i-limb
select
TM
Manual
Part number: MA 01155: Issue No. 4, January 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i-limb select and is the answer not in the manual?

Questions and answers

Related Manuals for touch bionics i-limb select

Summary of Contents for touch bionics i-limb select

  • Page 1 i-limb select Manual Part number: MA 01155: Issue No. 4, January 2015...
  • Page 2 This is an i-limb ultra that has been refurbished. This document provides instruction for prosthetists in the fitting and servicing of the i-limb select and should be read in full prior to fitting. It is highly recommended that the use of this manual is made in conjunction with instruction from a clinician experienced in upper limb and myo-electric prostheses.

  • Page 3: Table Of Contents

    Table of Contents 1. i-limb select Product Description Intended Use Prosthesis Overview Features catalogue 2. Socket Control Sites Socket Fabrication Charge Port Placement Assembly Battery Options Battery Configuration Battery Installation i-limb Power Pack Battery Charging 3. Wrist Wrist Connection Options...

  • Page 4: I-Limb Select

    Individually motorized digits and the unique biosim and my i-limb app used to control the i-limb select result in one of the most versatile prosthetic hand currently available to the global market. Users can choose from a wide selection of automated grips and gestures to help complete daily tasks.

  • Page 5: Part Number: Ma 01155 Issue No. 4, January

    Motorized Digit Knuckle Palmar Fairing Manual Thumb Rotator On / Off Switch 5 of 50 Part number: MA 01155 Issue No. 4, January 2015...
  • Page 6 1.4 Features Catalogue The i-limb select has 12 different grip options available. These grips can be accessed through biosim and the my i-limb app. This following Features Catalogue will review the various available grips and provide a functional description of each.
  • Page 7 Additional Grip and Gesture Options With these additional grip patterns and gestures, consider how often you perform different tasks and if having a program for that activity would make it easier/faster for you to perform. Since each digit has its own motor, you can put pressure against any digit to stop it from moving (called stalling the digit).

  • Page 8: Socket

    2.0 Socket 2.1 Control Sites Figure 1. Compact Electrode The i-limb select is controlled by compact electrodes (fig. 1). For information regarding the fitting of the Touch Bionics electrode, review the manual provided with the electrode. Electrode Site Selection The use of virtu-limb, the Touch Bionics’ myo-testing system, is recommended to determine the optimal placement of electrodes (fig.

  • Page 9: Figure

    (fig.3) where the battery and electrodes connect, to Figure 3. Coaxial Plug prevent loose connections . 2.2 Socket Fabrication While fabricating the socket for the i-limb select, special considerations will need to be given to: 1. Battery placement, size and configuration 2. Electrode position 3.
  • Page 10 Coupling Piece Assembly for QWD Wrist Insert the castelation ring (coupling piece) into lamination ring and turn until seated. Insert retaining ring around outside edge of coupling piece and use QWD release tool to seat the retain- ing ring. The QWD release tool is available to order from Touch Bionics.
  • Page 11 2.3 Charge Port Placement Assembly It is important to provide sufficient space for the charge port between the inner and outer sockets. The charge port should be positioned so that it is unaffected by forces running through the socket to prevent damage. Create a drill hole of 8mm through the inner surface of the prosthetic frame.

  • Page 12: Figure

    2.4 Battery Options i-limb 1,300 mAh Battery The i-limb select comes with a 1,300mAh battery. This battery has been specifically designed to meet the power Capacity 1,300 mAh requirements of the hand. Length 70mm (2.76”) Battery Dimensions Width 35mm (1.39”) Height 6mm (0.24”)
  • Page 13 2.5mm D.C. Socket Wiring Schematic for 1300mAh Low Profile Do not apply excessive force to the charger Battery with D.C. Socket socket interface during assembly. Co-axial Bush/Rotator A minimum of 2mm of free space surrounding the charger port should be provided. A flat surface is needed to secure the charger port to the socket interface frame.
  • Page 14 2.7 i-limb Power Pack Bottom of socket Top of socket i-limb Power Pack (ordered separately) are for users who want the ability to easily replace batteries. Battery housing is fabricated on top and bottom of socket, allowing for easy access. i-limb Power Pack kit Figure.
  • Page 15 Warnings and Precautions for additional information. If the patient intends to travel outside of their home country, they will need to ensure they have a Touch Bionics charger that will work in the country to which they are traveling. Additional chargers are available from Touch Bionics.

