Chicago Faucets 116.859.AB.1 Manual

ELECTRONIC-DC FAUCETS
116.859.AB.1
Electronic Faucets
Product Type
___________________________________________________
Deck Mounted Single Hole HyTronic Curve Sink Faucet with
Dual Beam Infrared Sensor
Features & Specifications
___________________________________________________
• Single Hole
• Curve Electronic Integral Spout
• Vandal Proof Non-Aerating Laminar Flow Stream Solidifier
• Single Supply for Tempered Water
• 6 Volt Lithium CRP2 Battery (Included)
• Stainless Steel Hoses Included
• 1.5 GPM (5.7 L/min) Laminar Flow Control Insert in Spout
Inlet
• Multiple Field Adjustable Modes and Ranges
• Geberit Commander™ Software Compatible
• ECAST® design provides durable brass construction with
total lead content equal to or less than 0.25% by weighted
average
Performance Specification
___________________________________________________
• Rated Operating Pressure: 20-125 PSI
• Rated Operating Temperature: 40-140ºF
Warranty
___________________________________________________
• Lifetime Limited Faucet Warranty
• 1-Year Limited Finish Warranty
• 5-Year Limited Mechanical Warranty
• 3-Year Limited Electronics and Solenoid Warranty
Codes & Standards
___________________________________________________
• ASME A112.18.1/CSA B125.1
• Certified to NSF/ANSI 61, Section 9 by CSA
• California Health and Safety Code 116875 (AB1953-2006)
• Vermont Bill S.152
• NSF/ANSI 372 Low Lead Content
• ADA ANSI/ICC A117.1
• CALGreen
Last Revision: 07/19/2012 • Date Printed: 07/12/2013 • Product specifications subject to change without notice
Job Name ________________________________________________
Item Number _____________________________________________
Section/Tag ______________________________________________
Model Specified ___________________________________________
Architect _________________________________________________
Engineer _________________________________________________
Contractor ________________________________________________
[ ] Submitted as Shown
Date _____________________________________________________
ECAST products are intended for installation where state laws and local
codes mandate lead content levels or in any location where lead content
is a concern.
[ ] Submitted with Variations
2100 South Clearwater Drive
Des Plaines, IL
P: 847/803-5000
F: 847/803-5454
Technical: 800/TEC-TRUE
www.chicagofaucets.com
