Specifications - Sony KDL-26S2000, KDL-32S2000, KDL-40S2000 Operating Instructions Manual

Other Information

Specifications

Television system:
NTSC American TV Standard
ATSC (8VSB terrestrial) ATSC compliant 8VSB
QAM on cable ANSI/SCTE 07 2000
(Does not include CableCARD
functionality)
Channel coverage:
Terrestrial (analog) 2-69
Cable TV (analog) 1-125
Terrestrial (digital) 2-69
Cable TV (digital) 1-135
Antenna:
75-ohm external terminal for VHF/UHF
Screen size (measured diagonally):
KDL-26S2000: 26 inches
KDL-32S2000: 32 inches
KDL-40S2000: 40 inches
Panel System:
LCD (Liquid Crystal Display) Panel
Display resolution (horizontal × vertical):
1,366 dots × 768 lines
VIDEO IN 1/2/3:
S VIDEO (4-pin mini DIN) (VIDEO 1/2 only):
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
VIDEO: 1 Vp-p, 75 ohms unbalanced, sync negative
AUDIO: 500 mVrms (100% modulation)
Impedance: 47 kilohms
HD/DVD IN 4/5:
YP P (Component Video):
B R
Y: 1.0 Vp-p, 75 ohms unbalanced,
sync negative
P : 0.7 Vp-p, 75 ohms
B
P : 0.7 Vp-p, 75 ohms
R
Signal format: 480i, 480p, 720p, 1080i
AUDIO: 500 mVrms (100% modulation)
Impedance: 47 kilohms
HDMI IN 6:
HDMI: Video: 480i, 480p, 720p, 1080i
Audio: Two channel linear PCM 32, 44.1 and
48 kHz, 16, 20 and 24 bits
AUDIO: 500 mVrms (100% modulation)
Impedance: 47 kilohms
AUDIO OUT:
500 mVrms (100% modulation)
More than 1 Vrms at the maximum volume setting (Variable)
More than 500 mVrms (Fixed)
PC IN 7:
D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive
See the PC Input Signal Reference Chart on page 41
PC AUDIO INPUT:
Stereo mini jack, 0.5 Vrms, 1 kilohm
Headphones:
Stereo mini jack
Impedance: 16 ohms
42
Speaker:
Full range: KDL-26S2000: 42 × 150 mm (1
KDL-32S2000: 42 × 150 mm (1
KDL-40S2000: 55 × 150 mm (2
Speaker output:
10 W + 10 W
Power requirement:
120 V-240 V AC, 50/60 Hz
Power consumption:
In use: KDL-26S2000: 120W
KDL-32S2000: 150W
KDL-40S2000: 200W
In standby: Less than 0.1 W
Dimensions (W/H/D):
KDL-26S2000: (with stand) 658 × 516 × 219 mm
(without stand) 658 × 470 × 94 mm
KDL-32S2000: (with stand) 792 × 593 × 219 mm
(without stand) 792 × 546 × 99 mm
KDL-40S2000: (with stand) 988 × 716 × 334 mm
(without stand) 988 × 664 × 103 mm
Mass:
KDL-26S2000: (with stand) 13 kg (28 lb. 10 oz.)
(without stand) 11 kg (24 lb. 4 oz.)
KDL-32S2000: (with stand) 17 kg (37 lb. 7 oz.)
(without stand) 15 kg (33 lb.)
KDL-40S2000: (with stand) 27 kg (59 lb. 8 oz.)
(without stand) 21 kg (46 lb. 3 oz.)
Supplied accessories:
Remote control RM-YD005 (1)
Size AA batteries (2)
75-ohm coaxial cable (1)
AC power cord (1)
HD15-HD15 cable (1)
Support belt (1), securing screw (1) and wood screw (1)
Cable holder (1)
Operating Instructions (1)
Quick Setup Guide (1)
Leaflet (Installing the Wall-Mount Bracket) (1)
Warranty Card (1)
Online Registration Card (U.S.A. only) (1)
Optional accessories:
Headphones plug adapter
Connecting cables
Wall-Mount Bracket: SU-WL31 (KDL-26S2000/KDL-32S2000)
SU-WL51 (KDL-40S2000)
Optional accessories' availability depends on
its stock.
Design and specifications are subject to change
without notice.
× 6 inches) (2)
11
/
16
11 × 6 inches) (2)
/
16
× 6 inches) (2)
1
/
4
(26 × 20 × 8
3 5
/ / inches)
8 8
(26 × 18 × 3
5 3
/ / inches)
8 4
× 23 × 8
1 3 5
(31 / / / inches)
4 8 8
× 21 × 4 inches)
1 1
(31 / /
4 2
(39 × 28 × 13
1 1
/ / inches)
4 4
(39 × 26 1 × 4 1
/ / inches)
4 8
