SUN13VDB
USE & CARE GUIDE
Read all instructions before you operate your Side
Burner, Save these instructions!
ATTENTION: THE SIDE BURNER MUST BE INSTALLED ACCORDING TO THE INSTALLATION
GUIDE. IF YOUR SIDE BURNER INSTALLATION DOES NOT MEET THE BASIC SETUP
INSTRUCTIONS ALL WARRANTIES MAY BE VOID. SEE WARRANTY ON LAST PAGE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SUNSTONE SUN13VDB
Summary of Contents for SUNSTONE SUN13VDB
- Page 1 SUN13VDB USE & CARE GUIDE Read all instructions before you operate your Side Burner, Save these instructions! ATTENTION: THE SIDE BURNER MUST BE INSTALLED ACCORDING TO THE INSTALLATION GUIDE. IF YOUR SIDE BURNER INSTALLATION DOES NOT MEET THE BASIC SETUP...
- Page 2 Welcome & Congratulations Congratulations on your purchase of a new Sunstone Side Burner! We are very proud of our product and we are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority. Please read this manual carefully to understand all the instructions about how to install, operate and maintain for optimum performance and longevity.
-
Page 3: Table Of Contents
Installation Requirements--------------5 situation which, if not avoided, may result in minor or moderate personal injury, or property damage. Installing Under Structure--------------6 SUN13VDB LED Light--------------------7 WARNING: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 4: Sun13Vdb Specifications
START-UP CHECKLIST Caution: Never operate the burner unattended. FIRST TIME STARTUP CHECKLIST The burner is free of any debris or obstruction. Installation of the proper gas type and regulator settings. The proper gas connection is complete. Minimum clearances are maintained. ... -
Page 5: Sun13Vsb Installation
SPECIFICATIONS – Diagram SUN13VDB Name Part No. Name Part No. SUN13VDB Hood DB-HOOD Gas Flex Hose (Long) G-HOSE-LONG Hood Handle P-HANDLE Gas Flex Hose (Short) G-HOSE-SHORT Grate Grids BURNER-GRAT Igniter Wire (Long) P-IGNITERW-L Control Panel Frame DB-CT-FRAME Igniter Wire (Short) -
Page 6: Sun13Vdb Installation
LOCATING BURNER – SUN13DSB Installation Double Side Burner Cut-Out The Versa Double Side Burner is SELF-RIMMING, meaning the lip of burner rests on top of the counter edge around the cut-out and is Free Hanging from counter top. Make Cut-Out according to details below, remember if counter overhangs make notch Cut measuring 13-1/4”... -
Page 7: Installation Requirements
Gas-Plumbing allow minimum 6 Inch clearance around underside back of Burner, we recommend placing one of Sunstone's Single Access Vented Doors. Also have at least One Safety-Shut Off Valve Present and within easy access, if this appliance is being installed in a High-Traffic location like for Residential Community, it is important to have installed a Shut-Off Timer set for Auto-Shut off in 20 Minutes. -
Page 8: Installing Under Structure
LOCATING BURNER Installing Under Structure – Overhead Structure Definition: Structure built above Appliance that is sometimes attached to the home’s exterior outside wall or roof and there is a Minimum of “Two” adjacent sides which are open with outside exposure. Minimum Distances to Combustible Materials or another Appliance ONLY, Maintain Minimum Six-Inch Clearance to Structure around interior of Appliance! A. -
Page 9: Sun13Vdb Led Light
INSTALLING COMPONENTS – SUN13VDB LED LIGHT 1. Locate the Transformer Remove the transformer from the plastic bag located in the interior of burner box. Make sure the Transformer is complete, and double check the plug cord is properly secured to transformer, and all wires are firmly fixed into plastic clip plug. -
Page 10: Gas Installation
GAS INSTALLATION – Propane Tank Connections ATTENTION: Before connecting burner to gas source, make sure BBQ Burner control knobs are in “OFF” position. Verify the type of gas supply to be used, either natural or LP, and make sure the marking on the appliance rating label agrees with that of the supply. - Page 11 GAS INSTALLATION – Propane Tank Connections Hose and Regulator The Type 1 connection system has the following features: • The system will not allow gas to flow until a positive connection has been made. NOTE: The cylinder control valve must be turned off before any connection is made or removed. •...
-
Page 12: Natural Gas Installation
GAS INSTALLATION – Natural Gas Installation Natural Gas Burners are designed to operate on Natural Gas ONLY, at a pressure regulated at 4” water column (W.C.) when equipped with the correct natural gas orifices on the valves and a NG regulator on the supply line regulated at the residential meter. -
Page 13: Leak Test
GAS INSTALLATION –Leak Test WARNING: Always perform a leak test before lighting the burner to prevent a possible fire or explosion. Never store a spare propane cylinder in the vicinity of this Burner, or in the vicinity of any other potential heat source. Never attempt to attach this burner to the self-contained LP gas system. Do not use burner until leak testing. - Page 14 GAS INSTALLATION –Leak Test Liquid Propane Leak Testing Procedure Test connection from LP Tank to Regulator Test connection from burner to LP Hose Natural Gas Leak Testing Procedure Test connection next to NG regulator If unable to stop gas leak, turn gas off Test connection from gas line to adapter Test Quick Disconnect SAFETY CHECKS...
-
Page 15: Burner Safety
BURNER STARTUP –Burner Safety For Household Outdoor Use Only – DO NOT use indoors or in any type of enclosed area such as a garage or shed. Keep clear of trees and shrubs. The Side Burners are for Residential Use Only. The area surrounding your new side burner should be kept clean and free from flammable liquids and other combustible materials such as mops, rags or brooms, as well as solvents, cleaning fluids, and gasoline. - Page 16 BURNER STARTUP - Burner Safety • Never lean over the burner when flame is ON. • Do not place clothing or other flammable material on or near the burner. • Do not wear loose-fitting clothes or long sleeves while using the side burner as some fabrics can be highly flammable.
-
Page 17: Care & Maintenance
BURNER STARTUP - Care & Maintenance ANNUAL CLEANING OF BURNER HOUSING Burn-off the burner after use will keep it ready for instant use, however, once a year you should give the entire burner a thorough cleaning to keep it in top operating condition. 1. -
Page 18: Lighting The Burner
GRILL STARTUP –Lighting the Burner WARNING: When Lighting the Burner. DO NOT RELEASE KNOB, GAS WILL CONTINUE TO FLOW. Lighting Instructions Tip: Remove Cover • It is normal to hear a popping sound when the burners are Ensure Burner Control Knobs turned off. -
Page 19: Side Burner Warranty
6. No one has the authority to add to or vary SIDE BURNER warranty, or to create for SUNSTONE METAL PRODUCTS LLC. any other obligation or liability in connection with the sale or use of its products.
