Summary of Contents for ILVE IVDFI645-D
- Page 1 Dishwasher Operating & Installation Manual ILVE Dishwasher Installation and Operating Instructions template pages.indd 1 1/05/2015 9:16 am...
-
Page 2: Table Of Contents
Dear Customer, Please carefully reading it before using the dishwasher will help you to use and maintain the dishwasher properly. Keep it to refer to at a later date. Control Panel...........2 Pass it on to any subsequent owner of the appliance. Dishwasher Features........ - Page 3 When using your dishwasher, follow the precautions listed below: This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in a risk of electric shock. the risk of electric shock by providing a path of Check with a qualified electrician or service least resistance of electric current.
- Page 4 To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Power on light: To come on when Power ON/OFF Rinse Aid Warning Light : To be on when the button is pressed down. rinse aid dispenser needs to be refilled.
-
Page 5: Rinse Aid Dispenser
Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes. That can leave spots and streaks. It also improves drying by allowing water to sheet off the dishes. Your dishwasher is designed to use liquid rinse aids. -
Page 6: Detergent
Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser set on "4". If spots and poor drying are problems, increase the amount of rinse aid dispensed by removing the dispenser lid and rotating the dial to "5". If the dishes still are not drying properly or showing spotted, adjust the dial to the next higher number until your dishes are spot-free. -
Page 7: Detergent Dispenser
Detergent Dispenser The dispenser must be refilled before the start of each wash cycle following the instructions provided in the Wash Cycle Table . Your dishwasher uses less detergent and rinse aid then conventional dishwasher. Generally, only one tablespoon of detergent is needed for a normal wash load. - Page 8 Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind of dishes'. If necessary, seek further information from detergent manufacturers. For particular items, select a programme with as low a temperature. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the programme has ended.
-
Page 9: Cutlery Basket
Position the dishes and cookware so that they will not get moved by the spray of water. Cups Saucers Dessert dishes Glasses Dinner plates Soup plates Cutlery basket Plate racks of Basket The basket is fitted with plate racks which can be stowed horizontal if required. - Page 10 Cutlery should be placed in the cutlery basket with handles at the bottom. If the rack has side baskets, the spoon should be loaded individually into the appropriate slots, especially long utensils should be placed in the horizontal position at the front of the upper basket as shown. 3 3 3 Soup spoons 2 Forks...
-
Page 11: When Load Bigger Dinner Plates
Plate racks of Basket When load bigger Dinner plates, please fold the rack to left picture showed location. The maximum plate can be loaded is 270mm(10 inches) diameter. Position the dishes and cookware so that they will not get moved by the spray of water. Cups Large serving bowl Saucers... - Page 12 Means: need to fill rinse into the Rinse-Aid Dispenser. AS/NZS 2007. 1 AS/NZS 2007. 1 : This program is the test cycle, the rinse-aid dispenser setting is recommended to Position 6. ℃ Pre-wash 50 ℃ For heaviest soiled crockery, Wash (70 、...
-
Page 13: Unloading The Dishwasher
You can modify the washing program, When the dishwasher just runs for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water. If this is the case, the detergent dispenser must be refilled (see the section entitled"... -
Page 14: Filter Assembly
The filter prevent larger remnants of food or other objects from getting inside the pump. The filter system consists of a coarse filter, a flat (Main filter) and a micro filter (fine filter). Main filter Food and soil particles trapped by this filter are pulverized by a special jet on the spray arm and washed down to drain. -
Page 15: Cleaning The Filter
Remarks: - Inspect the filters for blocking every time the dishwasher has been used. - By unscrewing the coarse filter.you can remove the filter system.Remove any food remnants and clean the filters under running water. The entire filter assembly should be cleaned once a week. Cleaning The Filter To clean the coarse filter and the fine filter, use a cleaning brush. - Page 16 Cleaning the Spray Arms The spray arms can be easily removed for periodic cleaning of the nozzles, to prevent possible clogging. Wash them under running water and carefully replace them in their seats, checking that their rotary movement is in no way impeded. Grasp the middle of the spray arm, pull it upwards to remove it.
