Dishwasher Operating
& Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IVSIX6 and is the answer not in the manual?

Questions and answers

Related Manuals for ILVE IVSIX6

Summary of Contents for ILVE IVSIX6

  • Page 1 Dishwasher Operating & Installation Manual...
  • Page 2 For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Open the door, press the On/Off button to switch on the appliance. Compartment A: For each wash cycle. Compartment B: Fill the detergent dispenser For programs with pre-wash only.

  • Page 3: Table Of Contents

    Dear Customer, Control Panel............2 This appliance is intended to be used in household Dishwasher Features...........2 and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; A. Rinse Aid Dispenser........-by clients in hotels, motels and other residential B.
  • Page 4 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. the risk of an electric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.

  • Page 5: Control Panel

    To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Inten . Heav y Normal 90 mi n Glass Rapid Soak Delay time, washing time, Remaining time, or error 1.On/Off Button: To turn on/off the power supply. codes indicator: 2.Delay Button: Press the button to delay the washing Rinse Aid indicator:...

  • Page 6: Rinse Aid Dispenser

    Before using your dishwasher for the first time: Rinse aid dispenser Detergent Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
  • Page 7 Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser set on "4". If spots and poor drying are a problem, increase the amount of rinse aid dispensed by removing the dispenser lid and rotating the dial to "5". If the dishes still are not drying properly or are showing spots, adjust the dial to the next higher lever until your dishes are spot-free.

  • Page 8: Amount Of Detergent To Use

    Amount of Detergent to Use If the lid is closed: press release button. The lid will spring open. Always add the detergent just before starting each wash cycle. Only use branded detergent and rinse aid for dishwasher. Dishwasher detergent is corrosive! Take care to keep it out of reach of children. Proper Use of Detergent Use only detergent specifically made for the use in dishwashers.

  • Page 9: Attention Before Or After Loading The Dishwasher Baskets

    Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low a temperature as possible. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the programme has ended.

  • Page 10: The Method Of Loading Normal Dishware

    The upper basket is designed to hold more delicate We suggest that you place large items and the most and lighter dishware such as glasses, coffee and difficult to clean items are to be placed into the lower tea cups and saucers, as well as plates, small bowls basket: such as pots, pans, lids, serving dishes and and shallow pans (as long as they are not too dirty).

  • Page 11: Wash Cycle Table

    Means: need to fill rinse into the Rinse-Aid Dispenser. Means: need to fill rinse into the Rinse-Aid Dispenser. ℃ Pre-wash(50 ) ℃ Wash (65 Intensive For heaviest soiled crockery, 5/28.75g Rinse and soiled pots, pans, 1.45 17.0 Rinse (Or All dishes etc with dried ℃...

  • Page 12: Change The Programme

    A cycle that is underway can only be modified if it has only been running for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water. If this is the case, the detergent dispenser must be refilled (see the section entitled " Loading the Detergent "...

  • Page 13: Filtering System

    The filter prevents larger remnants of food or other objects from getting inside the pump. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter(Fine filter). Main filter Food and soil particles trapped in this filter are pulverized by a special jet on the lower spray arm and washed down to drain.

  • Page 14: Cleaning The Filter

    Remarks: - Inspect the filters for blocking after every time the dishwasher has been used. - By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water. The entire filter assembly should be cleaned once a week. Cleaning the Filter To clean the coarse filter and the fine filter, use a cleaning brush.

  • Page 15: Installation Preparation

    After Every Wash When not in Use for a LongTime It is recommend that you run a wash cycle with the After every wash, turn off the water supply to the dishwasher empty and then remove the plug from the appliance and leave the door slightly open so that socket, turn off the water supply and leave the door of moisture and odours are not trapped inside.

  • Page 16: Aesthetic Panel's Dimensions And Installation

    Please carefully read the installation instruction. ● Illustrations of cabinet dimensions and installation position of the dishwasher Preparations should be made before moving the dishwasher to the installation place. Choose a place near the sink to facilitate the installation of inlet and drain hoses (see figure 1).
  • Page 17 2 magical paster A and magical paster B be disjoinedon ,magical paster A on the aesthetic wooden panel and felted magical paster B of the outer door of dishwasher(see figure 4a). After positioning of the panel , fix the panel onto the outer door by screws and bolts(See figure 4b) 【...

  • Page 18: Tension Adjustment Of The Door Spring

    ● Tension adjustment of the door spring The door springs are set at the factory to the proper tension for the outer door. If aesthetic wooden panel are installed, you will have to adjust the door spring tension. Rotate the adjusting screw to drive the adjustor to strain or relax the steel cable (see figure 5).

  • Page 19: Dishwasher Installation Steps

    Dishwasher installation steps 1 Install the furniture door to the outer door of the dishwasher using the brackets provided. Refer to the template for positioning of the brackets. 2 Adjust the tension of the door springs by using an Allen key turning in a clockwise motion to tighten the left and right door springs.

  • Page 20: About Electricity Connecting

    Dishwasher must be level for proper dish rack operation and wash performance. Place a spirit level on door and rack track inside the tub as shown to check that the dishwasher is level. level the dishwasher by adjusting the three levelling legs individually. When level the dishwasher, please pay attention not to let the dishwasher tip over.

  • Page 21: Water Connection

    please close the hydrant after using.(For the models: no safety inlet hose.) Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear.

  • Page 22: Error Codes

    Fuse blown, or the home Replace fuse or reset circuit breaker. Remove any other circuit breaker has been appliances sharing the same circuit with the dishwasher triggered. Make sure the dishwasher is turned on and the door is Power supply is not closed securely.
  • Page 23 The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed.
  • Page 24 Height : 815mm Width : 598 mm Depth : 570mm with the door closed Water pressure: 0.04-1.0MPa Power supply: see rating label Capacity: 15 place settings...
  • Page 26 ILVE Dishwasher Installation and Operating Instructions template pages.indd 2 1/05/2015 9:16 am...
  • Page 27 OPEN 24 ILVE ACCESSORIES ONLINE SHOP For a wide range of coffee machines, pods, and other ILVE accessories at the click of a button shop.ilve.com.au ILVE Dishwasher Installation and Operating Instructions template pages.indd 3 1/05/2015 9:16 am...
  • Page 28 Warranty Registration Card and return installation; it to us so that we have a record of the ILVE (d) use or operation after a defect has occurred or product purchased by you, Alternitivley, you can been discovered;...
  • Page 29 Act or other statute. (d) The liability of ILVE to you for a breach of any 01052015 express or non-excludable implied term, condition or warranty is limited at the option of ILVE to:...
  • Page 30 (Please attach proof of purchase to validate warranty) SERIAL NUMBER MODEL NUMBER (if you cannot locate the serial number please call ILVE on 1300 85 64 11) 01052015 ILVE Dishwasher Installation and Operating Instructions template pages.indd 6 1/05/2015 9:16 am...
  • Page 31 NOTES ILVE.COM.AU 01052015 You can now find us on: facebook.com/ILVEappliances twitter.com/ILVE_appliances youtube.com/ILVEappliances livewithilve.com ILVE Dishwasher Installation and Operating Instructions template pages.indd 7 1/05/2015 9:16 am...
  • Page 32 Australia National Telephone Number 1300 MYILVE (694 583) New Zealand Telephone Number 0508 458 369 ILVE showrooms are open daily from 9am-5pm and Saturdays 10am-4pm (WA by appointment only on Saturdays) ilve.com.au NSW & ACT (Head Office) VIC, TAS & SA WA &...
