SIMATIC Ident
RFID systems
Wide-range power supply unit for SIMATIC RF systems
Compact Operating Instructions
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage to property. The
notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices referring only to property damage
have no safety alert symbol. These notices shown below are graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be used. A notice warning of
injury to persons with a safety alert symbol may also include a warning relating to property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific task in accordance with
the relevant documentation, in particular its warning notices and safety instructions. Qualified personnel are those who, based on their
training and experience, are capable of identifying risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products
and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage,
installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any
problems. The permissible ambient conditions must be complied with. The information in the relevant documentation must be observed.
© Siemens AG 2006 - 2015. All rights reserved
J31069-D0169-U001-A5-7618, 07/2016
1
Advertisement
Table of Contents
Related Manuals for Siemens SIMATIC Ident
Summary of Contents for Siemens SIMATIC Ident
-
Page 1: Legal Information
WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 2: Scope Of Supply
EU standards for CE conformity. Furthermore, the US version has been UL-certified for the US and Canada. Table 1-1 Wide-range power supply unit for SIMATIC RF systems Characteristics Area of application Voltage supply for Siemens Ident de- vices Degree of protection IP67 Mechanically and electrically rug- Design features •... -
Page 3: Safety Information
Table 3-2 Ordering data accessories for the wide-range power supply unit for SIMATIC RF systems Article number 24 VDC connecting cable 6GT2891-0NH50 for SIMATIC RF600 readers RF620R/RF630R/RF640R/RF670R 24 VDC connecting cable 6GT2891-0PH50 for SIMATIC RF600 readers RF650R/RF680R/RF685R 24 VDC connecting cable 6GT2491-1HH50 for readers of the SIMATIC product family MOBY D 24 VDC connecting cable... - Page 4 NOTICE Restriction to the approval of the wide-range power supply Alterations to the SIMATIC RFID modules and devices as well as the use of SIMATIC RFID components with third-party RFID devices are not permitted. Failure to observe this requirement shall constitute a revocation of the radio equipment approvals, CE approval and manufacturer's warranty.
- Page 5 Grounding connection Hexagon-head screw (M5) Flat washer Cable lug Contact washer: To make ground contact, use contact washers accord- ing to the Siemens standard: SN 70093-6-FStflNnnc- 480h, Siemens item no.: H70093-A60-Z3 Wide-range power supply unit for SIMATIC RF systems J31069-D0169-U001-A5-7618, 07/2016...
- Page 6 Degree of protection The wide-range power supply unit for SIMATIC RF systems meets degree of protection IP67. ● Dust-tight: No ingress of dust ● Protected against harm from temporary submersion in water: Water must not enter in amounts that can cause damage, if the housing is immersed in water 1 m deep for 30 minutes.
-
Page 7: Technical Specifications
Technical specifications Table 7-1 Technical specifications 6GT2898-0ACx0 Product type designation Wide-range power supply unit for SIMATIC RF systems Electrical data Insulation strength (prim./sec.) U AC 3.3 kV isol p/s Primary- secondary side are galvanically isolated Insulation resistance R > 1 GΩ Leakage current I <... - Page 8 6GT2898-0ACx0 Noise immunity • EN 61000-6-2 / EN 61000-4-2 Contact discharge: 4 kV (air discharge): 8 kV Burst • EN 61000-6-2 / EN 61 000-4-4 Symmetrical: 2 kV Asymmetrical: 2 kV Surge • EN 61000-6-5 / EN 61 000-4-5 Symmetrical: 1 kV asymmetrical 2 kV HF field •...
-
Page 9: Dimension Drawing
6GT2898-0ACx0 Overload behavior P Constant current over Short-circuit protection/ Continuous/no-load stability No-load response Derating 2 % / K at T > +50 °C ... +70 °C Connector type M12, 4-pin two sockets Table 7-2 Output configurations Input Outputs ILoad = I1 + I2 Efficiency (%) Remarks U1 = U2... -
Page 10: Certificates And Approvals
Certificates and approvals Table 9-1 Approvals for wide-range power supply unit for SIMATIC RF systems (Europe, UK): 6GT2898-0AC00, 6GT2898-0AC10 Marking Description CE approval acc. to 2004/108/EG - EMC • 2006/95/EG - Voltage directive • Radio approval for Russia, Belarus, Kazakhstan Table 9-2 Approvals for wide-range power supply unit for SIMATIC RF systems (USA): 6GT2898-0AC20 Marking... - Page 11 Trademarks All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
