Miroir ELEMENT Series Quick Start Manual page 2

Your Miroir Micro Projector
A
D
E
F
B
I
J
K
G
H
Projector Lens
A
Focus Wheel – Roll the focus wheel forward and backwards
B
to fine-tune the projected image.
Volume Controls – Increase (+) or decrease (-) the volume
C
output of the projector.
Audio Out (3.5mm) – Connect an external speaker or
D
headphones.
USB Power Output – Connect a USB power cable to
E
provide power to a HDMI streaming stick or to charge a
smartphone battery. Cannot be used for video input.
C
HDMI Video Input – Connect an HDMI cable to a device
F
that supports HDMI video output.
Reset Button – Press to reset projector.
G
Micro USB Charging Port – Connect the supplied Micro
H
USB to USB charging cable to a USB wall outlet or USB
port on a computer to charge the projector's internal
battery. Fully charge battery before the first use (approx.
3-4 hours).
Power Indicator Light – Indicator light will illuminate red
I
when charging and illuminate green once fully charged.
System Indicator Light – Indicator light will illuminate blue
J
when the projector is starting up.
Power Switch – Connect the supplied Micro USB to USB
K
charging cable to a USB wall outlet or USB port on a
computer to charge the projector's internal battery. Fully
charge battery before the first use (approx. 3-4 hours).
