  • Page 1 Underwater Network Camera Quick Start Guide...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Ultra-wide Panoramic Network Camera· Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 5 Ultra-wide Panoramic Network Camera· Quick Start Guide This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 6 Ultra-wide Panoramic Network Camera· Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings”...
  • Page 7 Ultra-wide Panoramic Network Camera· Quick Start Guide ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. ● Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 24 VAC or 12 VDC according to the IEC60950-1 standard.
  • Page 8 Ultra-wide Panoramic Network Camera· Quick Start Guide malfunction), and affect the endurance of sensor at the same time. ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam.
  • Page 9 Ultra-wide Panoramic Network Camera· Quick Start Guide responsibility for problems caused by unauthorized repair or maintenance.) White Light Use The white supplement light source of the camera is classified as Risk Group 2 (RG2). Possibly hazardous optical radiation emitted from this product. Do not stare at operating light source.

  • Page 10: Table Of Contents

    Ultra-wide Panoramic Network Camera· Quick Start Guide Table of Contents 1 Appearance Description ............... 10 Overview of Underwater Camera ........10 Cable Description ............11 2 Installation ..................12 2.1 Mounting Selection ............12 2.2 PT Joint Mounting ............14 3 Setting the Network Camera over the LAN ........

  • Page 11: Appearance Description

    Ultra-wide Panoramic Network Camera· Quick Start Guide 1 Appearance Description Overview of Underwater Camera Overview of the Camera Description of Overview Name Description White light supplement Underwater light supplement Lens Camera lens Installation plate Fix the camera on the base Stainless steel shell Water-proof camera shell...

  • Page 12: Cable Description

    Ultra-wide Panoramic Network Camera· Quick Start Guide Cable Description Disassemble of Camera Description of Overview Name Description Power cable 36V DC power cable Network cable RJ45 10M/100M Ethernet port...

  • Page 13: Installation

    Ultra-wide Panoramic Network Camera· Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 36V DC, please make sure your power supply matches with your camera.
  • Page 14 Ultra-wide Panoramic Network Camera· Quick Start Guide Pole Mounting: The pole mounting is applicable to the shallow water environment. Figure 2-1 Pole Mounting Tripod Mounting: The tripod mounting is applicable to the deep water environment. You can use a rope to place the camera and tripod in the water and secure it.

  • Page 15: Pt Joint Mounting

    Ultra-wide Panoramic Network Camera· Quick Start Guide PT Joint Mounting Steps: 1. Connect the cables and make sure the insulation performance of power cable. 2. Fix the camera base to the PT joint top with four 1/4 UNC screws. PT Joint Top Installation 3.
  • Page 16 Ultra-wide Panoramic Network Camera· Quick Start Guide Figure 2-4 PT Joint Bottom Installation 4. Fix the PT joint top with the PT joint bottom with three 1/4 UNC screws to secure the camera to the installation base. Figure 2-5 Fix the PT Joint 5.
  • Page 17 Ultra-wide Panoramic Network Camera· Quick Start Guide 2) Tighten the No. 2 adjusting screw. Tilting Range -45° 45° Tilt Adjusting Screw Tilt Adjusting Screw No. 1 No. 2 45° Pan Adjusting Screw Panning Range -45° 2-Axis Adjustment...

  • Page 18: Setting The Network Camera Over The Lan

    Ultra-wide Panoramic Network Camera· Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 19: Activating The Camera

    Ultra-wide Panoramic Network Camera· Quick Start Guide 3.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported.

  • Page 20: Activation Via Sadp Software

    Ultra-wide Panoramic Network Camera· Quick Start Guide Figure 3-3 Activation Interface(Web) Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 21 Ultra-wide Panoramic Network Camera· Quick Start Guide activate the camera, please refer to the User Manual of Network Camera for other two activation methods. Steps: 1. Run the SADP software to search the online devices. 2. Check the device status from the device list, and select the inactive device.

  • Page 22: Modifying The Ip Address

    Ultra-wide Panoramic Network Camera· Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 23 Ultra-wide Panoramic Network Camera· Quick Start Guide 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address 4.
  • Page 24 Ultra-wide Panoramic Network Camera· Quick Start Guide The batch IP address modification is supported by the SADP; please refer to the User Manual of SADP for details.

  • Page 25: Accessing Via Web Browser

    Ultra-wide Panoramic Network Camera· Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 26 Ultra-wide Panoramic Network Camera· Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
