BY SUNSTONE®
USE & CARE GUIDE
Read all instructions before you operate your Side
To installer or person assembling burner:
reference.
Keep this manual for future reference.
To consumer:
www.sunstonemetalproducts.com
ATTENTION: THE SIDE BURNER MUST BE INSTALLED ACCORDING TO THE INSTALLATION
GUIDE. IF YOUR SIDE BURNER INSTALLATION DOES NOT MEET THE BASIC SETUP
INSTRUCTIONS ALL WARRANTIES MAY BE VOID. SEE WARRANTY ON LAST PAGE.
SIDE BURNER
Burner, Save these instructions!
Conforms to ANSI STD Z21.58-2018
Certified to CSA STD 1.6-2018
Outdoor Cooking Gas Appliance
Leave this manual with burner for future
Advertisement
Table of Contents
Related Manuals for SUNSTONE 1SSB
Summary of Contents for SUNSTONE 1SSB
- Page 1 SIDE BURNER BY SUNSTONE® USE & CARE GUIDE Read all instructions before you operate your Side Burner, Save these instructions! Conforms to ANSI STD Z21.58-2018 Certified to CSA STD 1.6-2018 Outdoor Cooking Gas Appliance Leave this manual with burner for future To installer or person assembling burner: reference.
-
Page 2: Welcome & Congratulations
Welcome & Congratulations Congratulations on your purchase of a new Sunstone Side Burner! We are very proud of our product and we are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority. Please read this manual carefully to understand all the instructions about how to install, operate and maintain for optimum performance and longevity. - Page 3 ATTENTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate personal injury, or property damage. WARNING: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. VOLTAGE: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate electrical shock.
- Page 4 START-UP CHECKLIST Caution: Never operate the burner unattended. FIRST TIME STARTUP CHECKLIST The burner is free of any debris or obstruction. Installation of the proper gas type and regulator settings. The proper gas connection is complete. Minimum clearances are maintained. ...
- Page 5 SPECIFICATIONS – Diagram 1SSB Name Part No. 1SSB Hood SB-HOOD Hood Handle P-HANDLE Grate Grids BURNER-GRAT Burner Assembly BURNER-RING Impulse Igniter IMP-IGNITER Gas Chamber BURNER-GC 1SSB Gas Manifold SB-MANIFOLD 1SSB Valve SB-VALVE LP/NG Igniter Ring IG-RING Control Knob KNOB-L Control Knob Ring...
- Page 6 SPECIFICATIONS – Diagram 2CSB Name Part No. 2CSB Hood DB-HOOD Hood Handle P-HANDLE Hood Brackets DB-HOOD-BRK Base Brackets DB-BASE-BRK Grate Grids BURNER-GRAT Gas Chamber BURNER-GC Impulse Igniter IMP-IGNITER 2CSB Gas Manifold SB-VALVE LP/NG Igniter Ring IG-RING 2CSB Valve DB-VALVE LP/NG Control Knob Ring KNOB-RING Large Knobs...
- Page 7 3. GAS SAFETY & ACCESS: For either Natural Gas or Liquid Propane type, it is required you have clear access to all interior island Gas-Plumbing, we recommend placing one of Sunstone's Single Access Vented Doors. Also have at least One Safety-Shut Off Valve Present and within easy access, if this appliance is being installed in a High-Traffic location like for Residential Community, it is important to have installed a Shut- Off Timer set for Auto-Shut off in 20 Minutes.
- Page 8 Free-Hang. The bottom of Burner needs to be open to allow for proper ventilation. Ruby Series Burner Island Cut-Out Dimensions ITEM NO. WIDTH DEPTH HEIGHT 2CSB – LP/NG 12” 20-1/4” 8” 1SSB – LP/NG 10” 16-1/8” 4”...
