Datacom Systems Tap Series Fast Start Manual

Tap Series FTP-1000,2000,4000
FASTstart Guide

What is included?

Fiber taps allow you to make a copy of network traffic as it travels between two network devices. These highly reliable, non-
powered devices are the perfect solution to collect and capture network traffic for application analysis.

Installation

Follow the wiring diagrams shown below. Fiber taps are directional, and use specific inputs and outputs for TX and RX to work
properly. Make sure to clean all connectors with compressed air and clean patch cable connectors prior to installation.

Typical Insertion loss ratios*

Firewall
Front View
Router
Link 1
TX RX
A
Link 1
TX RX TX
NET
NET
1A 1B
Customer Service
is available from our website: www.datacomsystems.com or by calling +1 315 463 9541
© 2015 Datacom Systems, Inc 541-0149-R
(1) Fiber tap w/ mounting bracket (for use with RMC-2 , RMC 12-2 or RMC-3, RMC 12-3)
(1) Download Card/Faststart Guide (tells where to download more product information)
: •50/50 MM -4.2 dB •70/30 MM -3.0/-6.7 dB •50/50 SM -3.9 dB
FTP-1000 Series
Port Port
1 2
Analysis Tool
RX TX
TX TX
A B
B MONITOR
Front View
RX TX TX TX TX TX
A B A B
NET
MON MON
2A
1 2
Firewall A
Front View
Router A
Link 1
TX RX
TX
NET NET
1A 1B
Link 2 Link 3
RX
RX RX TX TX
TX
NET NET
2B 3A
For More information
Page 1
DATACOM
S Y S T E M S I N C
•70/30 SM -2.2/-6.3 dB (*approximate)
Firewall B
FTP-2000 Series
Router B
Link 2
RX RX TX RX
TX
NET NET
2A 2B
FTP-4000 Series
TX
RX TX TX TX
A
A B B
MON
NET MON
3B 3 4
Find out more. Visit
www.datacomsystems.com
TX TX TX TX
A B A B
MON MON
1 2
Link 4
TX RX RX
TX
NET NET
4A 4B
