Installation and Operating Manual
Charging Converter, B2B Battery to Battery, battery charging while driving:
VCC 1212-25 Li
VCC 1212-45 Li
VCC 2412-25 Li
VCC 2412-45 Li
Note:
Please read this operating and installation manual thoroughly prior to connection and start-up.
Fully automatic Battery Charging Converter for LiFePO4 batteries in special purpose vehicles, in high-quality
campers, in the marine field.
The charging converters
(
supply battery charging (board battery) with LiFePO4 technology during driving.
In contrast to conventional cutoff relays, the charging voltage will be raised or lowered in case of losses on the supply
lines, battery voltage fluctuations etc., thus adapting it automatically to the default charging values. Charging converters
with 24 V input voltage allow charging of the 12 V supply battery without installation of a second generator.
Thus, the charging converter ensures the known high-quality battery charging of the VOTRONIC chargers also during
driving. Due to the intelligent microprocessor charging control with charging characteristic lines "IIU1oU2oU3" and
dynamic calculation of the charging time, automatic, quick and gentle full charging is ensured, as well as subsequent
100 % trickle charge of the connected batteries from any charging state. At the same time, simultaneous supply of 12 V
consumers, which are connected in parallel, is ensured. Overcharging of the batteries is avoided, even in case of
extremely long driving times.
The charging converters excel by their compact design, low weight (high-frequency switch mode technology), powerfully
dimensioned power components and consequently full charging capacity, even with long charging cables or strong
voltage fluctuations at the starter battery (EURO Standard 6, 6 + plus vehicles), information see page 10, table 2, switch
position "D".
Battery Port and Charging Programs:
Charging Port "OUT": Board battery, supply battery, depending on battery type and battery manufacturer 4 charging
programs selectable, adapted to Lithium LiFePO4 batteries, see table 1, page 8.
Further Characteristics of the Unit:
The charging voltage is free from peaks and is controlled in such a way, that overcharging of the batteries is
excluded.
Fully automatic operation by means of control input (ignition, running motor, D+), as well as voltage control.
Automatic, adjustable power control giving priority to charging of the starter battery by the generator in case of
overloaded vehicle mains to ensure that the vehicle can be started at any time.
No discharge (current 0,000 A) of the batteries during stand-by or with switched-off charging converter.
Parallel and Floating Operation: In case of simultaneous consumption, the battery will either continue to be charged
or maintained via trickle charging. Calculation and control of the adaptation of the charging time is effected
automatically by the charging converter.
Unattended Charging: Multiple protection against overload, overheating, overvoltage, short circuit, reverse battery
at the output, incorrect behaviour and back discharge of the battery by electronically controlled gradual reduction
down to complete separation of charging converter and battery by integrated safety relays.
Galvanic isolation between input and output: Complete separation of the battery circuits, even in case of failure,
important for 12 V/24 V mixed systems, avoids undesirable back discharge and suppresses interferences in the board
mains.
Charging Cable Compensation: Automatic compensation of voltage losses on the charging cables.
Integrated On-board Mains Suppression Filter: Unproblematic parallel operation of solar systems, wind and petrol-
driven generators, mains supply chargers etc. at a single battery.
Temperature control and adaptation of the charging by battery temperature sensor, which allows also charging
beyond the recommended LiFePO4 battery temperatures below 5 °C and above 35 °C.
Battery Lifetime and Efficiency:
Keep the batteries cool, LiFePO4 preferably above 0 °C. Choose an appropriate location for
installation.
Input Voltage 12 V
Input Voltage 12 V
Input Voltage 24 V
Input Voltage 24 V
The unit does not operate, unless the temperature sensor had been
connected (safety disconnection)!
Booster, B2B Battery to Battery
• Store only fully charged batteries and recharge them periodically.
Charging Capacity 12 V / 25 A
Charging Capacity 12 V / 45 A
Charging Capacity 12 V / 25 A
Charging Capacity 12 V / 45 A
had been developed according to the latest regulations for
)
No. 3300
No. 3307
No. 3302
No. 3309

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC 1212-25 Li and is the answer not in the manual?

Questions and answers

Summary of Contents for Votronic VCC 1212-25 Li

  • Page 1 24 V input voltage allow charging of the 12 V supply battery without installation of a second generator. Thus, the charging converter ensures the known high-quality battery charging of the VOTRONIC chargers also during driving. Due to the intelligent microprocessor charging control with charging characteristic lines "IIU1oU2oU3" and dynamic calculation of the charging time, automatic, quick and gentle full charging is ensured, as well as subsequent 100 % trickle charge of the connected batteries from any charging state.
  • Page 2: Safety Regulations

    We do not assume any liability for any damage resulting hereof. The liability exclusion is extended to any service being executed by third, which has not been ordered by us in writing. Service is to be effected exclusively by VOTRONIC Lauterbach.
  • Page 3: Installation Of The Unit

