Summary of Contents for Montarbo FiveO P6AM
- Page 1 P6AM FIVE CHANNEL FX MIXER EN OWNER’S MANUAL...
-
Page 2: Introduction
P6AM INTRODUCTION First of all, thank you for choosing a product FiveO Montarbo . The P6AM have been designed to provide a cost effective ® high grade solution while maintaining high quality cabinet construction and optimum components. The P6AM, depending on the model, can be used for all types of applications including, but not limited to, churches, conference centers and discos. -
Page 3: Table Of Contents
CONTENTS Introduction Features Contents Important Safety Instructions Description Control Element Control Element - Rear Panel Control Element - USB Player Connection Diagram Frequency Response Diagram Block Diagram Effects List Wire Connections Technical Specifications PACKAGE CONTENTS P6AM - Code 5O01346 P6AM Owner’s manual Warranty certificate P6AM | Owner’s manual... -
Page 4: Important Safety Instructions
P6AM IMPORTANT SAFETY INSTRUCTIONS CAUTION Describes precautions that should be observed to prevent damage to the product. 1. Read this manual carefully before operation. TO REDUCE THE RISK OF ELECTRIC SHOCK PLEASE DO NOT REMOVE THE COVER OR THE BACK PANEL OF THIS EQUIPMENT. 2. - Page 5 IMPORTANT SAFETY INSTRUCTIONS According to OSHA, an exposure to high SPL in excess WARNING of this limits may result in the loss of heat. To avoid the TO REDUCE THE RISK OF ELECTRIC SHOCK AND FIRE, potential damage of heat, it is recommended that person- DO NOT EXPOSE THIS EQUIPMENT TO MOISTURE OR RAIN.
-
Page 6: Description
P6AM DESCRIPTION CONTROL ELEMENT THE MONO INPUT CHANNELS These are marked CH1 to CH4 and include a balanced COMBO socket (MIC IN). Use the COMBO socket to connect a low impedance balanced dynamic microphone or a low level signal. You can also connect a condenser microphone into the COMBO socket. PHANTOM POWER SWITCH When the (2) switch is at ON position, a +15V phantom power will be applied to CH1 through CH4. - Page 7 DSP/FX-AUX This control is used to adjust the level of respective channel signal sent to the Aux Bus. The configuration is post- fader so the signal sent to AUX Bus will be affected by the LEVEL control of that particular channel. In this typical compact unit, the channel signal is not only assigned to external effect or processor equipment directly but also to internal digital multieffect.
-
Page 8: Control Element - Rear Panel
P6AM CONTROL ELEMENT MONITOR Via this Control, you can adjust the signal Level applied to MONITOR OUT sockets. POWER LED This LED will blink when your P6AM is switched ON. PRESETS Adjust this knob to select the desired effect. AUX/DFX RET This control is used to adjust the level of the signal coming from internal multi-effect. -
Page 9: Control Element - Usb Player
CONTROL ELEMENT USB PLAYER Insert a standard microSD card. Insert USB drive. Aux Input. Play the last song or decrease the volume after pressing 2 seconds. Press this key to start playing or Press this key to pause. Play the next song or increase the volume after pressing 2 seconds. PLAY MODE In the opening or playing state, press this key to select the three circling modes in order: Line: The player plays the files you input. -
Page 10: Connection Diagram
P6AM CONNECTION DIAGRAM HEADPHONE iPOD - CD PLAYER - MP3 LAPTOP COMPUTER TAPE RECORDER This will be typical setting for a Business Presentation making use of Power Point slides and background music/effects generated by CD player, iPOD or other sources such as Mp3 Players. The Presenter has up to 2 micro-phones available and a wireless microphone can also be connected for the use of the audience. -
Page 11: Frequency Response Diagram
FREQUENCY RESPONSE DIAGRAM P6AM | Owner’s manual... -
Page 12: Block Diagram
P6AM BLOCK DIAGRAM Owner’s manual | P6AM... -
Page 13: Effects List
EFFECTS LIST LETTER EFFECT DESCRIPTION Chorus/room 1 Chorus with reverb for guitars, synths, and pianos. Chorus/room 2 Auto-wah guitar effect with reverb for lead instruments. Room Hardwood studio for acoustic instruments. Flange Stereo flanger for jet wash effects. Rotary Rotary speaker emulation for organs and guitars. Vocal Cancel Removes lead vocals from many stereo recordings. -
Page 14: Wire Connections
P6AM WIRE CONNECTIONS Either the 1/4” TRS phone jack or XLR connector can be wired in balanced and unbalanced modes, which will be determined by the actual application status, please wire your system as the following wiring examples: For 1/4” Phone jack Ring Ring Sleeve... -
Page 15: Technical Specifications
TECHNICAL SPECIFICATIONS System Type 2-Way 6.5” Vented Active Speaker Cabinet Power Handling RMS-70Watts Program-140Watts Frequency Response 75 Hz - 20 kHz (-6dB) Sensitivity 110 dB Max Low Frequency 6.5” (165 mm) woofer/1” Voice Coil High Frequency 1” Neodymium Tweeter X-over Frequency 2.4 KHz @ 12dB/oct 2-band equalizer on input channels 5 Input channels with individual volume control... - Page 16 This manual cannot cover all the possible contingencies which may arise during the product installation and use. Should further information be desired, please contact us or our local distributor. Elettronica Montarbo srl can not be considered responsible for damages which may be caused to people and things when using this product.
