ECP-103J
DMX Dimming Controller
【USER MANUAL】
Lite-Puter Ent. Co., Ltd.
website:
www.liteputer.com.tw
E-mail:
sales@liteputer.com.tw
Lite-Puter
ECP-103J [EUM-D]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECP-103J and is the answer not in the manual?

Questions and answers

Related Manuals for Lite-Puter ECP-103J

Summary of Contents for Lite-Puter ECP-103J

  • Page 1 ISO 9001 CERTIFIED www.liteputer.com.tw ECP-103J DMX Dimming Controller 【USER MANUAL】 Lite-Puter Ent. Co., Ltd. website: www.liteputer.com.tw E-mail: sales@liteputer.com.tw Lite-Puter ECP-103J [EUM-D]...

  • Page 2: Table Of Contents

    2.6.1 TIMER Switch on / off ..............9 2.6.2 TIMER setting ................9 2.6.3 TIMER modify................12 2.6.4 TIMER Delete................12 2.6.5 System timing modify..............13 2.7 CHANNEL setting..................14 2.7.1 Setting of max. control channel ..........14 2.7.2 Switching off of control channel..........14 2.8 MEMORY DEFAULT ................14 Lite-Puter ECP-103J [EUM-E]...

  • Page 3: Chapter 1 Introduction

    6 set of chaser memory, up to 24 step per set 1.2 Specification Power supply：DC12V/1A Control signal：DMX512 Control channel：60 channel ☺ Connector： XLR 3pin (×1), XLR 5pin(×1), phone jack RJ11 (×2) Dimension： 125(W) x 170(H) x 55(D) mm Weight： 1.5 kg Lite-Puter ECP-103J [EUM-E]...

  • Page 4: Control Key Lock & Unlock

    ISO 9001 CERTIFIED www.liteputer.com.tw Chapter 2. ECP-103J Operation IMPORTANT: PRIOR TO USE, CHARGE BATTERIES FOR 8 HOURS 2.1 CONTROL KEY lock / unlock STEP-1 Press【FCN】+【OFF】+【◄】+【►】key to lock / unlock buttons【FCN】 、 【◄】 、 【►】 、 【▲】 、 【▼】 2.2 SCENE setting 2.2.1 Scene setting...

  • Page 5: Chaser Edit & Modify

    Press【▲】or【▼】to select CHASER01~CHASER06, and press【1】to edit or press 【2】to skip. STEP-4 Select【►】or【◄】STEP01~24, and【▲】or【▼】SC01~SC40，press【FCN】to save and quit STEP 01=SC 001 Press ’Fnc’ quit Warning ! after save, the scene of chaser will be delete, be sure before you modify. Lite-Puter ECP-103J [EUM-E]...

  • Page 6: Chaser Speed And Keep Time Setting & Modify

    Press【▲】or【▼】for CHASER SPEED modify 0.1 Sec. ~99 Min.；Press【◄】or 【►】 for KEEP TIME modify 0.1 Sec. ~10 Sec.，and press【FCN】key to save CHASE SPEED=0.1S KEEP TIME=0.1S ◄► ※ Regarding to CHASE SPEED & KEEP TIME ，please refer to figures of page 7。 Lite-Puter ECP-103J [EUM-E]...

  • Page 7: Chaser Mode And Fade Setting & Modify

    Press【FCN】 key，and press【▲】or【▼】to select F9 F8: LOAD SC →F9: CHASER MODE STEP-3 Press【FCN】to CHASER MODE and FADE ON/OFF。 STEP-4 Press【▲】or【▼】to choose chaser mode；to press【◄】or【►】to choose Fade on or off. press【FCN】to save ▲▼ CHASER MODE: 01 ◄► FADE: ON, OFF Lite-Puter ECP-103J [EUM-E]...
  • Page 8 Re : 4 different of color mix type MODE 1, CHASE SPEED=3S,KEEP TIME=2S SC1=CH1=100%, SC2=CH1~CH2=100%, SC3=CH1~CH3=100% SC 1 SC 3 SC 2 MODE 2, CHASE SPEED=3S, KEEP TIME=2S SC1=CH1=100%, SC2=CH1~CH2=100%, SC3=CH1~CH3=100% SC 1 SC 3 SC 2 Lite-Puter ECP-103J [EUM-E]...
  • Page 9 ISO 9001 CERTIFIED www.liteputer.com.tw MODE 3, CHASE SPEED=3S, KEEP TIME=2S(unavailable) SC1=CH1=100%, SC2=CH1~CH2=100%, SC3=CH1~CH3=100% SC 3 SC 1 SC 2 MODE 4, CHASE SPEED=3S, KEEP TIME=2S SC1=CH1=100%, SC2=CH1~CH2=100%, SC3=CH1~CH3=100% SC 1 SC 3 SC 2 Lite-Puter ECP-103J [EUM-E]...

  • Page 10: Timer Setting & Modify

    Press【FCN】key, and press【▲】or【▼】to select F4 →F4:EDIT TIMER F5:MODIFY CLOCK STEP-2 Press【FCN】for TIMER EDIT = = = = END = = = = <-,-> REVIEW DAT = = = = END = = = = 2DEL 3ADD 4EDIT Lite-Puter ECP-103J [EUM-E]...
  • Page 11 Press【►】for next selecting, press【▲】or【▼】to adjust chase no. TIME=00:00, MOD=1 CHS=00, SPD=0.1S STEP-8 Press【►】for next selecting, press【▲】or【▼】to adjust SPD TIME=00:00,MOD=1 CHS=00, SPD=0.1S STEP-9 Press【►】for next selecting of the date，then press【▲】or 【▼】 to choose the date (execution mode) WDAY:EVERYDAY Lite-Puter KEEP TIME=0.1S ECP-103J [EUM-E]...
  • Page 12 Press【►】for next selecting of KEEP TIME，then press【▲】or【▼】 to select the time。 WDAY: EVERYDAY KEEP TIME=0.1S Remark：4 type of execution mode Diary execution: EVERYDAY Weekday execution: MON.-FRI. Weekend execution: SAT.-SUN. Sunday execution: SUNDAY STEP-11 Press【FCN】to save to skip. Lite-Puter ECP-103J [EUM-E]...

  • Page 13: Timer Modify

    Press【◄】or【►】to select the TIMER, and press【4】for modify STEP-4 Press【◄】or【►】to select, and press【▲】or【▼】to adjust（please refer to 2.6.2） STEP-5 Press【FCN】to confirm and save the setting 2.6.4 TIMER Delete STEP-1 Press【FCN】key and pres【▲】or【▼】to select F4 →F4:EDIT TIMER F5:MODIFY CLOCK STEP-2 Press【FCN】key for TIMER EDIT. Lite-Puter ECP-103J [EUM-E]...

  • Page 14: System Timing Modify

    Press【FCN】key to modify STEP-3 Press 【►】 or 【◄】 to select the one to modify . Press 【▲】 or 【▼】 for date and time modify 03’ FEB , 12 , WED. 11:29:14 STEP-4 Press【FCN】key to confirm and save Lite-Puter ECP-103J [EUM-E]...

  • Page 15: Channel Setting

    To Power off . Press and hold keys【▲】+【▼】+【FUN】+【OFF】together, in the mean time, power on until you see following message : INITIATE MEMORY? 1: YES , 2: NO STEP-2 Press 1 or 2 to select Remark : suggest to initiate memory for the first time use Lite-Puter ECP-103J [EUM-E]...
