IVFSD10X
DISHWASHER OPERATING
& INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IVFSD10X and is the answer not in the manual?

Questions and answers

Summary of Contents for ILVE IVFSD10X

  • Page 1 IVFSD10X DISHWASHER OPERATING & INSTALLATION MANUAL...
  • Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................1 1.3. During Use........................2 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Drain Hose........................6 2.5. Electrical Connection ....................7 2.6.
  • Page 4 8.CLEANING AND MAINTENANCE ................. 22 8.1. Cleaning the Machine and Filters ................22 8.2. Spray Arms ........................22 9.TROUBLESHOOTING ....................23 10.PRACTICAL INFORMATION ..................25 11.THE PRODUCT FICHE ....................26...
  • Page 5: Safety Instructions

    1. SAFETY INSTRUCTIONS 1.1. General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed.
  • Page 6: Installation Warnings

    1.2. Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Your machine must only be installed by an authorised service agent. Installation by anyone other than an authorised agent may cause your warranty to be void.
  • Page 7 • it for other purposes. Commercial use will void the guarantee. Do not stand, sit or place loads on the open door of the dishwasher. Only use detergents and rinse aids produced specifically for dishwashers. Our company is not responsible for any damage that may occur due to misuse.
  • Page 8 be performed by an authorised service company, otherwise the warranty will be void. Before repair work, the machine should be disconnected from the mains. Do not pull the cable to unplug the machine. Switch off the water tap. Operation at a low voltage will cause a decline in performance levels.
  • Page 9 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
  • Page 10: Installation

    2. INSTALLATION new hose before connecting. 2.1. Machine positioning WARNING: Connect the hose directly to the water inlet tap. The pressure When positioning the machine, place it in supplied by the tap should be a minimum an area where dishes can be easily loaded of 0.03 MPa and a maximum of 1 MPa.
  • Page 11: Electrical Connection

    WARNING: After removing the top panel of your dishwasher, the machine should be placed in a space of the dimensions shown in the figure below. 2.5. Electrical connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection.
  • Page 12: Technical Specifications

    3. TECHNICAL SPECIFICATIONS 3.2. Technical specifications 15 place Capacity settings Dimensions (mm) Height 850(mm) Width 598(mm) Depth 598(mm) Net weight 62 kg Operating 220-240V voltage / 50 Hz, frequency 3.1. General appearance Total current 1. Worktop 10(A) 2. Upper basket with racks 3.
  • Page 13: Before Using The Appliance

    4. BEFORE USING THE APPLIANCE 4.1. Preparing your Dishwasher for first use • Make sure the electricity and supply water specifications match the values indicated in the installation instructions for the machine. • Remove all packaging material inside the machine. •...
  • Page 14: Water Hardness Table

    4.4. Water Hardness Table French British Level German dH Indicator L1 is shown on the display. 6-11 10-20 7-14 L2 is shown on the display. 12-17 21-30 15-21 L3 is shown on the display. 18-22 31-40 22-28 L4 is shown on the display. 23-31 41-55 29-39...
  • Page 15: Filling The Detergent

    4.8. Filling the detergent Push the latch to open the dispenser and In order to change the rinse aid level, pour in the detergent. follow the below steps before turning on the machine: Close the lid and press it until it locks in place.
  • Page 16 SOFT TOUCH Upper Basket Top basket The upper basket includes a mechanism Height Adjustable Rack which enables the height of the basket to be adjusted up (1) or down (2) without having These racks are designed to increase the to remove the basket. Hold the basket on capacity of the top basket.
  • Page 17 Four Folding Racks basket, after washing. (15 pc) The folding racks allow easier placement of larger items, such as pots and pans. Each section can be folded separately. The racks can be raised up, or folded down, as shown in the images. The upper cutlery basket is composed of two pieces that can be separately removed.
  • Page 18 5)Multi-functional Rack System The multi-functional rack system is located in the lower basket. It can be used for the placement of mugs or large utensils for washing. To close the racks, fold them from position (a) to position (b). Make sure the clips on the rack fit on the wire (c).
  • Page 19: Alternative Basket Loads

    5.2. Alternative Basket Loads Lower Basket Top basket Incorrect loads EN - 1...
  • Page 20: Programme Table

    4. PROGRAMME TABLE Duration Programme Description (min) Prewash To rinse heavily soiled dishes before a wash programme. Fast programme intended for recently used dishes which are lightly soiled. Mini 14’ Suitable for 4 place settings. Quick 30’ Quick wash programme for lightly soiled dishes. Standard programme for dishes which are used daily but are not heavily soiled.
  • Page 21: The Control Panel

    7. THE CONTROL PANEL a- Washing Cycle symbol b- Rinse Cycle symbol c- Drying Cycle symbol d- End Cycle symbol 7.1. Starting the Machine and Selecting a Programme Press the Power On/Off button (1). Select the programme most suitable for your dishes using the Up and Down Selection buttons (6, 7).
  • Page 22 to add extra drying steps to a programme in order to obtain drier dishes. The Extra Drying Indicator (13) will illuminate. 4. Press the Start/Pause button (5) to start the selected programme. The display will show ‘Program Activated’. 5. The display (21) will show the symbols corresponding to the status of the programme in operation.
  • Page 23: Adding Functions To A Programme

    Press the Confirmation button (2) to activate the additional function indicator (8, 9, 10, 11, 12, 13). Press the Start/Pause button (5) to start the selected programme. ‘Programme Activated’ will appear on the display. “-“ Function cannot be selected. “ ”...
  • Page 24: Cancelling A Programme

    Activated’ will show on the display. English Greek Turkish Croatian -The new programme will resume the French Russian course of the old programme. Deutsch Finnish Italian Norwegian 7.3. Cancelling a Programme Follow the steps below to cancel a programme while in operation. Polish Nederlands - Press and hold the Start/Pause button (5)
  • Page 25 ‘YES’ or ‘NO’. Select an option for ‘X’ and the time by 1 hour while the Down press the Confirmation button again to Selection button (7) decreases the time save your selection. If the factory settings by 1 hour. are restored, the machine will return to the following settings: Press the Start/Pause button to start the delay timer.
  • Page 26 Make sure the hydrant is closed Call a qualified technician if this is not the case. If an error occurs that you cannot fix, the warning shown below will be displayed. Call a qualified technician if this is the case. Call Service You can find more information in the “FAILURE CODES AND WHAT TO DO”...
  • Page 27: Cleaning And Maintenance

    8. CLEANING AND the filters. Replace the filter insert, and MAINTENANCE rotate it clockwise (4). • Never use your Dishwasher without a Cleaning your Dishwasher is important filter. to maintain the machine’s service life. • Incorrect fitting of the filter will reduce Oil and lime may build up in your the washing effectiveness.
  • Page 28: Troubleshooting

    9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 29 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
  • Page 30: Practical Information

    AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing Separate the inlet hose from the tap and clean the filter of Insufficient water the hose.
  • Page 31 Post: Locked Bag 3000, Annandale, N.S.W 2038 deterioration of parts and accessories and glass P: 1300 MY ILVE (694 583) breakage); (b) use for purpose for which the ILVE product was not WARRANTY REGISTRATION sold or designed; Your ongoing satisfaction with your ILVE product is (c) use or installation which is not in accordance with important to us.
  • Page 32 Mobile: Purchase Date: (Please attach proof of purchase to validate warranty) SERIAL NUMBER MODEL NUMBER (if you cannot locate the serial number please call ILVE on 1300 85 64 11) ILVE Warranty 01.06.2016 WITH TEAR OFF.indd 2 3/1/17 11:03 am...
