  • Page 2 Indicates the operation in order. 1, 2, 3, … Indicates further details of above operation. ● Indicates the operating description and items. Indicates the result of operation. Describes the points, notices and references of operation. © 2008-2009 Shimadzu Corporation. All rights reserved.

  • Page 3: Table Of Contents

    System Components .......4 Contents Examination Room ..............4 Control Room ................9 System Startup and Shutdown ..... 12 Startup ...................12 X-ray Tube Aging ..............13 FPD Calibration ..............14 Shutdown ................17 Daily Inspection ..............18 Start Study ..........19 Input Patient Information ............19 Fluoroscopy/Radiography .....20 Operation of C-arm ..............20 Operation of Catheterization Table ........22 Fluoroscopy/Radiography ............23 Change Fluoroscopy/Radiography Program ......24...

  • Page 4: System Components

    System Components Examination Room C-arm Acquisition C-arm Review Monitor Indicator Monitor CyberGrip (or Cyber Console) Collimator Local Console IVR NEO Catheterization Table X-ray Tube Foot Switch (Examination Room)
  • Page 5 ■ CyberGrip Stop Switch Visual Field Selector Switch Catheterization Table Up/Down Switch Release Switch FPD SID Switch Direct Memory Switches C-arm Travel Selector Switch Tabletop Unlocking Switch C-arm Rotation Selector Switch (Located at the rear side of the grip) ■ Cyber Console C-arm Rotation/Travel Tabletop Unlocking Switch...
  • Page 6 ■ Local Console ① ② ③ ④ ⑥ ⑤ ⑧ ⑦ Name or Explanation ① C-arm Working Positions Switch ② Direct Memory Switches ③ Operate the C-leaf of the Collimator by moving up and down. ④ Operates the H/V Collimation. The Collimator opens up when this is pressed down. ⑤...
  • Page 7 ＊ How to use Direct Memory Function (CyberGrip) Select a button from , and Select the location of the C-arm from this area. Press and hold to move the C-arm to memory position. ＊ How to use Direct Memory Function (Cyber Console) Select a button from , and Select the location of the C-arm...
  • Page 8 ■ IVR NEO The IVR NEO features 16 buttons with LED indicators and a multi-function Joystick with button. Joystick Category Button LED Meaning Select Fluoro Program ON=Fluoro menu displayed. Select Rad Program ON=Rad menu displayed. Select Image Comment ON=Comment menu displayed. Add Reference Image ON=can add Reference Image.

  • Page 9: Control Room

    Control Room Acquisition Monitor Review Monitor X-ray Generator Console Keyboard Foot Switch Mouse C-arm Remote Digital Operation Console Cabinet ■ X-ray Generator Console Radiography Fluoroscopy Heat Unit [Tool] menu Message Parameters Parameters Indicator Setting Button X-ray OFF Button Power ON Button Power Aging Button...
  • Page 10 ■ Main Window Acquisition Monitor Parameters Acquisition Active [Ref] is displayed Study Information in review mode. Selected Digital Programs Timer Comment Image Viewer Side Menu (displayed when the mouse pointer is put on the left edge of the screen)
  • Page 11 Review Monitor Side Menu [Ref] is displayed in Study Information Parameters Image Selector review mode. Image Digital Program Viewer Pop-up Menu Probe Signal Comment Status Selected Digital Cine Control Modes and Network Messages Programs Info. Activity...

  • Page 12: System Startup And Shutdown

    System Startup and Shutdown Startup Be sure to perform daily inspection before patient use. NOTE "Daily Inspection" P.18 Circuit Breaker Turn on the X-ray high voltage generator circuit breaker ・ Make sure that power OFF button of the X-ray generator console is lit. ・...

  • Page 13: X-Ray Tube Aging

    X-ray Tube Aging CAUTION Be careful! During aging, X-ray exposure is performed automatically without operating hand switch or foot switch. The aging procedure can be performed when C-arm is at the NOTE park position even though the "fluoroscopy at park position" setting is set to OFF.

  • Page 14: Fpd Calibration

    ・ Press to pause aging. Press to resume. ・ Press to cancel aging, and press to confirm. FPD Calibration CAUTION Before calibrating FPD, make sure (X-ray OFF) on the X-ray generator console is disabled. X-ray OFF Button...
  • Page 15 C-arm Remove any object from FPD field of view Make sure that [PARK] button on the local console is lit. If [PARK] button is not lit, press until it is to park the C-arm. Move the Compensation Filters to the outside.
  • Page 16 Digital Radiography System Select and click on the side menu FPD calibration window appears. Confirm the calibration type Confirm that [Full-All Modes] is selected. Click Progress messages are displayed during calibration. Completion message is displayed when calibration is completed. Click CAUTION Be careful! X-ray exposure is automatic during calibration.

  • Page 17: Shutdown

    Shutdown C-arm Set the C-arm to the center position Press and hold the Center Reset Switch until travel is completed. Move the C-arm to the park position Press and hold the C-arm Parking Switch until travel is completed. Digital Radiography System Click A confirmation message is displayed.

