o p E R at i n g i n s t R U c t i o n s M a n U a L
MUELLER
A-3
Drilling
TM
and Tapping
Machine
!
WARNING:
1. Read and follow instructions carefully. Proper training and periodic review
regarding the use of this equipment is essential to prevent possible serious
injury and/or property damage. The instructions contained herein were
developed for using this equipment on fittings manufactured by Mueller Co.,
and may not be applicable for any other use.
2. Do not exceed the pressure ratings of any components or equipment.
Exceeding the rated pressure may result in serious injury and/or property
damage.
3. Safety goggles and other appropriate protective gear should be used.
Failure to do so could result in serious injury.
4. Pressure test, check for and repair leaks in all fittings and components
each time one is installed or any joint or connection is broken. Failure
to find and repair a leak from any source in the fittings, by-pass lines or
equipment could result in an explosion and subsequent serious injury and/
or property damage.
5. Mueller Drilling Machines and Equipment have been carefully designed
and engineered to work together as a unit. The use of equipment
manufactured by someone other than Mueller Co. may cause excessive
wear or a malfunction of the Mueller machines.
®
Installation & Operating Instructions
All warranties, expressed or implied, for Mueller Drilling Machines are
rendered null and void if the machines are used with shell cutters or
equipment manufactured by someone other than Mueller Co.
tAble of ContentS
General Information
Maintenance Instructions
Parts Information
Notes
Reliable Connections
Customer Service Center
Decatur, Illinois
800.798.3131
www.muellercompany.com
moreinfo@muellercompany.com
PAGe
2
3
4-9
10
11
