  • Page 1 FO-350, FO-356 VGA AND STEREO AUDIO MATRIX/SPLITTER N Instruction manual FO-350 FO-356...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
  • Page 4: Controls And Functions Front Panel

    5.- OUTPUT ON: LED indicators that show which audio/video input is assigned to the corresponding output. Note: the front panel of model FO-350 is the same as that of FO-356 except that it only has 2 outputs. BACK PANEL FO-350 1.- DC INPUT: power connection for 5 V DC adapter.
  • Page 5: Remote Control

    14 assigns input 2 to output D, etc. Note: on the remote control for model FO-350 only buttons 1-4 are active: Buttons 1-2: for selecting the desired inputs for output A. Button 1 assigns input 1 to output A, button 2 assigns input 2 to output A, etc.
  • Page 6: Connection And Operating

    - Connect the VGA and stereo audio signal sources to the corresponding inputs on the matrix. - Then connect the VGA and stereo audio signal outputs to the screens, computer loudspeakers, etc. - With the FO-350, power the equipment using the AC/DC adapter connecting it to the 5 V DC input and the mains.
  • Page 7: Troubleshooting

    TROUBLE SHOOTING Check that the mains adapter is connected (model FO-350). The LED indicators do not light Check that the equipment is connected to the mains and the power switch is in the ON position (model FO-356). Make sure that the screen is on and the cables have been connected correctly.
  • Page 8: Declaration Of Conformity

    This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
