SyxthSense SDC-TS7+ Product Sheet

SDC-TS7+Tablet Interface for
Niagara and Sedona Framework
Devices
The SDC-TS7+ is 7" tablet PC for visualising plant information
from BMS controllers using a web-browser interface application.
The tablet is connected via Ethernet to the controllers. The device
is equipped with a powerful processor for high speed
performance. The 7 inch capacitive touchscreen provides easy
access to plant monitoring
Features
• 7" Capacitive Touchscreen (1024x600 pixels)
• 100-240VAC to 12VDC Mains Adapter Included (UK Plug)
• Ethernet RJ45 Connectivity
• USB Stick Support (software upgrades)
• Animated Colour Graphics for HVAC Systems
• Auto-Boot Web-Browser
• Android OS
Model Type
Technical Data
Power Supply
Display and Audio
Processor, Memory and System
Connections
Environmental Conditions
Online store: www.syxthsense.com
Enquiries: T: 0844 840 3100 F: 0844 840 3200
TM
Model
SDC-TS7plus
Power supply
Display
Video
Audio
Processor
RAM
Nand Flash
Operating System
Boot Up
Ethernet
USB
HDMI
Operating
Temperature
Humidity
Degree of Protection
Description
Tablet PC User Interface for Sedona and Niagara
TM
Framework Products
100-240Vac (Mains adapter with UK Plug Supplied)
7 Inch IPS Display, Resolution:1024 x 600, Brightness: 350
cd/m2
H.264 2160p video decoding. Multi-format FHD video
decoding, including Mpeg1/2, Mpeg4 SP/ASP GMC, H.263,
H.264, VP6/8, AVS jizun, Jpeg/Mjpeg,etc.
H.264 High Profile 1080p@30fps or 720@60fps encoding
3840 x 1080@30fps 3D decoding, BD/SBS/TAB/FP supported
Complies with RTSP, HTTP, HLS, RTMP, MMS streaming
media protocols
Two Speakers 2 X 1 Watt (Integrated 3W Amplifier For
External Speakers)
Allwinner's A20 ARM Dual-Core Cortex A7 CPU, 1.2Ghz
1GB
4GB
Android 4.2.2.
Auto Boot Up When Power is Applied
RJ45
USB Connector
HDMI Output
0°C...+40°C
0...95%rh (non-cond.)
IP30
Product sheet CT2.137
SDC-TS7+
Type
PS CT2.137 2.02 - 1/6
