Forza FR304GN Installation Manual

Hide thumbs Also See for FR304GN:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Use and Care Manual
INSTALLATION
MANUAL
GAS RANGE MODELS
FR304GN
FR366GN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR304GN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Forza FR304GN

Summary of Contents for Forza FR304GN

  • Page 1 INSTALLATION MANUAL GAS RANGE MODELS FR304GN FR366GN...

  • Page 2: Table Of Contents

    Congratulations on your recent Forza purchase! Before you begin using your new Forza product, please take a moment to review the Installation Manual. You will find the answers to all of your questions as well as some very important safety information.

  • Page 3: Safety Instructions

    Safety Instructions Pay attention to these symbols present in this manual: This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.” You can be killed or seriously injured if you don’t immediately follow instructions.
  • Page 4 If the information in this manual is not followed exactly, a fire or explosion may result in property damage, personal injury or death. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. What to do if you smell gas.
  • Page 5 FOR MASSACHUSETTS INSTALLATIONS: Installation must be performed by a qualified or licensed contractor, plumber or gas fitter qualified or licensed by the state, province or region where this appliance is being installed. Shut-off valve must be a “T” handle gas cock. Flexible gas connector must not be longer than 36”...

  • Page 6: Ventilation Requirements

    Ventilation Requirements Vent Hood Combinations: It is recommended that these ranges be installed in conjunction with a suitable overhead vent hood. Due to the high heat capacity of this unit, particular attention should be paid to the hood and ductwork installation to assure it meets local building codes.
  • Page 7 Electrical Supply The cord supplied with the gas ranges having an electric griddle requires a NEMA 5-15 receptacle. When the power supply cord is connected to the mating receptacle, the combined plug/receptacle connection should protrude no more than 1,55” (39,4 mm) from the rear wall. This product must be properly grounded.
  • Page 8 Product Dimensions 30” Range 36” Range...
  • Page 9 Cutout Requirements Figure 1 Model Range 30” (762mm) 6" (152mm) 9” (228mm) 6" (152mm) 6" (152mm) Range 36” (913mm) 6" (152mm) 12” (305mm) 9” (228mm) 6" (152mm) To eliminate the risk of burns or fire by reaching over heated surface units, cabinet storage space located above the surface units should be avoided.
  • Page 10 Figure 2 Choosing Range Location Carefully select the location where the range will be placed. The range should be located for convenient use in the kitchen, but away from strong drafts. Strong drafts may be caused by open doors or windows, or by heating and/or air conditioning vents or fans.

  • Page 11: Unpacking, Assembly And Moving Of The Range

    Unpacking, Assembly and Moving of the Range DO NOT lift the range by the oven door’s handle, as this may damage the door hinges and cause the door to fit incorrectly. DO NOT lift the appliance by the range’s control panel. The unit is heavy and should be handled accordingly.
  • Page 12 Unpacking the Range Remove the outer carton and packing materials from the shipping pallet but leave the adhesive-backed foam layer over brushed-metal surfaces, to protect finish from scratches, until the range is installed in its final position. CAUTION: Stand clear. The ends of the cut banding may snap toward you. It is recommended that the grates, griddle plate, burner caps and oven racks be removed to facilitate handling.
  • Page 13 Pull out the hand-truck, tilt the range laterally and insert the legs. After the electrical and gas connections (see both paragraphs for instructions) measure the four corners in cutout area to verify if flooring is level. Adjust the leveling legs to the desired height and ensure range is level. Turn the bottom section of each leg counter-clockwise to raise the leg and clock wise to lower it.

  • Page 14: Installing Anti-Tip Device

    Installing the Anti-Tip Device • A child or adult can tip the range and be killed. • Ensure the anti-tip bracket is engaged when the range is moved. • Do not operate range without anti-tip bracket in-stalled and engaged. Failure to follow these instructions can result in death or serious burns to children and adults. To verify the anti-tip bracket is installed and engaged: •...
  • Page 15 The anti-tip bracket should be inserted into the opening on the anti-tip brace on the range. RANGE SIDE DISTANCE OF X 30” Left or Right 3” (75.5 mm) 36” Left or Right 3” (75.5 mm)
  • Page 16 Tools You Will Need: For Concrete or Cement Construction: You must use appropriate fastening hardware (not provided). Materials Provided: Anti-Tip Bracket Brace and Screws Materials Required (Not Provided): Shut-off Valve Joint Sealant Pipe Fittings 5-foot maximum length, 5/8” O.D. CSA-approved flexible metal gas supply (3-foot maximum length: in Massachusetts only)