  • Page 16: Figure

    Power Pack Charger Figure. 16 i-limb Power Pack batteries for i-limb select should only be charged using the Touch Bionics battery charger (fig. 16) supplied. Place the batteries in the charger as illustrated. Insert the charger lead from the battery powerpack into the charge port.

  • Page 17: Wrist

    Connecting the i-limb select using the QWD Ensure the i-limb select is switched off. On/Off Switch Align the QWD connection of the i-limb select with the connection in the forarm socket. 17 of 50 Part number: MA 01155 Issue No. 4, January 2015...
  • Page 18 Test the connection is fully engaged with a slight rotation. Disconnecting the i-limb select using the Ensure the i-limb select is switched off. Support the i-limb select in the palm of the hand. 18 of 50 Part number: MA 01155 Issue No. 4, January 2015...
  • Page 19 3.3 Wrist Disarticulation The wrist disarticulation is fabricated directly into the socket frame and then attached to the i-limb select by the following steps: Disconnect the Palm Fairing from the i-limb select chassis by unscrewing the screw in the palmar surface using a T10 Screwdriver (available for order).
  • Page 20 Remove the Wrist Disarticulation and feed the power cable through. Align the slots and slide the Wrist Disarticulation plate onto the WD Lamination Plate at base of the i-limb select ensuring it is firmly engaged. Secure the Wrist Disarticulation plate to the WD Lamination Plate using a T10 screw and a T10 Screwdriver.
  • Page 21 Palm Fairing. Loosen the WD Lamination Plate Screw from the Wrist Disarticulation plate. Slide the Wrist Disarticulation off the base of the i-limb select. Separate the i-limb select from the Wrist Disarticulation, drawing the Basket cable through the Wrist Disarticulation.

  • Page 22: Adjustments

    2, 3, 5 and 6. Sizes 2 and 3 contain a small motor, while sizes 5 and 6 contain a a larger motor. The standard digit configuration Digit Small Medium of the small and medium sized i-limb select is outlined in the Thumb table. Index Middle 4.2 Digit Installation...
  • Page 23 4.3 Thumb Installation The i-limb select is only compatible with Touch Bionics i-limb select thumb digits. When exchanging a thumb, ensure the correct size has been selected. Instruments required: T10 Screwdriver provided by Touch Bionics.
  • Page 24 Disconnect the Palm Fairing using the T10 screwdriver to loosen the palmar T10 screw. Gently move the Palm Fairing to the ulnar side to allow access to the exposed T10 screw at the base of the thumb. Using the T10 Screwdriver access the screw from the medial to lateral direction to loosen.
  • Page 25 If there is resistance while tightening the screw check for cross threading by removing and re-inserting the screw. Touch Bionics recommends T10 Screwdriver for use with all T10 screws in the i-limb select. Do not reuse screws 25 of 50...

  • Page 26: Covers

    The i-limb select should not be used without an approved cover that is well maintained. The i-limb select can be used with both i-limb skin active and i-limb skin natural covers. These covers require regular checks for wear and tear. Covers will need occasional replacement depending on level of use.

  • Page 27: Biosim App Clinician Version

    6.1 biosim app overview Welcome to the mobile world of Touch Bionics! The biosim mobile application is provided for you to quickly and easily change the features of the i-limb select prosthesis while on the move. Important points to note: •...
  • Page 28 “settings” icon on the first screen. Next go to the App Store via the icon. Tap on it to start the app. To search for the biosim app, type “Touch Bionics” or “biosim” in the search tab and download the app to your iPod.
  • Page 29 Touch Bionics. Total update time may take up to 10 minutes. After tapping "Continue with After tapping "Yes" the update update" you will arrive at a final will begin.
  • Page 30 Connection Authorized User Access When hand is turned on and In order for you to connect to a ready to connect, the screen patient’s device, they will need will show this display to tell you their 4 digit serial number located proximal to Tap on the desired device the base of the thumb on the serial number to begin the...
  • Page 31 Editing favorites Editing favorites Tap here to change the name Tap an icon to choose one to associate with the favorite you are editing. Tap here to change the icon associated with the favorite. Tap here to change the features and triggers that will be sent to the hand when this favorite is activated from the favorite list.
  • Page 32 Save a new favorite Save a new favorite Tap an icon to choose one for Tap the text field to type in a the new favorite name for the new favorite Tap the Icon entry to choose an icon for the new favorite Save a new favorite Save a new favorite Switch to the favorites page by...
  • Page 33 Currently active Currently active features and triggers features and triggers Tap a feature icon to change Tap a trigger to change its its trigger association. association with the selected feature Tap the disclosure triangle to adjust the settings for a specific trigger Currently active Currently active...
  • Page 34 Currently active Other features features and triggers This page can be used to This is an example of the enable or disable the various features page after the changes global features of the hand. from the previous page. Notice the highlighted feature with the trigger name under it.
  • Page 35 Change control strategy The highlighted icon indicates the current control strategy. Tap the desired control strategy to change it. Real time graph The real time graph is best viewed in landscape mode by rotating the device horizontally.It will show the user’s input signals.
  • Page 36 Multilingual support About the App Choose which language This screen gives information should be used by the app. about the hand and the app. Choosing system default will Tap sign out to disconnect the make the app use whatever app from the PCP account you language the rest of the are currently logged into.

