Delta Children Jeep SPORT UTILITY Instruction Manual

All-terrain stroller
Hide thumbs
Table of Contents

Advertisement

Quick Links

SPORT UTILITY
ALL-TERRAIN
STROLLER
ADULT ASSEMBLY REQUIRED
STYLES AND COLORS MAY VARY
12498
WARNING:
CHOKING HAZARD
Adult assembly required because of
small parts. Keep assembly parts out
of reach of children under 3 years.
Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE.
This stroller is not from, sponsored or endorsed by Graco Children's Products Inc.
This stroller is not from, sponsored or endorsed by Evenflo Company, Inc.
This stroller is not from, sponsored or endorsed by Artsana S.p.A.
This stroller is not from, sponsored or endorsed by Britax®.
Customer Care Tel. (646) 435-8726
INSTRUCTION MANUAL
Fits Graco® SnugRide® Click Connect™ 30, 35, and 40 Infant Car Seat (not included)
Fits Evenflo® Embrace™ Select Infant Car Seat (not included)
Fits Evenflo® Nurture™ Infant Car Seat (not included)
Fits Chicco® Keyfit 30™ Infant Car Seat (not included)
Fits Britax® B-Safe 35™ Infant Car Seat (not included)
www.DeltaChildren.com
DCP-02052019-V3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jeep SPORT UTILITY and is the answer not in the manual?

Questions and answers

Related Manuals for Delta Children Jeep SPORT UTILITY

Summary of Contents for Delta Children Jeep SPORT UTILITY

  • Page 1 SPORT UTILITY ALL-TERRAIN STROLLER INSTRUCTION MANUAL ADULT ASSEMBLY REQUIRED Fits Graco® SnugRide® Click Connect™ 30, 35, and 40 Infant Car Seat (not included) Fits Evenflo® Embrace™ Select Infant Car Seat (not included) STYLES AND COLORS MAY VARY Fits Evenflo® Nurture™ Infant Car Seat (not included) Fits Chicco®...
  • Page 2 WARNING: Please follow all of these instructions to ensure the safety of your child. Keep these instructions for future reference. WARNING: Failure to follow these instructions could result in serious injury or death. WARNING: Avoid serious injury from falling or sliding out. Always insure that the child is properly positioned by using the safety harness according to these instructions.
  • Page 3 Parts Assembly IMPORTANT! Please remove all parts from the package and identify them Remove stroller from box. The front wheels, rear wheels, seat, canopy, and before assembly. child bar need to be installed prior to use. IMPORTANT! Before assembly and each use, inspect this product for WARNING: Care must be taken when folding and unfolding damaged hardware, loose joints, missing parts, or sharp edges.
  • Page 4 Assembly Please follow these instructions for the proper installation of your front wheel assembly. Fig. 2 Rotate clockwise Rotate counter to lock clockwise to unlock Fig. 3 Fig. 3A Front Swivel Wheel Lock • To lock the front swivel wheel lock: Rotate the lever located on the top of the front wheel housing clockwise until it “CLICKS”...
  • Page 5 Assembly Please follow these instructions for the proper installation of your rear wheel assembly. Attaching Rear Wheels: Fully Locked Fig. 4 CLICK Position Fig. 4A Removing Rear Wheels: Fig. 5 Push downward on brake lever to lock stroller Fig. 4B Fig.
  • Page 6 Assembly Right / Left Seat Housing CLICK Fully Locked Position Fig. 6B Front Facing Seat - Rear Facing Seat - Child Facing Child Facing Parent- Away from Parent Infant -Toddler Fig. 6 Fig. 6A Attaching / Removing Seat Attaching Seat •...
  • Page 7 Securing Child Before Placing your Child in Stroller: Close Canopy. Press both brake pedals down until they “click” into the locked position. Make sure the brake pedals are pressed down completely. Always set both brake pedals when parking the stroller. Waist Belt Waist Belt 5 Point Safety...
  • Page 8 Setup and Use Velcro Fig. 7A Fig. 7C Fig. 7 Fully Locked Position Fig. 7B Canopy Adjustment Options: Fig. 7D Fig. 7F Attaching Canopy and Canopy and Sun Visor Adjustment Attaching Canopy • To attach the canopy: Place canopy onto the top front of the stroller. (Fig.
  • Page 9 Setup and Use RECLINE UPRIGHT Fig. 8 Fig. 8A Seat Back Recline Positioning • To recline seat: Lift recline latch located on the back of the seat and rotate seat downward to recline seat. (Fig. 8) • To return to an upright position: Pull the recline latch and push seat upward into its desired position until it “CLICKS”...
  • Page 10 Setup and Use CLICK Fig. 11 Fig. 11A Child Bar Cover Unzip Fig. 11D Unvelcro Fig. 11C Fig. 11B Attaching / Removing Child Bar Attaching Child Bar • To attach child bar: Insert left / right sides of the child bar into the child bar housing located on the left / right side of the stroller frame.
  • Page 11 Attaching Chicco Car Seats ® Chicco Keyfit 30™ ® Lock The Rear Wheels: Remove Seat: Press Both Side Fig. 12 Buttons And Lift Push downward on brake To Fully Remove lever to lock stroller Seat Fig. 12A Attaching Car Seat Adapter: Insert On Both Sides Front...
  • Page 12 Attaching Graco Car Seats ® Graco SnugRide® Click Connect™ 30, 35, and 40 ® Lock The Rear Wheels: Remove Seat: Press Both Side Fig. 13 Buttons And Lift Push downward on brake To Fully Remove lever to lock stroller Seat Fig.
  • Page 13 Attaching Evenflo Car Seats ® Evenflo Nurture™ and Embrace™ ® Lock The Rear Wheels: Remove Seat: Press Both Side Fig. 14 Buttons And Lift Push downward on brake To Fully Remove lever to lock stroller Seat Fig. 14A Attaching Car Seat Adapter: Fig.
  • Page 14 Attaching Britax Car Seats ® Britax B-Safe 35™ ® Remove Seat: Lock The Rear Wheels: Fig. 15 Press Both Side Buttons And Lift To Fully Remove Push downward on brake Seat lever to lock stroller Fig. 15A Attaching Car Seat Adapter: Insert On Both Sides Front...
  • Page 15 Setup and Use Fold Latches Fig.16 Auto Lock Fully Folded Position Fig. 16A Folding the Stroller WARNING: Care must be taken when folding and unfolding the stroller to prevent finger entrapment. NOTE: Stroller can be folded with seat attached, if folding with seat attached, make sure canopy is in it’s fully closed position, seat is in a fully upright position, and footrest is in it’s lowest position before folding the stroller.
  • Page 16 Flat Tire The stroller features rear bicycle air tires which could become flat. If you have a flat tire, use a standard bicycle hand air pump to inflate the tires. Inflate the tires 28 psi. NOTE: The stroller air tires can be taken to a bicycle shop for flat tire repair. Customer Service www.DeltaChildren.com Tel.
  • Page 17 646-435-8726...
