eControls WRDC User Manual

eControls
The WRDC Wireless Remote Damper Control eliminates
overheating, overcooling and conditioning unused spaces to
improve comfort and save energy.
Understanding Your WRDC Damper Control
Your installation includes a WRDC Wireless Remote Damper
Control and a wireless modulating R80DWL Damper that
controls the amount of heating or cooling airflow to a space.
The WRDC Remote wirelessly communicates to the R80DWL
Damper. Airflow can be adjusted from 100% (damper fully
open) to 0% (damper closed).
The WRDC Remote and the R80DWL Damper default to
Damper 01. If more than one damper is installed, you will
need to select the damper number before making
adjustments - See page 2, Selecting the Damper Number.
Eliminate Overheating or Overcooling
When the space is overheated or overcooled, simply lower
the airflow. The damper partially closes and reduces the
amount of heating or cooling to the space. By partially closing
the damper, more heating or cooling is redirected to other
spaces, improving comfort and saving energy.
Press and hold the
key to reduce the airflow
to the space. Start with a
10-20% adjustment.
Press the key to
ENTER
send the communication
to the damper.
Use the or key
to make additional
adjustments to airflow to
achieve your ideal
comfort level.
%
Dpr
LITE LITE
DMPR DMPR
ENTER ENTER
Model WRDC - User Manual
Wireless Remote Damper Control
Eliminate Conditioning Unoccupied Spaces
For unoccupied spaces, lower the airflow to a very low
setting. The damper closes and significantly reduces the
amount of heating or cooling to the space, saving energy. By
closing the damper, more heating or cooling is redirected to
other spaces.
Press and hold the
key to reduce the airflow
%
to the space. At 0% there
Dpr
will be minimal airflow to
the space.
Press the ENTER
send the communication
to the damper.
When the space is occupied, simply press the
increase the heating or cooling airflow to the space then
press the
%
Dpr
LITE
DMPR
ENTER
%
Dpr
key to
LITE
DMPR
ENTER
key.
ENTER
Jan 2025 Ver 1.00
(Damper is sold
separately)
%
Dpr
LITE
DMPR
ENTER
key to
