Calsense ET2000 Setup Instructions

MOISTURE SENSOR
ET2000 (500 SERIES) MOISTURE SENSOR SETUP
8
4
3
2
1
10
1
STOP – The STOP key will stop any currently
running Scheduled watering Cycle, Manual
Cycle, Test Cycle, Manual Special Sequence.
2
MANUAL – The MANUAL key will perform
Manual Water, Test, Master Valve Override and
Manual Program 1 & 2, Walk-thru,
and Use Hold-over.
3
NO WATER – The NO WATER key will turn the
controller Off and set No Water Days.
4
? – The ? key is used to access the controller
Help screens.
5
ENGLISH / ESPANOL – The ENGLISH /
ESPANOL key allows you to toggle the displayed
text between English and Spanish.
6
BACK – The BACK key will go back to the
previous screen.
®
MOISTURE SENSOR SETUP
7
MAIN MENU – The MAIN MENU key is used to
access the different program features of the
controller.
8
MENU KEYS – MENU keys select the different
features of commands in the different screens
and are adjacent to the left and right side of the
controller's display screen. The text in the screen
will point towards the MENU key that needs to
be pressed.
9
LEFT / RIGHT ARROW KEYS – The LEFT /
RIGHT ARROW keys move the highlighted
cursor around the different screens when setting
up or editing the controller's features and
options.
10
PLUS / MINUS KEYS – The PLUS / MINUS
keys increase or decrease values or answer Yes
or No questions in the different screens.
water work
m aking
8
5
6
7
9
