Bircher Reglomat PIR 22 Operating Instructions

PIR 22
Passive infrared motion detector

Operating instructions

1

Safety instructions

The device must only be operated at a protective low voltage with safe electrical
isolation. Interventions and repair work must only be performed by your supplier!
2

Design / Overview

8
7
4
5
3

Mounting (Accessories depending on type purchased)

Mounting bracked Swivel bracked
Attention: the connection terminal must in side close to door.
Refer to PIR 20, PIR 22 and AIR 20
Ceiling Mounting Frame Installation
Guide for detail.
Ceiling Mounting Frame
1 Potentiometer setting
sensitivity
2
2 Swivel bracket
3 Lens cover
1
4 Switch active/passive
5 LED, function
indicator red sensor
3
activated green sensor not
activated
6 Cover with Fresnel lens
7 Zoom scale
6
8 Zoom screw
Release connection terminal
Protective cover
4

Wiring diagrams

12-30 V DC
~
1
white
12-24 V AC
~
2 +
brown
3
green
48 V AC/DC
4
30 W/60 VA
yellow
5
gray
5

Switch

active
Active (normally open n.o.), relay is
activated if sensor system is active or
electronics output is conducting.
Setting sensitivity
I
6 5

Zoom ranges

Position 10
Position 0
Detection ranges with zoom setting only. The best optical values can be obtained
at position 0 – choose the smallest possible zoom range
mm
A
B
A
¢
Detection ranges with zoom setting and diaphragm
7

Technical data

Operating voltage
12–30 VDC
12–24 VAC
Power consumption
Temperature range
Maximum installation height
Maximum field size
Minimum detection speed
Output hold time
Protection class
Relay contact load:
– maximum switching current
– maximum contact voltage
– maximum switching capacity
Wiring diagram of relay
Wire diameter= 5 x 0.25 mm 2
passive
Passive (normally closed n.c.), relay is
activated if sensor system is passive or
electronics output is conducting.
Min. Max.
Max. = Maximum
Min. = Minimum
800
2000
1600 3400
B
300
500
800 1000
– 0%/+15%
– 0%/+15%
approximately 15 mA
– 40° C ... 60° C
48 VAC /48 VDC
30 W / 60 VA
mm
mm
A
B
4 m
3.4 x 1.6 m
0.1 m/s
0.5 s
lP 52
1 A
