport image Scanning Speed capture) Scanning Area (W x L) Maximum: 127 x 95 mm (5"...
  • Page 24 Plustek SecureScan X100 Image Sensor CMOS Light Source White LED / IR LED Optical Resolution 5 Megapixels Focus Fixed Color: 24-bit Input; 24-bit Output Scan Modes IR: 24-bit Input; 8-bit Output Approx. 1 second (Color Mode, Full Page passport image...
  • Page 25 Plustek SecureScan X150 Image Sensor CMOS Light Source White LED / IR LED / UV LED Optical Resolution 5 Megapixels Focus Fixed Color: 24-bit Input; 24-bit Output Scan Modes IR: 24-bit Input; 8-bit Output UV: 24-bit Input; 24-bit Output Approx. 1 second (Color Mode, Full Page passport image...

  • Page 26: Appendix B: Customer Service And Warranty

    Appendix B: Customer Service and Warranty Visit our website www.plustek.com for more customer service information. For further assistance call our customer support phone number listed on the website. One of our representatives will be happy to assist you from Monday through Friday during...

  • Page 27: Statement Of Limited Warranty

    Statement of Limited Warranty This Statement of Limited Warranty applies only to the options you originally purchase for your use, and not for resale, from an authorized reseller. The manufacturer warranty includes all parts and labor, and is not valid without the receipt of original purchase.

  • Page 28: Fcc Radio Frequency Statement

    Some jurisdictions do not allow the exclusion or limitations of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This Limited Warranty gives you specific legal rights, and you may also have other rights that vary from jurisdiction to jurisdiction. FCC Radio Frequency Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
