Olympus DM-770 Training Manual

Olympus DM-770 Training Manual

Sheffield hallam university
Hide thumbs Also See for DM-770:

Advertisement

Quick Links

Download this manual See also: User Manual
Sheffield Hallam University
Olympus DM-770
Digital Recorder
Training Guide
Simon Crawley & Rich Nind
2/24/2017

Advertisement

loading
Need help?

Need help?

Do you have a question about the DM-770 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Olympus DM-770

Summary of Contents for Olympus DM-770

  • Page 1 Sheffield Hallam University Olympus DM-770 Digital Recorder Training Guide Simon Crawley & Rich Nind 2/24/2017...
  • Page 2 How to use the... Olympus DM-770 Digital Recorder - 1 -...

  • Page 3: Charging The Recorder

    Charging the recorder 1. Slide the USB connector slide lever in the direction of the arrow. The USB connector will extend out. 2. Connect the extension cable to this and the other end to a USB port on your PC or a plug adapter. You can connect the recorders USB connector directly to a computer port, however this is not recommended.
  • Page 4 Selecting folders and files The recorder provides five folders [A], [B], [C], [D] and [E]. Each folder can store up to 200 files. 1. While the voice recorder is in the stop mode, press the F1 (FOLDER) button. The folder changes each time you press this button, and will cycle through the five available folders.

  • Page 5: Setting An Index Mark

    4. You will see some information on screen - 5. Press the STOP button when you want to stop recording. Pausing / resuming a recording 1. Press the REC button during recording. The recording will pause and the blinking PAUSE message will appear on the display.
  • Page 6 You can set index marks during playback as well as recording, just follow the same process. Up to 200 index marks can be set in a single recording. Playback The recorder can playback your recordings, we would recommend using the earphones for a clearer playback or to connect and transfer the recordings to your home computer.

  • Page 7: Erasing Files

    6. Press the OK button to erase the file or folder. If you are unsure about erasing files using this method, you can cancel out at any time. You can also erase files from the recorder using the Olympus Sonority software on your computer.
  • Page 8 Using the Olympus Sonority software By being connected to a PC, the recorder enables you to do the following: • Recorded files can be played back on your computer • Recorded files can be transferred onto your computer, managed and...
  • Page 9 Olympus Sonority display window By connecting the recorder to your PC, you will automatically start the application. You will see the following screen. - 8 -...

  • Page 10: Playback Control Bar

    3. The file will be copied across. Do not disconnect the device while copying is in progress. Play a recording You can play back your recordings through the Olympus Sonority software. We recommend this because you have access to a range of options to improve the playback quality.
  • Page 11 Noise cancel control You can use the noise cancel control slider to help improve the quality of your recording. 1. While playing back a recording, drag the noise cancel control slider to the right. 2. There are 3 settings to try, so check to see which makes the biggest difference.