  • Page 17: Gas Requirements

    Gas Requirements QUALIFIED SERVICE MAN OR GAS APPLIANCE INSTALLER MUST MAKE THE GAS SUPPLY CONNECTION. High Altitude For altitudes above 2,000 feet (610 m) above sea level, adjustments can be made with the instructions in the manual. If flame performance is satisfactory, will not be required regulation. It is required that a Certified Professional make the high altitude adjustments during installation.
  • Page 18 Gas Connection OPEN POSITION A manual gas shut-off valve must be installed external to the appliance, in a location accessible from the front, for the purpose of shutting off the gas supply. The supply line must not interfere with the back of the unit. Make sure the gas supply is turned off at the manual shut-off valve before connecting the appliance.
  • Page 19 CAUTION: Do not attempt to attach the flexible connector directly to an external pipe thread. Connection requires flare union adapters. FOR ALTERNATIVE PIPING METHODS TO CONNECT THE APPLIANCE TO THE GAS SUPPLY, A TRAINED SERVICE TECHNICIAN OR GAS APPLIANCE INSTALLER MUST MAKE THE GAS SUPPLY CONNECTION. Leak testing of the appliance shall be conducted by the installer according to the instructions given.
  • Page 20 GAS REQUIREMENTS Natural Gas Supply Pressure 4” (10 mbar) Min. Line Pressure 5” (12.5 mbar) Max. Line Pressure 14" (34.9 mbar), .5 psi (3.5 kPa) GAS REQUIREMENTS LP Gas Supply Pressure 11" (27 mbar) Min. Line Pressure 12" (27.4 mbar) Max.

  • Page 21: Electrical Requirements

    Electrical Requirements This appliance must be supplied with the proper voltage and frequency and connected to an individual, properly grounded branch circuit, protected by a circuit breaker or fuse having amperage as noted on the rating plate. We recommend having the electrical wiring and hookup of your appliance connected by a qualified electrician.
  • Page 22 Plug Power Supply Cord • If cold water pipe is interrupted by plastic, non metallic gaskets, union connections or other insulating materials, DO NOT use for grounding. • DO NOT ground to a gas pipe. • DO NOT have a fuse in the NEUTRAL or GROUNDING circuit. A fuse in the NEUTRAL or GROUNDING circuit could result in an electrical shock.

  • Page 23: Leveling The Range

    Leveling the Range The top edges of the range’s side panels must be on the same or higher level as the adjacent countertop. If the range is operated while at a lower height relative to the adjacent cabinet, the cabinet could be exposed to excessive tempera- tures, causing damage to the cabinet and countertop.

  • Page 24: Test Rangetop Burners

    Fan each of the flames out and allow to reignite to verify burner reignition. If any burners do not carry over, call Forza. Repeat the Ignition and Flame Test procedures, described for each range top burner.

  • Page 25: Converting Appliance For Use With Lp Gas

    Converting Appliance for Use with LP Gas Conversion is to be performed by an AUTHORIZED SERVICER (or other qual- ified agency) in accordance with the manufacturer’s instructions and all codes and requirements of the authority having jurisdiction. Failure to follow instruc- tions could result in serious injury or property damage.
  • Page 26 Pressure Regulator Replace Injector On (Oven Lower Burner) 1) Remove the burner cover plate. 2) Remove the screws A securing the oven burner and withdraw the burner from the support. 3) Remove the injector by turning 9-32” nut driver counter clockwise. 4) Install the injectors supplied with this appliances in the appropriate burner.
  • Page 27 Replace Injector On (Oven Grill Burner) 1) Remove the door as described in the paragraph “Door removal”; 2) The range is equipped with two broiler burners. Remove the screws A securing the broiler burners and withdraw the burners from the support. 3) Remove the injector by turning 9-32”...

