Whirlpool FT M10 71Y EU Quick Manual

Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register

CONTROL PANEL

ON/OFF button (Reset if long pressed)
1
Programme selection Knob
2
Start/Pause
3
Options Buttons*
Dryness Level
4
Timed Drying
5
Start Delay
6
Rapid
7
Fresh Care+ (Key lock if long pressed)
8
Cycle End
9
INDICATORS
Dryness Level:
Iron Dry -
Cycle phase:
Drying -
Empty Water tank - Clean Door filter:
Refer to Troubleshooting section:
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is fixed correctly,
either to the dryer's water tank, or to your domestic sewage
system.
The dryer should be installed in environment in a room
temperature range of 20°to 23°C for optimum performance. But
will function if the room is between 14 and 30°C. Before you use
your dryer ensure that it has been in a upright position for at
least 6 hours.

DAILY USE

Doing this will keep your machine working at its BEST!
Remember to empty your water tank after each drying cycle.
Remember to clean your filters after each drying cycle. (Refer
to section Care & Maintanence).
1. Open the door and load garments. Always refer to instructions
on clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door filter.
2. Close the door.
3. Press the button On/Off.
4. Select the programme according to the laundry type.
5. Select the options, if necessary.
6. To start the cycle, press the Start/Pause button.
7. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Pull the load out
immediately to prevent the formation of creases on laundry
8. Turn the machine off by pressing the button On/Off, open the
door and pull clothing out. If the machine is not switched off
manually, after about a quarter of an hour from the cycle end, the
appliance turns off automatically to save energy.
If this last stage is not carried out immediately, some machines
You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:
and/or some programmes/options are equipped with Crease Care
• Visiting our website -
system. For some hours, after the end of drying, the drum rotates
• Using QR Code
at regular intervals to prevent the formation of creases. In case of
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
power failure, it is necessary to press the button Start/Pause to
contacting our After-sales Service, please state the codes provided on your product's identifi cation plate.
restart the cycle.
OPENING OF THE DOOR DURING THE CYCLE
During operation, it is possible to open the door. After having
closed it, press the button Start/Pause again to restart the dryer.
2
2
Hanger Dry - Cupboard Dry -
Cool Down - End of cycle
primary,
Failure: Call after sales service
docs.whirlpool.eu
Before using the appliance carefully read the Safety Instructions. Before using the appliance carefully read the Safety Instructions.
*Note: some models may have the wording in full instead of the icons
Extra Dry
secondary Autoclean
Demo Mode
DEMO
PROGRAMS
Eco Cotton
Standard cotton programme, suitable to dry normally wet cotton
laundry. Most efficient programme in terms of energy consumption
for drying cotton laundry. The values on the Energy Label are based on
this programme.
Mixed
This programme is ideal for drying cotton and synthetic fabrics
together.
Bed Linen
This programme is intended for drying cotton sheets.
Shirts
This is a programme for Shirts made from cotton or cotton
blend/synthetics.
Sport
For drying sports garments made of synthetics or cotton.
Duvet
Programme intended to dry bulky garments, as single duvet.
Jeans
For drying cotton jeans-wear and garments made of robust
cotton, like denim, such as trousers and jackets.
Easy Ironing
This cycle allows to extend the fibres of garments thus making
ironing and folding easier. Do not use in case of garments that are
still wet. Suitable for small loads of cotton textiles or cotton blends.
*MAX LOAD 7 Kg
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
h
4 5 6
180'
120' 9h
90' 6h
60' 3h
30' 1h
h
4 5 6
kg Max* Time 197'
kg 4 Time 184'
kg Max* Time 240'
kg 3 Time 137'
kg 4 Time 75'
Time 179'
kg 3 Time 135'
(Dry load)
EN 3
7
9 1
8
3"
3
7
xxxx xxxx
xxxxxxxxxxxx xxxxxxxxxxxx
