Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.

AIR COMPRESSOR

IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
6-GALLON
Model # 2287
(M-F 8AM-5PM CST)
bit.ly/wenvideo

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2287 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wen 2287

Summary of Contents for Wen 2287

  • Page 1: Air Compressor

    WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    Know Your Compressor Assembly Operation Maintenance Troubleshooting Parts List & Exploded View Warranty TECHNICAL DATA Model Number: 2287 Motor: 120V, 13A, 60 Hz, 3 Wire Capacity: 6 Gallon Max PSI: 125 PSI Approximate Cut-in Pressure: 95 PSIG Approximate Cut-out Pressure:...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instruc- tions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
  • Page 4 GENERAL SAFETY RULES POWER TOOL USE AND CARE 1. Avoid accidental start-ups. Make sure the power switch is in the OFF position before connecting the plug to a power source or carrying the tool. 2. Check power tool for damaged parts. Check for misalignment of moving parts, jamming, breakage, improper mounting, or any other conditions that may affect the tool’s operation.
  • Page 5 SPECIFIC RULES FOR AIR COMPRESSORS 5. Keep your air compressor in a well-ventilated area. Do not cover during use. 6. Do not spray flammable liquids in a confined area or towards a hot surface. The spray area must be well-ventilat- ed.

  • Page 6: Electrical Information

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug.

  • Page 7: Know Your Air Compressor

    KNOW YOUR AIR COMPRESSOR Air Filter Regulated Pressure Gauge Tank Pressure Gauge Motor Pressure Switch Tank Air Pressure Regulator Air Line Outlet Tank Drain Valve Handle Pump Oil Cap Breather Power Cord Oil Gauge...

  • Page 8: Assembly

    ASSEMBLY INSTALLING THE WHEELS Insert bolt M10X1.25X57 into the wheel through the wheel bracket and 10mm flat washer, then tighten with M10X1.25 hex nut. Repeat for both wheels. INSTALLING THE AIR FILTER Remove the plastic plug. Install the air filter (Fig. 2 - 1) before starting the air compressor.

  • Page 9: Thermal Overload Protector

    OPERATION WARNING: To prevent burns or other injuries, DO NOT touch the compressor while it is running. Allow it to cool before handling or servicing. Keep children away from the compressor at all times. 7. Allow the compressor to reach the desired PSI on the tank pres- sure gauge before turning off the compressor.

  • Page 10: Maintenance

    MAINTENANCE WARNING: Always shut off and unplug the compressor and relieve all air pressure from the system before performing any cleaning or inspection on the air compressor. CLEAN AND INSPECT DAILY 1. Pull the pressure release valve ring to open the pressure release valve after each operation. 2.

  • Page 11: Troubleshooting

    If there are still problems after consulting this list, or if you have any questions about the solu- tions provided above, feel free to contact the WEN help line at 800-232-1195 (M to F, 8 to 5 CST).
  • Page 12 EXPLODED VIEW AND PARTS LIST...
  • Page 13 EXPLODED VIEW AND PARTS LIST Part No. Description Qty. 2287-001 Pump L2 2287-002 Isolator Foot Sears 58mmX27mm 2287-003 Shroud L2 2289-005 Kit Air Intake Metal Housing 1/2-14 NPT 2289-006 Power Cord ST Type 6’ 2287-006 Pressure Switch 4-Port 95-125 PSI 2287-007 Pressure Gauge 1.5”, 1/4”...

  • Page 14: Warranty

    LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
