Cambridge Audio HDMI DVD 99 Service Manual

Issue Date: December 2007
© Copyright Audio Partnership 2007
SERVICE MANUAL

SPECIFICATIONS:

Disc Types:
Output:
Rear connections:
Video Systems:
D/A Converters:
Video Amplitude:
S-Video Output Amplitude:
Frequency Response:
Signal to Noise Ratio:
THD:
Max. Power Consumption:
Dimensions (W x D x H):
Weight:
Audio Partnership PLC; Gallery Court; Hankey Place; London; SE1 4BB; UK
Tel: +44 (0)207 940 2200 Fax: +44 (0)207 940 2233
DVD – Video, DVD – Audio, SACD, DVD +/-R/RW, CD/CD-R/CD-RW,
MPEG4/DivX, Compatible with digital photo albums
Video: DVI and HDMI support for HDTV with PAL/NTSC Progressive
Scan and Upscaling Component Video with 50Hz/60Hz Interlaced
Output; Scart (RGB/
Composite / 2 Channel Audio); S-Video; Composite Video, Audio: 5.1
Audio; Stereo Downmix, Digital: Digital Coaxial; Optical: DTS Digital via
Digital Outs
HDMI Output with HDCP, DVI Output, Component Video Out; S-Video
Out; RGB Scart Out; Composite Out; Optical Out; Coaxial Out; 5.1CH
out, USB In
Video resolution 480/576p,720/1080p, PAL or NTSC interlaced or non-
interlaced
(progressive scan)
D/A Converters: 24-bit, 192kHz
Video Amplitude 1.0Vp-p (75ø)
S-Video Output Amplitude: Y:1.0p-p (75ø), C:O.286Vp-p (75ø)
5Hz-30kHz (+/-3dB)
>100dB
0.003% (A weighted) @ 1kHz 0.01% (no weighting)
20 Watts
420 x 45 x 266 (mm)
27 x 1.8 x 10 (inches)
2.5kg/5.5 lbs
HDMI DVD 99
AP23252/1