    - 3 - Installation of the Unit: The charging converter can be installed at any location, which is clean and which is protected from humidity and dust. Choose an installation location ensuring that the length of the connection cable between starter battery (IN) and board battery (OUT) is as short as possible.
  • Page 4 - 4 - General Connection Plan Charging Converter, All Types: Note: For safety reasons, the unit does not operate, unless the temperature sensor had been connected! The temperature sensor must be screwed-down to the negative pole of the battery. If possible, the unit should always be installed as close as possible to the board battery I Observe the cable cross-sections, lengths and fuses according to the table on page 5! Possibly existing cables, which do not have the required cross-sections must be adapted to the minimum requirements in any case!
  • Page 5 - 5 - Recommended Cable Cross-Sections and Cable Lengths: VCC 1212-25 Li VCC 1212-45 Li cross-section cable length IN Fuse cable length Fuse cable length IN Sich. cable length Fuse +/- Pole II Motor Batt. OUT I Main Batt. II Motor Batt.
  • Page 6 Connection Plan VCC 1212-25 Li, VCC 1212-45 Li, including: • VOTRONIC Charger Li with separate charging port for starter battery • VOTRONIC Solar Charging Controller Li with separate charging port for starter battery Note: For safety reasons, the unit does not operate, unless the temperature sensor had been connected! The temperature sensor must be screwed-down to the negative pole of the battery.
  • Page 7 - 7 - Temperature Sensor (must be connected to allow operation of the unit): The temperature sensor controls the battery temperature of the board battery and must be connected to the terminals "Temp. Sensor T T" (any polarity). Installation Temperature Sensor: The thermal contact of sensor and inside temperature of the battery should be well.
  • Page 8 - 8 - Table 1: Setting of the charging program OUT for type (design) board battery I Move the 2 slide switches "Battery Type" OUT 12 V at the front panel to the desired position for board battery "I" using a small screw-driver. The control levers are shown in white. The charging regulations of the battery manufacturer are absolutely to be observed! An operation of the unit at a LiFePO4 battery without BMS Battery Management System and without cell equalization charging (balancing) is not admissible!
  • Page 9 - 9 - Charging Voltage Rates and Temperature Control Battery I: Do not operate the unit without temperature sensor. The sensor must be screwed down to the negative pole of the battery. Charging will not be effected without sensor (LED "Main Charging" is flashing)! Switch Position Charging Program "1 LiFePO4"...
  • Page 10 - 10 - Table 2: Setting the Input, Installation Operating Mode IN II at the Starter Battery: Power Control for Starter Battery and Generator Move the 2 slide switches "Input Type S1, S2" IN II 12 V (24 V) at the front panel to the desired position for Starter Battery "II"...
  • Page 11: Pilot Lamps

    - 11 - Start-up and Function Test: After connection of the charging converter according to the description, a function test can be executed. Start the vehicle or switch on ignition (Kl.15). The charging converter will be activated and starts with 10 % of the maximum charging capacity. The LEDs "Power”, "Battery I”, "Main Charging”...
  • Page 12: Operating Instructions

    - 12 - "Battery II" (Starter Battery, yellow): • If it is flashing: The power control of the charging converter has reduced the output capacity by more than 30 % (starter battery discharge protection, starting capacity is maintained), since the voltage of the starter battery dropped below the adjusted value for "Reduction of the charging capacity"...
  • Page 13 - 13 - Charging Process of the Board Battery I, Out, Output Side of the Charging Converter: A new, complete main charging cycle will be executed: • After a standstill of the generator or removal of the control signal D+ or Kl.15. •...
  • Page 14 Special Case 1: Connection Plan for existing Electroblock "EBL", Only for Types VCC 1212-25 Li and VCC 1212-45 Li: Imperatively check the mains supply charger of the "EBL" for its suitability for the LiFePO4 battery! Option: Voltage display at an EBL of older design (EBL START In): After installation of the charging converter in connection with an EBL of older design, it might happen, that the voltage for the starter battery will not be displayed, if the charging converter had been switched-off.
  • Page 15 Special Case 2: Connection Plan for existing Electroblock "EVS", Only for Types VCC 1212-25 Li and VCC 1212-45 Li: Imperatively check the mains supply charger of the "EVS" for its suitability for the LiFePO4 battery! A special feature of the "EVS" systems is only a single connection to the starter battery, which means, that separate connections for charging and voltage measurement for the starter battery do not exist.
  • Page 16 • Operating Manual Subject to misprints, errors and technical modification without notice. All rights reserved, particularly the right of reproduction. Copyright  VOTRONIC 07/2018. Made in Germany by VOTRONIC Elektronik-Systeme GmbH, Johann-Friedrich-Diehm-Str. 10, 36341 Lauterbach/GERMANY Phone: +49 (0)6641/91173-0 Fax: +49 (0)6641/91173-20 E-mail: info@votronic.de...
