Satellite Receiver
and Cable/Antenna
Satellite Receiver
VCR, Cable and
Antenna
VCR
Satellite
antenna
cable
S VIDEO
VIDEO
(yellow)
S VIDEO cable
AUDIO-L
(white)
A/V cable
AUDIO-R
(red)
If your satellite receiver is not equipped with S VIDEO, use a VIDEO
cable (yellow) instead of the S VIDEO cable.
Run the Initial Setup program, as described in "Setting Up the Channel
List" on page 18 after completing your connections.
CATV cable
S VIDEO
S VIDEO cable
AUDIO-L (white)
A/V cable
AUDIO-R (red)
If your VCR is not equipped with S VIDEO, use a VIDEO cable (yellow)
instead of the S VIDEO cable.
Run the Initial Setup program, as described in "Setting Up the Channel
List" on page 18 after completing your connections.
CATV/Antenna
cable (supplied)
VIDEO IN
1
S VIDEO
VIDEO
L
(MONO)
AUDIO
R
Antenna cable
(supplied)
VIDEO IN
1
S VIDEO
VIDEO
(yellow)
VIDEO
L
(MONO)
AUDIO
R
Getting Started
VHF/UHF
HD/DVD IN
(1080i/720p/480p/480i)
3
5
4
Y
OPTICAL OUT
P
B
P
R
AUDIO OUT
(VAR/FIX)
L
AUDIO
R
Rear of TV
VHF/UHF
HD/DVD IN
(1080i/720p/480p/480i)
3
5
4
Y
OPTICAL OUT
P
B
P
R
AUDIO OUT
(VAR/FIX)
L
AUDIO
R
Rear of TV
13
