Front Panel Controls
and LCD
Continuous or pulsed ultrasonics
Time, energy, and temperature control modes.
Program a Pulse Temp and a Max Temp
to enable True Temperature Control
Fully programmable pulsing, in time or energy (joules)
Experiment progress indicator
Process monitoring
Press and hold the Test key to turn on sonics.
Press the Microtip key when using a microtip
probe. This limits amplitude to 70%, thus
preventing damage to the probe.
Test Key
Microtip Key
Sonifier
Quickstart Guide
®
Sonifier
Navigation Keys
Press the Up key or Enter key to initiate a change to
the current settings, then use the Up, Down, Left,
and Right keys to adjust values.
Press the Left and Right keys to select control
modes, to move horizontally between digits, and
to move between different result screens.
Press the Enter key to accept control setting changes.
Preset Key
Press the Preset key to select a memory location to
save the current sample-processing program, or to
recall stored settings.
ESC Key
Press the ESC key to return to the ready screen when
modifying control settings.
Pause Key
Press the Pause key to pause an ultrasonic cycle. Press
the Pause key again to resume current cycle.
Start/Stop Key
Press the Start/Stop key to turn ultrasonics on/off.
Reset Key
Press the Reset key to reset errors and alarms.
®
