CLINK II SCU MANAGER
Table 18: Functions of digital inputs
Digital Input Function
DI_3 None
Isolator
DI_4
Contactor K1
Contactor K2
DI_5
Manual Stop
DI_6 Manual Start 1
Manual Start 2
DI_7
Manual Acknowledge
External Protection
Tray In Test
External Interlock
Digital Input Invert
It is possible to invert a digital input via LCU-5. Select:
5.4

Outputs

5.4.1

Digital outputs

The Starter Control Unit has 8 digital outputs (DO_0 to DO_7). The functions of the first three outputs (DO_0
to DO_2) are fixed and the functions of the other outputs (DO_3 to DO_7) are configurable. See table 19.
Digital Output Function
DO_0 Auxiliary Relay K10
DO_1 Auxiliary Relay K11
DO_2 Auxiliary Relay K12
DO_3 See table 20
DO_4 See table 20
DO_5 See table 20
DO_6 See table 20
DO_7 See table 20
Configurable digital outputs
The digital outputs DO_3 to DO_7 can be assigned via LCU-5 to the functions listed in table 20. Select:
Manager - Unit Properties - tab Dig. Output
functional description scu
Parameter type
Setpoint
Table 19: Functions of digital outputs
.
SCU Manager - Unit Properties - tab Dig. Input
For information see
5.6 on page 32
5.6 on page 32
5.6 on page 32
version 5.0
.
SCU
26
