Specifications
General
Power requirements
Power consumption
Dimensions (approx.)
Mass (approx.)
Operating temperature
Operating humidity
Signal system
DVD Section
Laser system
Frequency response
Signal-to-noise ratio
Harmonic distortion
Dynamic range
Inputs
ANTENNA IN
VIDEO IN
AUDIO IN
FM ANTENNA IN
AM ANTENNA IN
OPTICAL IN
Outputs
VIDEO OUT
S VIDEO OUT
COMPONENT VIDEO OUT
Audio output (analog audio)
ANTENNA OUT
VIDEO Section
Head system
Tape speed
Tape width
Maximum recording time
Rewind time
Channel coverage
Frequency range
Signal-to-noise ratio
Dynamic range
Channel separation
FM Tuner
Tuning Range
Intermediate Frequency
AM Tuner
Tuning Range
Intermediate Frequency
46
(AVD-K600P)
AC 120V, 60 Hz
74W
430 x 97 x 386 mm (17 x 3
6.3 kg (13.15 lbs)
5˚C to 35˚C (41˚F to 95˚F)
5 % to 90 %
NTSC
Semiconductor laser, wavelength 650 nm
DVD (PCM 48 kHz): 8 Hz to 22 kHz, CD: 8 Hz to 20 kHz
More than 80 dB (AUDIO OUT jacks)
Less than 0.3%
More than 85 dB (AUDIO OUT jacks)
Antenna or CATV input, 75 ohms
1 Vp-p 75 ohms, sync negative, RCA jack x 1
-6.0 dBm more than 47 kohms, RCA jack (L, R) x 1
FM antenna input, 300 ohms
AM antenna input, 300 ohms
Optical connector x 1
1 Vp-p 75 ohms, sync negative
(Y) 1.0 V (p-p), 75 ohms, negative sync, Mini DIN 4-pin x 1
(C) 0.286 V (p-p) 75 ohms
(Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(P
/C
)/(P
B
B
2.0 Vrms (1 KHz, 0 dB), 330 ohms, RCA jack (L, R) x 1
Channel 3 or 4 (Switchable)
4 heads helical scan azimuth system
Timer
12-hour display type with AM, PM
SP: 33.35 mm/sec, EP: 11.12 mm/sec
12.7 mm
SP: 2 HOURS (T-120), EP: 6 HOURS (T-120)/8 HOURS (T-160)
About 150 seconds (T-120)
Antenna
75 ohms (VHF/UHF)
VHF: 2-13, UHF: 14-69, CATV: 1-125 (4A, A-W, W+1 - W+84, A-5 - A-1)
20Hz to 20kHz
More than 43dB
More than 85 dB (AUDIO OUT jacks)
More than 55 dB (AUDIO OUT jacks)
87.5 - 108.0 MHz
10.7 MHz
530 - 1,720 kHz
450 kHz
/
x 15
7
8
/C
) 0.7 V (p-p), 75 ohms, RCA jack x 2
R
R
/
inches) (W x H x D)
1
4
