Name of Parts
Body / Transmitter
Battery
Compartment
Micro USB Port
(for firmware updates)
PC Sync Port
Hot Shoe Speedlite
Connection
LCD Panel
Hot Shoe Camera
Connection
4
TEST Trigger Button
AF Assist Beam
Switch
Power Switch
Status Indicator Lamp
CH/OK
Channel Setting
'OK' Button
GR
Group Setting Button
Select Dial
MODE
Mode Selection
Button