  • Page 18: Daily Inspection

    Daily Inspection Check the following items before using the system. Before turning on the power switch. Ensure there is: • No damage on the exterior. • No Condensation or Water on the system. • No twisting of the cables. After turning on the power switch. Ensure there are: •...

  • Page 19: Start Study

    Start Study Input Patient Information Click from [Study] menu [New Study] window is displayed. Indicates Mandatory Items. Input each items Be sure to input the items with a dot. Click Patient information will appear on the upper Patient Information area of the main window.

  • Page 20: Fluoroscopy/Radiography

    Fluoroscopy/Radiography Operation of C-arm ■ CyberGrip Backward/Forward Movement of FPD Move the CyberGrip in the up and down direction while pressing FPD moves according to the direction of the grip. Rotation of C-arm (RAO/LAO) Move the grip in the up/down direction while pressing C-arm rotates according to the direction of the grip.
  • Page 21 ■ Cyber Console Backward/Forward Movement of FPD FPD SID Comfirmation Switch Move the FPD SID lever forward/ (on the far side) backward while pressing confirmation switch. FPD moves according to the direction of the lever. Rotation of C-arm （RAO/LAO） Move the C-arm rotation/ travel lever forward/ backward while pressing C-arm rotation selector...

  • Page 22: Operation Of Catheterization Table

    Operation of Catheterization Table Horizontal movement or raising/lowering of catheterization table. Horizontal Movement of Catheterization Table Move the table manually while pressing the unlocking switch. CyberGrip Grip Switch Table Console Raising of Catheterization Table Press (Up) switch. Tabletop rises. Table Console CyberGrip Lowering of Catheterization Table Press...

  • Page 23: Fluoroscopy/Radiography

    Fluoroscopy/Radiography Fluoroscopy Radiography Confirm the fluoroscopy Confirm the radiography program program ・ Modify the condition as needed. ・ Modify the condition as needed. ・ Positioning shall be set by fluoroscopy. Perform fluoroscopy more than 3 seconds. Press the fluoroscopy foot switch Press the radiography foot switch...

  • Page 24: Change Fluoroscopy/Radiography Program

    Change Fluoroscopy/Radiography Program Fluoroscopy/Radiography program presets and corresponding parameters are changeable. These parameters can be changed at the digital processing system in the control room or at the IVR NEO. "IVR NEO" P. 8 ■ Change Preset Parameters Fluoroscopy Radiography Click on the Click...

  • Page 25: Hv Flip

    HV Flip Flip and acquire the fluoroscopy and radiography images in the Horizontal or Vertical direction. Click the flip buttons on the side menu to flip images Flip horizontal (Click the button again to change the setting back to normal) Flip vertical (Click the button again to change the setting back to normal)

  • Page 26: Change Settings Of Injection Delay

    Change Settings of Injection Delay Injection-Acquisition Delay (the delay in seconds between injection and beginning of acquisition) and Mask- Acquisition Delay (the delay in seconds between end of mask acquisition and beginning of live acquisition) are set in advance for each acquisition program. These values can be changed temporary during study according to the following procedure.

  • Page 27: Recording Fluoroscopy Image

    Recording Fluoroscopy Image Last N seconds fluoroscopy record or Either Direct fluoroscopy record can be used. Default setting is Last N seconds fluoroscopy record. If you NOTE want to use Direct fluoroscopy record, system setting is required beforehand. ■ Last N seconds Fluoroscopy Record Perform fluoroscopy Click or press...

  • Page 28: Adjusting Image

    Adjusting Image ■ Display Button Function Adjust image brightness. Right-click: + (increase) Left-click: - (decrease) Click both mouse buttons simultaneously: 0 Adjust image contrast. Right-click: + (increase) Left-click: - (decrease) Click both mouse buttons simultaneously: 0 Optimize the brightness and contrast frame by frame. Enhance the image.
  • Page 29 ■ Playback Button Function Adjust the loop playback speed. Right-click: + (increase) Left-click: - (decrease) Click both mouse buttons simultaneously: Return to default ■ Controlling Image Playback Control Bar Keyboard IVR NEO Joystick Control Bar Keyboard IVR NEO Joystick Function Play/show next loop/image.

  • Page 30: Adding, Deleting And Displaying Reference Images

    Adding, Deleting and Displaying Reference Images Page Insert Home Page Delete Down Keyboard IVR NEO Joystick IVR NEO Button Keyboard IVR NEO Function Add Reference Image Delete Reference Image (Tilt downward) Go to next loop and pause (Tilt upward) Go to previous loop and pause Switch Playback mode/Review mode Related Operation for Study Button...

