2.
Press <Delete> or <F2> to enter the BIOS Setup program at the system startup.
From the Advanced menu, click Trusted Computing.
3.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Main
Ai Tweaker
Platform Misc Configuration
System Agent (SA) Configuration
PCH Configuration
PCH Storage Configuration
PCH-FW Configuration
Trusted Computing
Onboard Devices Configuration
APM Configuration
USB Configuration
Network Stack Configuration
HDD/SSD SMART Information
HDD Secure Erase
Event Log
Version 2.17.1246 Copyright (C) 2018 American Megatrends, Inc.
Set the Security Device Support and TPM State items to [Enabled].
4.
Aptio Setup Utility - Copyright (C) 2018 American Megatrends, Inc.
Main
Ai Tweaker
TPM20 Device Found
Security Device Support
Active PCR banks
Available PCR banks
SHA-1 PCR Bank
SHA256 PCR Bank
Pending operation
Platform Hierarchy
Storage Hierarchy
Endorsement Hierarchy
TPM2.0 UEFI Spec Version
Physical Presence Spec Version
Version 2.17.1246 Copyright (C) 2018 American Megatrends, Inc.
5.
Press <F10> to save the changes, exit the BIOS Setup program and boot into the OS.
Now you can start using the TPM-SPI card with Windows
Advanced
Monitor
Advanced
Monitor
Boot
Tool
Exit
Boot
Tool
Exit
[Enable]
SHA-1,SHA256
SHA-1,SHA256
[Enabled]
[Enabled]
[None]
[Enabled]
[Enabled]
[Enabled]
[TCG_2]
[1.3]
BitLocker.
®
Trusted Computing Settings
:
Select Screen
: Select Item
Enter: Select
+/-: Change Opt.
F1:
General Help
F2:
Previous Values
F5:
Optimized Defaults
F10: Save & Exit
ESC: Exit
Enables or Disables BIOS
support for security
device. O.S. will not
show Security Device. TCG
EFI protocol and INT1A
interface will not be
available.
:
Select Screen
: Select Item
Enter: Select
+/-: Change Opt.
F1:
General Help
F2:
Previous Values
F5:
Optimized Defaults
F10: Save & Exit
ESC: Exit
