Hardware Connection
2.2

Explanation of connectors

10
Siemens AB
Security Products
Communication with SiPass integrated
The AC5200 communicates with SiPass integrated via TCP/IP. Connect an Ether-
net cable to either of the available RJ45 Ethernet connections.
Peer to Peer communication between controllers is also done via TCP/IP.
The following table explains of each of the available connectors on the AC5200.
Terminal Number Connector Label
1 12-24V +
2
3 COM B
4 COM A
5 FRAME
6 COM B
7 COM A
8 FRAME
Description
Positive connector for power source
Negative connector for power source
RS485 bus connection for FLN/Entro
devices
RS485 bus connection for FLN/Entro
devices
Signal screen for RS485 bus connec-
tion.
Not in use
Not in use
Not in use
