FONESTAR FO-522 Manual

FO-522
N
1 X 2 HDMI SPLITTER
CONTROLS AND FUNCTIONS
CONNECTION AND OPERATING
- Connect the HDMI source signal to the splitter INPUT.
- Connect the OUTPUTs to each of the monitors or to another splitter to make a connection in series and increase the number of
monitors or the signal distribution distance.
- Power the splitter using the mains adapter provided.
TECHNICAL SPECIFICATIONS
CHARACTERISTICS
INPUTS
OUTPUTS
INDICATORS
POWER SUPPLY
DIMENSIONS
DECLARATION OF CONFORMITY
FONESTAR SISTEMAS S.A.
Polígono de Trascueto s/n
39600 Revilla de Camargo, Cantabria (Spain)
Declares, under its responsibility, that the following equipment:
Description: 1 x 2 HDMI splitter
Brand: FONESTAR
Model: FO-522
complies with the European Community Directives 2004/108/CE on
Electromagnetic Compatibility, 2006/95/CE on Low Voltage and 2011/65/UE on
the restriction of certain dangerous substances in electrical and electronic
appliances (RoHS).
FONESTAR is a member of ECOEMBALAJES ESPAÑA, S.A. "ECOEMBES", with number 03497 and all our products carry the symbol, backed by our membership and subscription to the above
mentioned organization with the recycling and subsequent management of our packaging.
FONESTAR is registered in the RAEE (Registro de Aparatos Eléctricos y Electrónicos) in a special section REI (Registro de establecimientos Industriales), with the entry number 001851.
FONESTAR S.A. - NIF A28780443 - Polígono Trascueto - 39600 Revilla de Camargo, Cantabria (Spain)
www.fonestar.com
1.- Power input for mains adapter provided.
2.- INPUT: input for the signal to be distributed, HDMI connector.
3.- POWER: LED splitter power indicator.
4.- OUTPUT 1-2: LED output indicators: display the outputs which are connected.
5.- OUTPUT 1-2: outputs which have an identical signal to the input, HDMI connectors .
FO-522
1 X 2 HDMI amplifier splitter.
Compatible with Full HD 1080p, 3D.
Bandwidth 2'25 Gbps/225 MHz.
1 gold-plated female HDMI connector
2 gold-plated female HDMI connectors
LED power indicator
LED output indicator
5 V DC, 1 A maximum with adapter included
76 x 15 x 49 mm depth
Revilla de Camargo, 24th September, 2015
Juan Vallejo
Technical Engineer, Sales Department
This product has been tested and has passed the corresponding quality control prior to being put on the
market.
FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the
delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law 'La Ley
General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 Noviembre.
The lack of conformity in the first six months after purchase, due to a manufacturing defect, will be rectified
with no more than showing the proof of purchase. After six months FONESTAR reserves the right to demand
proof of the product being sold with that problem.
This warranty does not include damage produced by: inappropriate use or negligence, accidents, worn out
parts due to use, breakages, burns, spilt liquids or other substances, excessive humidity, battery deterioration
and internal manipulation of the device, the software or its components by unauthorized persons, and in
general any use that is unrelated to the nature and purpose of the product
If any service is needed during the warranty period because of lack of conformity, please contact the business
or distributor where the product was purchased in no more than 2 months after being conscious of the
problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them
to solve it.
To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with
no corrections or crossing out.
This document adds information, and never decreases the consumers' rights, which in all cases are protected
by the Spanish law 'La Ley General para la Defensa de los Consumidores y Usuarios, Real Decreto Legislativo
.
1/2007 16 Noviembre
.
WARRANTY
.
