- Page 1 W14A W17A bi-amped, active speaker systems...
- Page 2 Per evitare il rischio di incendio e/o folgorazione, non aprirlo. Per qualsiasi intervento di manutenzione o riparazione, rivolgersi alla Elettronica Montarbo srl e/o a personale altamente qualificato specificamente segnalato da questa. - Nel predisporre l'apparecchio all'utilizzo, assicurarsi che la forma e la portata della superficie di appoggio siano idonee a sostenerlo.
- Page 3 F Tubi di accordo. alluminio, centratore in kapton, diaframma in titanio). G Maniglie laterali per il trasporto. B W14A: woofer da 12" con magnete al neodimio. H Pannello controlli e connessioni. W17A: woofer da 15" con magnete al neodimio. Adattatore per asta di supporto.
- Page 4 W14 A 2 - WAY PROCESSOR CONTROLLED Volume frequenze alte (H.F.LEVEL) ACTIVE SPEAKER SYSTEM Montarbo N.B: se utilizzate un mixer Montarbo, o 2 - WAY PROCESSOR CONTROLLED W14A MADE IN ITALY MOD. comunque un mixer avente livello di uscita...
- Page 5 XLR bilanciati. caloriferi o qualsiasi altro oggetto che produca calore). Se il mixer ha uscite sbilanciate XLR e non è Montarbo, • Evitate di esporre la cassa alla radiazione solare è bene accertarsi che le uscite XLR del mixer siano sbilancia- diretta, ad eccessive vibrazioni e ad urti violenti.
-
Page 6: Table Of Contents
To prevent fire and/or electrical shock, never remove its cover. For maintenance and servicing always refer to the official Montarbo Distributor in your State or to qualified personnel specifically authorised by the Distributor. - Before placing the product on a surface of any kind, make sure that its shape and load rating safely match the product size and weight. -
Page 7: Introduction
60° x 40°) with 1,4" dynamic driver (featuring aluminum F Tuning ports. flat wire voice coil, kapton former, titanium dome). G Transport handles B W14A: 12" neodymium magnet woofer. H Control and connection panel W17A: 15" neodymium magnet woofer. Speaker stand adaptor. -
Page 8: Control And Connection Panel
W14 A High frequencies level control 2 - WAY PROCESSOR CONTROLLED ACTIVE SPEAKER SYSTEM (H.F. LEVEL) Montarbo 2 - WAY PROCESSOR CONTROLLED Note: if you are using a Montarbo mixer (or W14A MADE IN ITALY MOD. 600 W POWER Elettronica... -
Page 9: Important
(each speaker is designed to support up to two SHIELDED cables. other speakers). Connect the first W14A / W17A’s LINK OUT to the second’s LINK IN, the second’s LINK OUT to the third LINK IN, and so 5 - Always make sure that the truss structure intended to support the speakers is sturdy enough to hold their weight, even under stressful, adverse conditions. -
Page 10: Appendix
W14A / W17A active, processor controlled, bi-amped speaker systems APPENDIX Specifications __________________________________________ Parallel connection __________________________________________ __________________________________________ Connectors __________________________________________ Installation examples __________________________________________ Spare parts __________________________________________ Block diagram __________________________________________ APPENDIX... -
Page 11: Specifications
Technical specifications W14A W17A Speaker system 2-way bass reflex 2-way bass reflex • Components: custom designed to Montarbo specifications custom designed to Montarbo specifications - bass frequencies 12"high efficiency, neodymium magnet woofer 15"high efficiency, neodymium magnet woofer Nominal diameter 12"... -
Page 12: Connectors
W14A / W17A active, processor controlled, bi-amped speaker systems Connectors (W14A & W17A) INPUT LINK H.F. MASTER LEVEL LEVEL BALANCED FEMALE AND MALE XLR SOCKETS XLR - BAL. 1 = GND 2 = HOT (+) 3 = COLD (-) 0,775V RMS... -
Page 13: Installation Examples
W14A / W17A active, processor controlled, bi-amped speaker systems Installation examples stackable: flyable: pole mountable: as floor monitor: APPENDIX... -
Page 14: Spare Parts
W14A / W17A active, processor controlled, bi-amped speaker systems Spare parts D100W17 2-way filter A300216 1,4” driver for W14A D00W17J PCW17J: inputs + preamp. A300215 1,4” driver for W17A D100W17R PCW17T: amplifier chassis D100W17F PCW17F: power amplifier A088674 transport handle... - Page 15 Elettronica Montarbo srl no puede ser conside- La Elettronica Montarbo srl non può essere Elettronica Montarbo srl ne peut être rada responsable de daños que puedan ser ritenuta responsabile per danni o incidenti a consideré...
