eControls RT2 Homeowner And Installer Manual

Smart
C o n t r o l
The RT2 is a wireless whole house fan (WHF) control
that can be placed on a night table or used anywhere
in the home to control the Whole House Fan using
temperature control for improved comfort and energy
efficiency or a built-in 1 to 12-hour timer. The fan speed
can be set from the remote. The RT2 has a wireless
range of 125 feet in a home or building.
For more information on using the RT2, visit the
"eControls WHF Channel", RT2 Homeowner Video.
Displays the outdoor
temperature when an outdoor
temperature sensor is installed.
Displays the WHF speed.
Indicates the RT2 is linked to
the RM2 receiving module.
MENU Key accesses
user options such as
Temperature or Timer Control.
QUICK START FOR HOMEOWNERS
Before operating your Whole House Fan (WHF), always OPEN windows. See the WHF Owners manual for
more information. Your A/C should be off during WHF operation.
In the morning and/or before operating your A/C, make sure the RT2 control is set to Econo Cooling OFF.
If operating your A/C, make sure windows are closed.
Operating your WHF using Temperature Control (See pages 2 and 3 for more information).
The RT2 wireless WHF control is factory set to control your WHF using Temperature, just like your thermostat, and
improves your comfort and energy savings. Simply touch the Econo Cooling key to display ON, then set the Set To
temperature to your desired Indoor temperature. The WHF will turn ON when the Indoor temperature rises 1 above
the Set To temperature and turn OFF when the Indoor temperature drops 1 below the Set To temperature. The
following morning or when WHF operation is no longer desired, touch the Econo Cooling key to display OFF. As a
precaution, the RT2 control includes a built-in Safety Timer that will turn the WHF OFF after 8 hours of operation.
Operating your WHF using Timer Control (See pages 2 and 4 for selecting and using Timer Operation)
Homeowner and Installer Manual
Model RTK, Wireless WHF Control Kit
WHF
For 1, 2 or 3-Speed PSC or ECM Fans
Smart Smart
Outdoors Outdoors
Link Link ed ed
Menu Menu
WHF WHF
Smart Smart
Outdoors Outdoors
Indoors Indoors
o o
F F
Cool Cool
Link Link ed ed
Set To Set To
Econo Econo
Cooling Cooling
ON ON
Menu Menu
WHF WHF
Indoors Indoors
o o
F F
Displays the indoor temperature.
Use the Up/Down keys to change
Cool Cool
temperature setting or timer setting
in WHF cooling.
Set To Set To
Displays the temperature setting for
WHF cooling.
Econo Econo
Cooling Cooling
ON ON
Use this key to turn WHF cooling
On or Off.
Slide battery cover off to replace
the two AA batteries.
o
Rev D Apr 2019
Model RM2
WHF Radio Module
Laguna Hills, CA
eControlsUSA.com
Pat. Pending
Made in USA