  • Page 31: Measuring And Analyzing

    Measuring and Analyzing ■ Quantitative Coronary Analysis (QCA) QCA Tool Bar Click and select QCA tool bar will appear. Perform calibration To perform calibration, display the image of reference object (such as a catheter) previously acquired with the same magnification as the analysis object.
  • Page 32 Specify the stenosed artery Click button from [Manual] menu. Click points on opposite sides of the narrowest part of the stenosed artery. The stenosis is measured and indicated on screen. Specify the reference value Click button from [Manual] menu. Click points on opposite sides of the part of the un-stenosed artery.
  • Page 33 ■ Left Ventricle Analysis (LV) Perform LV analysis with a projected image of RAO 30 degrees (or images of RAO 30 degree and LAO 60 degree). LV Tool Bar Click and select LV Tool bar will appear. Perform calibration To perform calibration, display the image of reference object (such as a ball) previously acquired with the same magnification as the analysis object.
  • Page 34 Outline the ventricular wall Outline each image of End-of-Diastole (ED) and End-of-Systole (ES). Outline both ED and ES image repeating the following procedure. Click the projection icon that corresponds to the image. RAO ED RAO ES LAO ED LAO ES Using the mouse, click multiple points along the ventricular wall starting from the base of the aorta.

  • Page 35: Operating Dsa Tool

    Operating DSA Tool Click and select [DSA Tools] bar will appear. Button Function Setting mask image. Switching ON/OFF of subtraction. Resetting mask image. Executing reregistration. (Shift the mask image) Click [Pixel Registration] tool bar will appear. Button Function Moves the mask image upward. Moves the mask image downward.

  • Page 36: Printing Images

    Printing Images Click Printer dialog will appear. Setting any required items such Click Printing is started. Closing Study Click from [Study] menu...

  • Page 37: Administration

    Administration Managing Studies Click from [Study] menu [Studies Management] window is displayed. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ Button Function Searches based on the search target set by the [System] and [Drives] Search buttons, plus all search criteria. View Displays the selected study or studies in the Image Viewer window.

  • Page 38: Sending Studies

    Button Function Info Displays detailed information about the selected patient. Permanently deletes the unprotected studies selected from the local Delete system. Write Prepares and writes the selected studies to CD/DVD. Protect Protects the selected studies from deletion. Unprotect Removes protection from selected studies. Sending Studies Select the desired studies in the Study List...

  • Page 39: Writing To Cd/Dvd

    Writing to CD/DVD Select the studies Select the desired studies from the Study List. Click Prompted to insert a blank disc to the writer. Insert a blank disk. Media Writing dialog box appears. Volume name is changeable. Click Writing is started. To cancel a media write, click on the side menu of the Image Viewer window.

  • Page 40: Trouble Shooting

    Trouble Shooting Emergency Halt ■ Halting the C-arm Press (Stop switch) Stop Switch Stop Switch Stop Switch CyberGrip Cyber Console Catheterization Table ■ Resetting the Emergency Halt Turn (Stop switch) clockwise When resetting, be sure to reset the pressed switch. NOTE Reset the STOP switch after the message "Stop Mode: Reset OK"...

  • Page 41: Shutdown Failure

    Shutdown Failure If trouble occurs when trying to shut down the Digital Radiography System via [Exit] button (system does not shut down), shut down the system according to the following procedure. Digital Operation Cabinet (Control Room) Press and hold the Power button for at least 5 seconds The power goes off.

  • Page 42: Reboot The Digital Radiography System Application

    To restart the system, wait 1 minute after turning off power to NOTE the X-ray generator, then press (ON) again. If the acquisition monitor is blank when restarting the system NOTE after shutdown failure, press the power button on the digital control cabinet in the equipment room to turn on the power.

  • Page 43: Error Messages

    CD-R or DVD-R media are used as patient data archive, An error occurred during cache. re-write all unsaved patient data to new CD-R or DVD-R. No available cache. If not, please contact Shimadzu service representative. Insert a blank CD-R or DVD-R and re-execute the Burn Operation Failed. operation.
  • Page 44 DC power of FPD is [DC Power Supply]:Overload overloaded. Error of sensor chassis Stop study immediately temperature. HV and DC and contact Shimadzu [Sensor]:Temperature error power of FPD shut down after service representative. 30 minutes. HV and DC power of FPD shut down immediately.
  • Page 45 Radio Over Current +200 mA. If this message appears repeatedly though Measured tube voltage Measured kV Over pressing [RESET] key, exceeded permitted range. contact Shimadzu service Starter Error Starter failure. representative. Abnormal filament heating I.F. Over current. Supply voltage exceeded Line Voltage Over permitted range.
  • Page 46 HU Full Stored permitted limit. X-ray tube unit temperature Thermal Over exceeded the permitted limit. Water flow in heat Contact Shimadzu service (LX-Tube Water) Flow Error exchanger of X-ray tube is representative. stopped. Contact Shimadzu service representative. Water volume of heat...

  • Page 47: Other Messages

    Radiography is not possible while this message is displayed. Message Description Action The examination room door Door/Interlock Close the door. is open. Contact Shimadzu service representative. Heat Exchanger of FPD FPD (Water) Flow Error (It's possible to perform detects error. fluoroscopy and radiography) ■...
  • Page 48 Low Battery Drop of battery voltage. Shimadzu service representative. Incorrect installation setting Pos. Calibration Error of position detection. Contact Shimadzu service Incorrect installation Lever Calib. Error setting of the console. representative. Detects disconnection of Interlink Error ! XXX console.
  • Page 49 2009.11...