  • Page 37: My I-Limb Patient Version

    7.1 my i-limb Overview Welcome to the mobile world of Touch Bionics! The my i-limb mobile application is provided for you to quickly and easily change the features of the i-limb select prosthesis while on the move. Important points to note: •...
  • Page 38 Next go to the App Store via the icon. Tap on it to start the app. To search for the my i-limb app, type “Touch Bionics” or “my i-limb” in the search tab and download the app to your iPod.
  • Page 39 Touch Bionics. Total update time may take up to 10 minutes. After tapping "Continue with After tapping "Yes" the update update" you will arrive at a final will begin.
  • Page 40 When the hand is turned on Authorized User Access and is ready to connect the In order for someone else to screen will show this display. gain access to your device you will need to tell them your 5 Tap the desired device to digit security code.
  • Page 41 Editing favorites Editing favorites Tap the edit button at the top To change the name tap here right and the screen changes to look like the one seen here Tap here to change the icon to the right associated with the favorite. Tap to red symbol to delete Tap here to change the the favorite...
  • Page 42 Save a new favorite Save a new favorite Tap the text field to type in a To save a new favorite with the name for the new favorite currently active features and triggers, tap the + button. Tap the Icon entry to choose an icon for the new favorite Save a new favorite Save a new favorite...
  • Page 43 Currently active Currently active features and triggers features and triggers continued... The settings pages present the user with the currently Tap a feature icon to change active hand configuration. its trigger association Any changes made on the settings pages are sent to the hand and take effect immediately.
  • Page 44 Real time graph The real time graph will show the user’s input signals and is best viewed in landscape mode. It shows red for the open signal and blue for the close signal. Rotate the device to portrait mode or tap the Done button to exit the graph.

  • Page 45: Support Information

    Failure to comply with the above guidelines will invalidate the warranty. Failure to comply with the above guidelines will invalidate the warranty. If you experience technical problems with the i-limb select contact your local distributor 45 of 50 Part number: MA 01155 Issue No. 4, January 2015...
  • Page 46 Check the electrode cable is not damaged Check the battery cable is not damaged Check that the i-limb select is connected correctly to the wrist Contact your local distributor User complains that the Electrode settings may be too low...
  • Page 47 Touch Bionics is unable to provide definitive advice in respect to a patient with an i-limb device driving a motor vehicle.

  • Page 48: Appendix

    Hazardous Area Classification The i-limb select device is not intended for use outside the boundries of the environments listed below. The cus- tomer or user of the i-limb select device should assure that it it not used in such environments...

  • Page 49: Warranty

    (12) months from the date of Touch Bionics invoice for the i-limb select. This Limited Warranty applies only to an i-limb select provided by Touch Bionics or an affiliate authorized by Touch Bionics to provide the i-limb select. This Limited Warranty applies to all components including but not limited to fixtures, motors, bearings, and electronics.
  • Page 50 Manufacturer/Date of Manufacture European Conformity Customer Service/Contact Information: Touch Bionics, Unit 3 Ashwood Court, Oakbank Park Way, Livingston EH53 0TH , UK Tel: Customer Service: +44 (0) 1506 438 556 50 of 50 Part number: MA 01155 Issue No. 4, January 2015...
  • Page 51 For address details and further information please visit www.touchbionics.com Third party products and brand names may be trademarks or registered trademarks of their respective owners © Copyright 2015 Touch Bionics Inc. and Touch Bionics Limited. All rights reserved. MA 01155 Issue No. 4, January 2015...
