SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS

SERVICE MANUAL

R410A
Outdoor unit
[model name]
PUHZ-RP35VHA4
PUHZ-RP50VHA4
PUHZ-RP60VHA4
PUHZ-RP71VHA4
PUHZ-RP100VKA
PUHZ-RP125VKA
PUHZ-RP140VKA
PUHZ-RP100YKA
PUHZ-RP140YKA
PUHZ-RP200YKA
PUHZ-RP250YKA
PUHZ-RP60VHA4
PUHZ-RP71VHA4
[Service Ref.]
PUHZ-RP35VHA4
PUHZ-RP50VHA4
PUHZ-RP60VHA4
PUHZ-RP71VHA4
PUHZ-RP100VKA
PUHZ-RP125VKA
PUHZ-RP140VKA
PUHZ-RP100YKA
PUHZ-RP125YKA
PUHZ-RP140YKA
PUHZ-RP200YKA
PUHZ-RP250YKA
Note:
• This manual describes only
• RoHS compliant products
CONTENTS
1 REFERENCE MANUAL ·································· 2
2 SAFETY PRECAUTION ·································· 2
3 FEATURES ······················································ 6
4 SPECIFICATIONS ··········································· 7
5 DATA ······························································ 10
6 OUTLINES AND DIMENSIONS ···················· 16
7 WIRING DIAGRAM ······································· 20
8 WIRING SPECIFICATIONS ··························· 25
9 REFRIGERANT SYSTEM DIAGRAM ·············· 30
10 TROUBLESHOOTING ··································· 34
11 FUNCTION SETTING ···································· 94
12 MONITORING THE OPERATION DATA BY THE REMOTE CONTROLLER ···101
13 EASY MAINTENANCE FUNCTION ·············111
14 DISASSEMBLY PROCEDURE ···················· 116
PARTS CATALOG (OCB451)
May 2009
No.OCH451
service data of the outdoor
units.
have <G> mark on the
spec name plate.