  • Page 28: Converting Appliance For Use With Natural Gas

    Converting Appliances for Use with Natural If this appliance should be converted for use with gas NG (natural gas), each of the following modifications must be performed. 1) Convert the pressure regulator to NG position as per the section “Pressure Regulator Conversion”. 2) Replace all injectors following the step described on the previous pages, observe the number stamped on the side, this number corresponds to the orifice diameter and its correct burner location (refer to the illustrations in section: “Injectors Position”).
  • Page 29 INJECTORS POSITION NATURAL GAS (NG) 30” Range – Cooktop Please note that the dual burner is equipped with two outer injectors with the same diameter; 30” Range – Oven...
  • Page 30 INJECTORS POSITION NATURAL GAS (NG) 36” Range – Cooktop Please note that the dual burner is equipped with two outer injectors with the same diameter; 36” Range – Oven...
  • Page 31 INJECTORS POSITION LP GAS 30” Range – Cooktop Please note that the dual burner is equipped with two outer injectors with the same diameter; 30” Range – Oven...
  • Page 32 INJECTORS POSITION LP GAS 36” Range – Cooktop Please note that the dual burner is equipped with two outer injectors with the same diameter; 36” Range – Oven...

  • Page 33: Low Flame Adjustment

    Low Flame Adjustment Lighting gas burners with a match is dangerous. You should match light the burners only in an emergency. Light a match and hold the flame near the burner you want to light. Wooden matches work best. Push in and turn the control knob slowly. Be sure you are turning the correct knob for the burner you are lighting.
  • Page 34 CONVERSION FROM NATURAL GAS TO LIQUID GAS Insert the screwdriver in the hole in the front wall of the instrument panel and turn regulation screw A clockwise. Proper adjustment will produce a stable, steady blue flame of minimum size. The final adjustment should be checked by turning the knob from high to low several times without extinguishing the flame. This adjustment, at low setting, will automatically provide the proper flame size at medium setting.
  • Page 35 ELECTRIC GAS IGNITION The gas burners use an electric ignition device located near each burner ensures burners ignite automatically. Lighting gas burners with a match is dangerous. You should match light the burners only in an emergency. Light a match and hold the flame near the burner you want to light.

  • Page 36: High-Altitude Adjustment Instructions

    High-Altitude Adjustment Instructions Valve adjustments must be completed by a qualified technician. Damage to the unit could occur. STEP 1 These instructions are used to adjust ranges and range tops for operation at high altitudes, if necessary. Important Information for the Installer: It is important that the following be completed BEFORE making adjustments to the appliance.
  • Page 37 Adjust the burner’s control valve to MIN to see that the flame continues to wrap around the burner. Blow out the flame, or use a quick fan motion from a writing tablet or piece of cardboard to extinguish the flame. Observe the burner’s ability to reig nite and wrap around (also called “carry-over”) the burner within several seconds.

  • Page 38: Technical Data

    Technical Data 30” Cooktop Features KNOB COOKTOP BURNER BURNER OUTPUT RATINGS: BURNER OUTPUT RATINGS: 30” MODEL BTU/HR NG (Natural Gas), 5” BTU/HR LP (Propane) Gas, 10” W.C.P. W.C.P. Burner Rear Left 12,000 btu/h 12,000 btu/h Burner Front Left 20,000 btu/h 20,000 btu/h Burner Front Right 20,000 btu/h...
  • Page 39 36” Cooktop Features KNOB COOKTOP BURNER BURNER OUTPUT RATINGS: BURNER OUTPUT RATINGS: 36” MODEL BTU/HR NG (Natural Gas), 5” BTU/HR LP (Propane) Gas, 10” W.C.P. W.C.P. Burner Rear Left 12,000 btu/h 12,000 btu/h Burner Front Left 20,000 btu/h 20,000 btu/h Burner Central Rront 20,000 btu/h 20,000 btu/h...

  • Page 40: Installer Checklist

    Installer Checklist Specified clearances maintained to cabinet surfaces. Unit Level – front to back – side to side. Burner caps positioned properly on burner bases. All packaging material removed. A Flush Island Trim attached according to instructions. Verify flame at each burner. Flame may need to burn for several minutes to remove impurities from the gas lines. Verify that the Min feature works and relights around the entire burner.
