CCD COLOR CAMERA
Model CS5270B/CS5270BP
Thank you for purchasing our product.
Before using this CCD Color camera, please read through this instruction manual
carefully in order to use this product correctly and safely.
After reading, keep this instruction manual handy so that you can refer to,
whenever you need it.
1. Overview··································································································· 1
2. Features ····································································································· 1
3. Configuration ···························································································· 1
4. Optional parts···························································································· 2
5. Name of Each Parts··················································································· 2
6. Control of internal dip switches ································································ 3
7. Connection ································································································ 5
8. How to set up your camera ······································································ 6
9. Specifications ··························································································· 7
10. How to mount your camera ···································································· 8
11. Outline Drawing······················································································ 9
Instruction Manual
Contents
Rev.1. 0
Printed on recycled paper
D4161564A
Advertisement
Table of Contents
Related Manuals for Toshiba teli CS5270B
Summary of Contents for Toshiba teli CS5270B
-
Page 1: Table Of Contents
Rev.1. 0 CCD COLOR CAMERA Model CS5270B/CS5270BP Instruction Manual Thank you for purchasing our product. Before using this CCD Color camera, please read through this instruction manual carefully in order to use this product correctly and safely. After reading, keep this instruction manual handy so that you can refer to, whenever you need it. -
Page 2: Safety Precautions
Rev.1. 0 Safety Precautions Before using this product, read these safety precautions carefully. Important information is shown in this Instruction Manual to protect users from bodily injuries and property damages, and to enable them to use the product safely and correctly. Please be sure to thoroughly understand the meanings of the following signs and symbols before reading the main text that follow, and observe the instructions given herein. - Page 3 Rev.1. 0 [General Handing] WARNING Immediately cease use of the equipment in the event of abnormality or malfunction. If abnormal conditions are present, such as smoke, a burning smell, ingress of water or foreign matter, or if the equipment is dropped or malfunctions, fire or electric shock may result. If such abnormalities occur, disconnect the power plug from the outlet and contact your sales unplug representative.
- Page 4 Rev.1. 0 [General Handing] CAUTION Observe the following when installing the equipment: · Do not cover the equipment with a cloth, etc. · Do not place the equipment in a narrow location where heat is likely to accumulate. Otherwise, heat will accumulate inside the equipment, possibly resulting in a fire. Instruction Do not place the equipment in locations subject to high moisture, oil fumes, steam, or dust.
-
Page 5: Restriction For Use
Rev.1. 0 CASES FOR INDEMNITY (LIMITED WARRANTY) We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user in the following cases. In the case damage or losses are caused by fire, earthquake, or other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme operating conditions. -
Page 6: Notes On Using This Product
Rev.1. 0 Notes on using this product Handle carefully Do not drop the equipment or allow it to be subject to strong impact or vibration, as such action may cause malfunctions. Further, do not damage the connection cable, since this may cause wire breakage. Environmental operating conditions Do not use the product in locations where the ambient temperature or humidity exceeds the specifications. - Page 7 Rev.1. 0 This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 8: Overview
Rev.1. 0 1. Overview The CS5270B/CS5270BP is a one-piece type (*) CCD color camera with a ultra-compact & light-weight body. [*One-piece type : One integrated body made up of the camera head & the camera control unit] 2. Features (1) The camera is driven by DC+12V. -
Page 9: Optional Parts
Rev.1. 0 4. Optional parts (1) Power cable Model name: CPRC5260D-** (2) Camera mounting kit Model name: CPT8420 (3) Camera adapter Model name: CA5260 Notes on optional parts and compliance with safety standard conditions: We assure the compliance of this camera with the safety standard when it is used in combination with the optional parts listed above. -
Page 10: Control Of Internal Dip Switches
6. Control of internal dip switches (1)The inner structure The inner structure of this camera is shown as follows. ●The side-view of a CS5270B/CS5270BP without the cabinet S201 ● The top-view of a CS5270B/CS5270BP without the cabinet S201 CONTROL BOARD Initial factory-setting D4161564A... - Page 11 Fix ON(γ γ γ γ =0.45) Under S201-4 ON (=Flicker-less ON) ― ― CS5270B : Shutter speed 1/100(s) CS5270BP : Shutter speed 1/120(s) With S201-4 ON, fluorescent light flicker is reduced. (Under rear-panel SW ALC ON only) S201-5 & 6 should be set ON constantly.
-
Page 12: Connection
(The figure below shows an example of connection. For details, contact our sales representative.) CAMERA CABLE CPRC5260D (Optional accessory) CCD COLOR CAMERA CAMERA VIDEO OUT GAIN CS5270B/CS5270BP 0dB 6dB 12dB OFF CAMERA ADAPTER AC100V IN RS-232C CA5260 DC IN VIDEO OUT (optional accessory) SERIAL NO. -
Page 13: How To Set Up Your Camera
Rev.1. 0 8. How to set up your camera (1) Connect the camera, video monitor, and the power supply onto each other. (2) Set the power switch of video monitor ON. (3) Supply power to the camera. (4) After confirming that images appear on the video monitor, adjust the lens aperture to obtain optimal illumination. (5) While monitoring images on the video monitor, adjust the focus of lens to obtain the sharpest images. -
Page 14: Specifications
Rev.1. 0 9. Specifications Model CS5270B CS5270BP TV system NTSC Image sensor Interline CCD ①Total pixels 811(H)×508(V) 795(H)×596(V) ②Active pixels 768(H)×494(V) 752(H)×582(V) ③Pixel size 8.4μm(H)×9.8μm(V) 8.6μm(H)×8.3μm(V) ④Scanning area 6.45(H)×4.84(V)mm 6.47(H)×4.84(V)mm ⑤Color filter Corrective mosaic filter (Ye, Cy, Mg, G) ⑥CCD integration... -
Page 15: How To Mount Your Camera
Rev.1. 0 10. How to mount your camera There are several alternative ways to fix the camera. Choose your method among the following options. (1) Option 1 : Using a camera tripod fixing kit Use an optional tripod fixing kit to fix the camera onto the tripod. Use attached screws to affix tripod-mounting hardware to your camera. -
Page 16: Outline Drawing
Rev.1. 0 11. Outline Drawing D4161564A... - Page 17 Rev.1. 0 Head Office : 7-1, 4 chome, Asahigaoka, Hino-shi, Tokyo, 191-0065, Japan (Overseas Sales Department) Phone : +81-42-589-8771 : +81-42-589-8774 : http://www.toshiba-teli.co.jp Distributor • This product must be classified for disposal according to the laws of each country and municipal laws. •...
