WIND GAGE
ET2000 (400 SERIES) WIND GAGE
8
4
3
2
1
10
1
STOP – The STOP key will stop any currently
running Scheduled watering Cycle, Manual
Cycle, Test Cycle, Manual Special Sequence.
2
MANUAL – The MANUAL key will perform
Manual Water, Test, Master Valve Override and
Manual Special Sequence.
3
NO WATER – The NO WATER key will turn the
controller Off and set No Water Days.
4
? – The ? key is used to access the controller
Help screens.
5
ENGLISH / ESPANOL – The ENGLISH /
ESPANOL key allows you to toggle the displayed
text between English and Spanish.
6
BACK – The BACK key will go back to the
previous screen.
®
7
MAIN MENU – The MAIN MENU key is used to
access the different program features of the
controller.
8
MENU KEYS – MENU keys select the different
features of commands in the different screens
and are adjacent to the left and right side of the
controller's display screen. The text in the screen
will point towards the MENU key that needs to
be pressed.
9
LEFT / RIGHT ARROW KEYS – The LEFT /
RIGHT ARROW keys move the highlighted
cursor around the different screens when setting
up or editing the controller's features and
options.
10
PLUS / MINUS KEYS – The PLUS / MINUS
keys increase or decrease values or answer Yes
or No questions in the different screens.
water work
m aking
WIND GAGE SETUP
8
5
6
7
9
since 1986
Advertisement
Related Manuals for Calsense 400 Series
Summary of Contents for Calsense 400 Series
- Page 1 WIND GAGE SETUP ® WIND GAGE ET2000 (400 SERIES) WIND GAGE STOP – The STOP key will stop any currently MAIN MENU – The MAIN MENU key is used to running Scheduled watering Cycle, Manual access the different program features of the Cycle, Test Cycle, Manual Special Sequence.
- Page 2 The WIND GAGE SETUP screen will change to Press the WEATHER menu key reveal the irrigation wind settings (Figure 4). (Figure 1). WIND GAGE SETUP CALSENSE WATER MANAGEMENT SYSTEM Is controller Wired to a Programs & Stations Lights WIND GAGE ? YES...
- Page 3 WIND GAGE SETUP ® Press the PLUS or MINUS key Press the blue ARROW key to (Figure 6). move the cursor to the next entry. To set the wind sustained time that you want the controller to check for prior to resuming irrigation, WIND GAGE SETUP Is controller Wired to a WIND GAGE ? YES...
- Page 4 WIND GAGE SETUP ® ® 2075 Corte del Nogal, Suite P, Carlsbad CA 92011 1-(800)-572-8608 FAX: 1-(760)-438-2619 www.calsense.com Stock Number: PG1-WG-D2 Rev. 03/06 water work m aking since 1986...