- Page 9 LOCATING BURNER Installing in Open Area – ATTENTION: Take special precaution when installing burner in open Breezy area, check the direction of Prevailing Wind, if back of burner is facing any oncoming wind or breeze, be sure to protect the back of burner and erect a partition wall. Windy Area Positioning your Side Burner in your backyard is more often thought of as how it is pleasing to the eye, but more important than this is how it functions correctly.
-
Page 10: Clearances To Combustible Construction
LOCATING BURNER Installing Under Structure – ATTENTION: All Gas Burner Installations MUST HAVE MINIMUM TWO AIR-FLOW VENTS, either in ELEVATED POSITION for Natural Gas or LOWERED POSITION for Liquid Propane. Your Warranty may be VOID if island does not meet basic setup requirements. BODILY INJURY: Failure to maintain required clearances creates a fire hazard that may result in property damage or serious personal injury. -
Page 11: Gas Installation
GAS INSTALLATION – Propane Tank Connections IMPORTANT: Before connecting burner to gas source, make sure BBQ Burner control knobs are in “OFF” position. Verify the type of gas supply to be used, either natural or LP, and make sure the marking on the appliance rating label agrees with that of the supply. - Page 12 GAS INSTALLATION – Propane Tank Connections Hose and Regulator The Type 1 connection system has the following features: The system will not allow gas to flow until a positive connection has been made. NOTE: The cylinder control valve must be turned off before any connection is made or removed. ...
- Page 13 GAS INSTALLATION – Natural Gas Installation Natural Gas Burners are designed to operate on Natural Gas ONLY, at a pressure regulated at 4” water column (W.C.) when equipped with the correct natural gas orifices on the valves and a NG regulator on the supply line regulated at the residential meter.
-
Page 14: Leak Testing Procedure
GAS INSTALLATION –Leak Test WARNING: Always perform a leak test before lighting the burner to prevent a possible fire or explosion. Never store a spare propane cylinder in the vicinity of this Burner, or in the vicinity of any other potential heat source. Never attempt to attach this burner to the self-contained LP gas system. Do not use burner until leak testing. -
Page 15: Safety Checks
GAS INSTALLATION –Leak Test Liquid Propane Leak Testing Procedure Test connection from LP Tank to Regulator Test connection from burner to LP Hose regulator Natural Gas Leak Testing Procedure Test connection next to NG regulator If unable to stop gas leak, turn gas off Test connection from gas line to adapter Test Quick Disconnect SAFETY CHECKS... -
Page 16: Burner Startup
BURNER STARTUP –Attention & Warnings WARNING: When Lighting the Burner. DO NOT RELEASE KNOB, GAS WILL CONTINUE TO FLOW. WARNING: Keep any electrical supply cords and the fuel supply hose away from any heated surfaces. CAUTION: Inspect the hose before using the burner. If there is excessive abrasion or wear, or if the hose is cut, it must be replaced prior to the outdoor cooking gas appliance being put into operation. - Page 17 BURNER START-UP - Burner Safety For Household Outdoor Use Only – DO NOT use indoors or in any type of enclosed area such as a garage, shed or breezeway. Keep clear of trees and shrubs. The side burners are not intended for installation in or on recreational vehicles, portable trailers, boats or any other moving installation.
-
Page 18: Lighting Instructions
BURNER START-UP –Lighting the Burner Lighting Instructions 1. If burner does not light, repeat Open Lid/Hood previous steps, or follow the following instructions. Ensure Burner Control Knobs In the “OFF” position, 5. If ignition does not occur in 5 seconds, Turn on the gas supply valve turn the burner control knob to “OFF”, wait 5 minutes to allow gas to dissipate... - Page 19 BURNER STARTUP - Care & Maintenance ANNUAL CLEANING OF BURNER HOUSING Burn-off the burner after use will keep it ready for instant use, however, once a year you should give the entire burner a thorough cleaning to keep it in top operating condition. 1.
- Page 20 6. No one has the authority to add to or vary SIDE BURNER warranty, or to create for SUNSTONE METAL PRODUCTS LLC. any other obligation or liability in connection with the sale or use of its products.
