PUMY-71VM, PUMY-125VM
··································································
1 1 Outdoor units / Y series / PUMY-71·125VM
CONTENTS
·································································
······························································
············································
·············································
·······························································
····················································
··············································
·········································
1
2
4
4
6
···························
8
····························
9
9
10
11
13
15
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric Y Series
Summary of Contents for Mitsubishi Electric Y Series
-
Page 1: Table Of Contents
1 1 Outdoor units / Y series / PUMY-71·125VM PUMY-71VM, PUMY-125VM CONTENTS 1. Specifications ································································· 2. Capacity Tables ······························································ 2-1 Correction by temperature ············································ ············································· 2-2 Correction by total indoor 2-3 Correction by refrigerant piping length ··························· 2-4 Correction at frosting and defrosting ····························... -
Page 2: Specifications
1. Specifications Model name PUMY-71VM Cooling Heating Capacity kcal/h 7,100 Power source ~/N 220-230-240V 50Hz / 208-230V 60Hz Power input 3.50/3.63 3.65/3.53 Current 17.5-16.7-16.0/18.1 18.2-17.4-16.0/17.6 Type Quantity Propeller fan Airflow rate /min Motor output 0.04 Type Hermetic Compressor Motor output Crankcase heater Refrigerant / Lubricant R22/MS56... - Page 3 1 1 Outdoor units / Y series / PUMY-71·125VM Model name PUMY-125VM Cooling Heating Capacity 14.0 16.0 kcal/h 12,500 Power source ~/N 220-230-240V 50Hz / 208-230V 60Hz Power input 6.57/6.43 6.10/6.03 Current 34.9-33.5-32.2/33.6 32.6-31.2-29.9/31.5 Type Quantity Propeller fan Airflow rate...
-
Page 4: Capacity Tables
2. Capacity table 2-1. Correction by temperature Cooling • Standard Specifications PUMY-71VM PUMY-125VM 14.0 Capacity Input 3.50/3.63 6.57/6.43 Source 208-230V Current 17.5-16.7-16.0/18.1 34.9-33.5-32.2/33.6 • Calculation Capacity' Capacity Ratio Capacity' Input Input Ratio Input' After correction Input' 1000 Current' Current' Source 0.91 (:PUMY-71VM) 0.85 (:PUMY-125VM) The Ratio of Cooling Capacity... - Page 5 1 1 Outdoor units / Y series / PUMY-71·125VM Heating • Standard Specifications PUMY-71VM PUMY-125VM Capacity 16.0 Input 3.65/3.53 6.10/6.03 Source 220-230-240/220V Current 18.2-17.4-16.0/17.6 32.6-31.2-29.9/31.5 • Calculation Capacity' Capacity Ratio Capacity' Input Input Ratio Input' After correction Input' 1000 Current'...
-
Page 6: Correction By Total Indoor
2-2. Correction by total indoor PUMY-71VM 1) Capacity 10.0 Heating Cooling Total capacity of indoor units 2) Input 4.00 Cooling 220V 60Hz 220V 50Hz 3.50 220V 50Hz 220V 60Hz Heating 3.00 2.50 2.00 Total capacity of indoor units 3) Current 20.0 Cooling 220V 50Hz... - Page 7 1 1 Outdoor units / Y series / PUMY-71·125VM PUMY-125VM 1) Capacity 17.0 Heating Cooling 15.0 13.0 11.0 Total capacity of indoor units 2) Input 7.00 Cooling 50Hz 60Hz 6.00 50Hz Heating 5.00 60Hz 4.00 3.00 2.00 Total capacity of indoor units 3) Current 36.0...
-
Page 8: Correction By Refrigerant Piping Length
2-3 Correction by refrigerant piping length To obtain a decrease in cooling/heating capacity due to refrigerant piping extension, multiply by the capacity correction factor based on the refrigerant piping equivalent length in the table below. • Cooling capacity correction PUMY-71VM PUMY-125VM 70 75 Piping equivalent length (m) -
Page 9: Correction At Frosting And Defrosting
1 1 Outdoor units / Y series / PUMY-71·125VM 2-4 Correction at frosting and defrosting When a decrease in heating capacity due to frosted and defrosting operations is considered, the value multi- plied by the correction factor in the table below represents the heating capacity. -
Page 10: Sound Levels
3. Sound levels PUMY-71VM Measurement condition NC60 NC50 NC40 Sound pressure level in anechoic room NC30 57 dB (A) NC20 Approximate minimum audible limit on continuous noise 1000 2000 4000 8000 OCTAVE BAND CENTER FREQUENCIES<Hz> PUMY-125VM Measurement condition NC60 NC50 NC40 Sound pressure level in anechoic room NC30... -
Page 11: External Dimensions
1 1 Outdoor units / Y series / PUMY-71·125VM 4. External dimensions PUMY-71VM Unit : mm... - Page 12 PUMY-125VM Unit : mm...
-
Page 13: Electrical Wiring Diagram
1 1 Outdoor units / Y series / PUMY-71·125VM 5. Electrical Wiring Diagram PUMY-71VM NAME NAME NAME SYMBOL SYMBOL SYMBOL AC,CT Current detection Fan control Terminal block <Transmission> Crankcase heater FUSE1 Fuse(2A) Terminal block Connector <Power supply> FUSE2 Fuse(6A) <Transmission> (Centralized control) Connector <DC Power supply>... - Page 14 PUMY-125VM SYMBOL NAME SYMBOL NAME SYMBOL NAME AC,CT Current detection Reactor Terminal block <Transmission> Surge absorber Fan control Terminal block Smoothing capacitor FUSE1 Fuse(2A) <Transmission> (Centralized control) Crankcase heater FUSE2 Fuse(6A) THHS Thermistor Connector <Power supply> FUSE Fuse(60A) <IPM radiator panel temperature detection> Connector <DC Power supply Intelligent power module Thermistor <Discharge temperature detection>...
-
Page 15: Refrigerant Circuit Diagram And Thermal Sensor
1 1 Outdoor units / Y series / PUMY-71·125VM 6. Refrigerant circuit diagram and Thermal sensor PUMY-71, 125VM...
