Summary of Contents for Bissell 1672 SERIES
- Page 1 Big Green ® D E E P C L E A N E R U S E R ’ S G U I D E 1672 SERIES Safety Instructions Product View Assembly 6-11 Operations / Special Tools Maintenance Troubleshooting Replacement Parts...
- Page 2 Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance. My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your Big Green.
-
Page 3: Grounding
Use only manufacturer’s recommended attachments Use only cleaning products formulated by BISSELL for use in this appliance. Keep openings free of dust, lint, hair, etc. Keep appliance on a level surface Turn off all controls before unplugging Unplug by grasping the plug, not the cord... -
Page 4: Overview
Large Vacuum Flex Hose Clips Vacuum Flex Hose Ball Cage Tank Unit Grip/Trigger Hose with Threaded Connectors Wand Solution Tube Top Power Unit Motor Filter Measuring Ball Tank Siphon Tube Casters Tip: Finger tighten threaded outlet connections. Do not over tight- en, or use pliers or tools to tighten. -
Page 5: How To Use This Guide
Locate and organize all parts before assembly. Familiarize yourself with the parts and where they fit. Following this User’s Guide will greatly enhance your ability to get the most performance from your BISSELL Big Green for many years. How To Put It Together Casters. - Page 6 How To Put It Together Continued Wand Solution Tube. Connect wand solution tube to spray tip on floor nozzle and to cap valve on grip/trigger unit. Small Wand Clips. Secure tube to wand with two small wand clips. Vacuum Flex Hose. Connect vacuum flex hose to grip/trigger unit and lock with latch buttons.
-
Page 7: Deep Cleaning Carpet
The Big Green is not recommended for cleaning wood floors. Use only Bissell ® Floor Care cleaning solution on no-wax floors. Never use Bissell ® Carpet Cleaner or other carpet cleaners on bare floors. Sweep before starting. Remove old wax before cleaning. -
Page 8: Pre-Treating
120° F/48° C) into filling cavity until level reaches bottom of three vertical lines in tank unit. Shake bottle of BISSELL Carpet Care. Fill measuring lid to fill line (10 ounces). Empty measuring lid into filling cavity and replace measuring lid. -
Page 9: Clean Upholstery/Small Areas
When You’re Done Turn off pump/spray and vacuum/suction switches. Unplug from outlet. Remove tank siphon tube, flip down carrying handle and lift top power unit from tank unit. Carry tank unit to a toilet or sink to empty. With carrying handle in one hand, place other hand in gripping slot under filling cavity on tank unit. - Page 10 Attach bare floor attachment to bottom of floor nozzle with rubber and brush strips facing out. Align front edges and snap together. Fill measuring lid twice with Bissell Floor Care and empty into filling cavity. Pour two gallons of hot tap water into filling cavity.
- Page 11 How To Dry Vacuum Attach one of four dry vacuuming tools. Insert tank siphon tube in tank unit. Turn on vacuum/suction switch. Vacuum as usual. Empty collection tank when it is half full. See PUTTING IT AWAY, page 12. How To Wet Vacuum Getting Ready Remove dry filter bag from ball cage.
-
Page 12: Putting It Away
Putting It Away After Deep Cleaning/Wet Vacuuming Rinse filling cavity with clean water. Leave about 1/2 gallon of clean water in filling cavity. Hold floor nozzle over bucket or sink. Turn on pump/spray switch, pull trigger for 30 seconds, and empty power unit. Empty filling cavity of excess water. -
Page 13: Troubleshooting
See PUTTING IT AWAY Step 8 (see page 12) Tighten loose connections Relax kinks in solution tubes/hoses Check electrical plug Pump/spray switch on? Call BISSELL Consumer Services ( see page 15) Finger tighten all connections (do not use pliers or other tools) -
Page 14: Parts List
BISSELL Replacement Parts Item Part No. Part Name 210-4706 Vacuum flex hose 555-9129 Large vacuum flex hose clips (3) 555-9013 Hose with threaded connectors 216-4181 Grip/trigger unit 210-1188 Dusting brush 010-9156 Crevice attachment 010-6055 Small vacuum nozzle 213-9152 Drain clean-out attachment... - Page 15 NOTE: Please keep your original sales receipt. It is your warranty. You may purchase replacement parts from your retailer, by using the order form in this User’s Guide, by calling BISSELL Consumer Services or by visiting our website. To locate a retailer near you, or to place an order using...
-
Page 16: About Your Warranty
User's Guide is not covered. If your BISSELL product should require service: Call BISSELL Consumer Services at the number below or visit the BISSELL website - www.bissell.com to locate a BISSELL Authorized Service Center in your area. If there are no authorized BISSELL Service Centers in your area, select the "Customer Service"...
