9. Install the console.
10. Install the battery compartment cover.
11. Close the hood.
5B410023

Fuse replacement

The main fuse, the fuel injection system fuse,
and the fuse box are located under the hood.
If a fuse is blown, turn off the main switch and
install a new fuse of the specified amperage.
If a fuse is blown, replace it as follows.
1. Turn the key to "OFF" and turn off the
electrical circuit in question.
NOTICE
To prevent accidental short-circuiting,
turn off the main switch when checking or
replacing a fuse.
2. Open the hood. (See pages 8-7–8-8 for
hood opening and closing procedures.)
8-53
