Flexispot ET203H Installation Manual

Item No.：ET203H
Technical data
Column qty 3 Input Voltage 100-240V
125KG Max Speed 38mm/s
Max Loading capacity
Height range 600-1230mm Temperature 0-40°C
Length range Certification
1100-1800mm CE FCC CUL
Frequency continuous operation for 2 mins at most after pause for 18 mins
Component list
No. Part Qty No. Part Qty
1 2 2 2
Left Lifting Column Right Lifting Column
No. Part Qty No. Part Qty
3 2 4 4
Connecting beam Cover
No. Part Qty No. Part Qty
5 2 6 4
Supporting beam Supporting plate
No. Part Qty No. Part Qty
7 4 8 2
Cable management Control box
No. Part Qty No. Part Qty
Handswitch
9 10
2 2
Power cable
No. Part Qty No. Part Qty
11 12
4
12
Square spacer
Screen fixing base
Installation guide
Accessor y list
Attention: The drawings below are only for reference which might be
slightly different from the actual object, please in kind prevail. Any
tools missing or installation problems, please contact the customer
service firstly.
No. Image
Wrench
A
4x4mm
M6X16mm
B
M8×35mm
C
ST4.2x16mm
D
ST4.8x16mm
E
10
11
4
12
11
5
2
7
3
1
Step 1
A
5x5
Spec Qty
Wrench
1
5x5mm
8
Step 2
16
C
52
1
x16
10
A
A
C
5x5
Install the supporting beam(5) use 5*5
wrench(A) to tighten the screws(C).
8
6
Step 3
9
2
10
9
Install the connecting beam(3) use
5*5 wrench(A) to tighten the screws.
3
1
Install the supporting plate(6) use
5*5 wrench(A) to tighten the screws(C).
2
5
6
Connect all the cables onto the control box(8).
1
8
10
2
1
2
Install the connecting
beam(3)
2
3
Use 5*5 wrench(A)
to tighten the screws
A
6
C
4
Power port
Port for cable
Handswitch
connected to
H S M 1 M 2 the lifting
column
