How to Set Up Your JSA7500 Appliance
Overview
Juniper Secure Analytics 7500 (JSA7500) is an enterprise and carrier-class appliance that provides a scalable network security
management solution for large, globally deployed organizations.
JSA7500 can be deployed as a console or as a distributed event or flow processor. It can also be deployed as a store-and-forward
event collector.
The JSA7500 appliance has a 2-U, rack-mountable chassis redundant DC power supplies (optional AC power supplies),
twenty-eight hot-swappable hard drives in a RAID10 array, 128 GB of memory, and four Gigabit Ethernet interfaces.
Front Panel
Table 1: JSA7500 Front Panel Ports
Callout
1
2
3
4
5
6
Description
ESD wrist strap grounding jack
Hard drives
Power LED
Hardware disk activity LED
Fault LED
Front bezel with air filter
Advertisement
Related Manuals for Juniper Secure Analytics 7500
Summary of Contents for Juniper Secure Analytics 7500
-
Page 1: Front Panel
How to Set Up Your JSA7500 Appliance Overview Juniper Secure Analytics 7500 (JSA7500) is an enterprise and carrier-class appliance that provides a scalable network security management solution for large, globally deployed organizations. JSA7500 can be deployed as a console or as a distributed event or flow processor. It can also be deployed as a store-and-forward event collector. -
Page 2: Jsa7500 With Fan
The JSA7500 has internal hot-swappable cooling fans. See the above illustration for details on the fan location in JSA7500. Back Panel Table 2: JSA7500 Back Panel Ports Callout Description Hard drive Network port 0 Network port 1 Network port 2 IOC expansion slots Network port 3 USB ports Copyright © 2018, Juniper Networks, Inc. -
Page 3: Hardware Specifications
Browser Requirements - You must have Internet Explorer 8.0 or 9.0 or Firefox 10.0. WARNING: Before performing the installation and configuration procedures in this document, see the safety instructions and important regulatory information in the JSA Installation Guide and the JSA Hardware Installation Guide. Copyright © 2018, Juniper Networks, Inc. - Page 4 Be sure to set Connect Using to the appropriate COM port of the serial connector and Bits per second to 9600. You must also set (1), (8), and (None). Stop Bits Data bits Parity Copyright © 2018, Juniper Networks, Inc.
- Page 5 Manual— Allows you to manually input the date and time. Select Next Server— Allows you to specify your time server. Select Next Select your time zone continent or area, and then select Next Select your time zone region, and then select Next Copyright © 2018, Juniper Networks, Inc.
-
Page 6: Step 7: Finish Installation
Verify the appliance configuration settings: Open your Web browser. Log in to JSA with the username admin and the password <root password>. <root password> is the new root password that you set during the configuration process. Copyright © 2018, Juniper Networks, Inc. -
