2.3

Mounting the AC5200

2.4

Battery Installation

Siemens AB
Security Products
The following instruction explains how to mount an AC5200.
To mount an AC5200:
1. Remove the AC5200 from its carton and discard the packaging material.
2. Place the AC5200 against the surface to which it is to be affixed and mark the
location of the mounting holes.
3.
Select the appropriate drill bit according to the mounting surface / hole size
and drill the holes in the locations marked (if required).
4. Fasten the AC5200 to the surface using the correct type of screws or stand-
offs for the surface in the 4 locations provided.
5. Download the firmware instruction set (as described in the section titled
"Firmware Download").
6.
Connect the cabling to the ACC (as described in the section titled "Wiring").
7. Apply power to the ACC and test its operation. This step will require pro-
gramming of the host software.
A battery is already installed and shipped with the AC5200.
To activate the AC5200 battery:
1. Open the AC5200 case
2. Remove the orange isolating plastic band to activate the battery poles.
