CLINK II SCU MANAGER
8

TECHNICAL SPECIFICATIONS SCU

8.1

Technical specifications main board and interface board

Component
(C)FCU main board
Interface board
Item
Power supply
Ambient temperature
Relative Humidity
Vibration (operating)
Vibration (non-operating)
8.2

SCU print

The Starter Control Unit is a microprocessor controlled system provided with digital and analog I/O functions
and a serial bus for communication with DeviceNet.
The hardware is distributed over two prints:
• Main board
• Interface board
In order to comply with the EMC requirements (IEC 1000-4), the main board is designed as a 4 layer multi-layer
(Printed Circuit Boards). All inputs and outputs are adequately high-frequency decoupled against interference
signals. A combination of SMD components and conventional components is used for the main board.
The interface board includes varistors for the DeviceNet buses.
8.3

Connections

8.3.1

Connectors on the front of the SCU

Reserved for future development.
technical specifications scu
Table 61: Type and part numbers
Holec Partnumber
(with CFCU functionality)
1307222
1307221
Table 62: Environmental conditions
operating
storage
Holec Partnumber
(without CFCU functionality)
1307200
1307201
Specification
24 - 30
0 to 55
-5 to 70
0 to 95
1.0
1.0
version 5.0
Unit
V /100 mA
0
C
% Note: non-condens-
ing
G
G