- Page 17 Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned to the right or the left to facilitate proper installation. For personal safety: DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
- Page 18 Insert the drain hose into a drain pipe with a minimum diameter of 4cm, or let it run into the sink, making sure to avoid bending or crimping it. Use the spe ial plastic support that comes with the appliance. The free end of the hose must be at a height lower than 75cm and must not be immersed in water to avoid the back flow of it.
-
Page 19: Water Outlet
How to Drain Excess Water From Hoses If the sink is 1000mm higher from the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink. -
Page 20: Technical Problems
Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker triggered. appliances sharing the same circuit with the dishwasher Power supply is not Make sure the dishwasher is turned on and the door is turned on. closed securely. -
Page 21: Wash Cycle Table
The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. The programme was Select a more intensive programme. not powerful enough. See" Wash Cycle Table . " Not enough detergent Use more detergent, or change your detergent. was dispensed. - Page 22 The dimensions with * variable “ ” according to actual situation ater pressure: 0.04-1.0MPa Power supply: See rating label Capacity: 6 place settings...
- Page 23 Electrical, drain and water supply line entrances, both sides Space of cabinet Step 1a: If only the body into cabinets, please make this map the size of the cabinet hole.
- Page 24 Electrical, drain and water supply line entrances, both sides. Space of cabinet ： Step1b If the entire decorative panel into the cabinet also, the size of a should be equal to D +3.5 + E +6; size b should be equal to C +6; Meanwhile, the cabinet around the inward booster: the bottom of the entire plane for the E-49 +3;...
- Page 25 decorative panel (up) decorative panel (down) ： Step 2 Weight of the decorative panel (up) should be min 3Kg-max 4Kg. Dim.A and B could be alterable by handle, Dim.C,D,E and F could be alterable by fact, ′ If you want to make the decorative panels size same as front of the machine, please use the minimum size in brackets;...
- Page 26 Step 3: Assemble the decorative panels If the m achine with a decorative plate, no this step. Step 4: Assemble the decorative door on the dishwasher, as figure. First install sidepiece screw between base board and decorative panel (down),in all 4; then pull glide from out door groove ,case 8-screw between decorative panels...
- Page 27 Step Install the dishwasher in aperture, but not full, as figure, adjust screw, ’ let its bottom align aperture s base, then push dishwasher full. Step ： Take out cap, a hole revealing , using screwdriver install screw, bothsides. Then recover the cap in hole.
- Page 28 ILVE Dishwasher Installation and Operating Instructions template pages.indd 2 1/05/2015 9:16 am...
- Page 29 OPEN 24 ILVE ACCESSORIES ONLINE SHOP For a wide range of coffee machines, pods, and other ILVE accessories at the click of a button shop.ilve.com.au ILVE Dishwasher Installation and Operating Instructions template pages.indd 3 1/05/2015 9:16 am...
- Page 30 Warranty Registration Card and return installation; it to us so that we have a record of the ILVE (d) use or operation after a defect has occurred or product purchased by you, Alternitivley, you can been discovered;...
- Page 31 Act or other statute. (d) The liability of ILVE to you for a breach of any 01052015 express or non-excludable implied term, condition or warranty is limited at the option of ILVE to:...
- Page 32 (Please attach proof of purchase to validate warranty) SERIAL NUMBER MODEL NUMBER (if you cannot locate the serial number please call ILVE on 1300 85 64 11) 01052015 ILVE Dishwasher Installation and Operating Instructions template pages.indd 6 1/05/2015 9:16 am...
- Page 33 NOTES ILVE.COM.AU 01052015 You can now find us on: facebook.com/ILVEappliances twitter.com/ILVE_appliances youtube.com/ILVEappliances livewithilve.com ILVE Dishwasher Installation and Operating Instructions template pages.indd 7 1/05/2015 9:16 am...
- Page 34 Australia National Telephone Number 1300 MYILVE (694 583) New Zealand Telephone Number 0508 458 369 ILVE showrooms are open daily from 9am-5pm and Saturdays 10am-4pm (WA by appointment only on Saturdays) ilve.com.au NSW & ACT (Head Office) VIC, TAS & SA WA &...
